1. General
1.1 Exterior views
Operating Side
Non-Operating Side
Fresh water filler cap
Cover
Sea water pump
<Note> This illustration shows the 3YM30 with Yanmar marine gear (Model:KM2P-1).
Intake silencer
Marine gear
V-belt
Intake manifold
Engine name plate (on the rocker arm cover)
Coolant tank / Heat exchanger
Alternator
1
1. General
Oil filter cap
Fuel filter
Fuel injection pump
Dipstick
Oil filter cap
Fuel feed pump
Lubricating oil filter
Exhaust manifold
Starter motor
Shift lever
