T E C H N O L O G I E S
PCI Slot Mount
Master/Slave Setting
CF/MD Slot
Bay Mount
Master/Slave Setting
CF/MD Slot
Technical Support
If you need any assistance to get your unit functioning properly, please have your
product information ready and contact Addonics Technical Support at:
Hours: 8:30 am - 6:00 pm PST
Phone: 408-453-6212
Email: http://www.addonics.com/support/query/
User Guide
IDE CF Adapter
(ADIDECF, ADIDECFB, ADIDECF-N)
40-Pin IDE Connector
4-Pin Floppy
Power Connector
Eject Button
40-Pin IDE Connector
4-Pin Floppy
Power Connector
Eject Button
v4.1.11
Advertisement
Related Manuals for Addonics Technologies ADIDECF
Summary of Contents for Addonics Technologies ADIDECF
-
Page 1: User Guide
User Guide IDE CF Adapter T E C H N O L O G I E S (ADIDECF, ADIDECFB, ADIDECF-N) PCI Slot Mount 40-Pin IDE Connector Master/Slave Setting 4-Pin Floppy Power Connector CF/MD Slot Eject Button Bay Mount 40-Pin IDE Connector... - Page 2 Addonics IDE/CF Converter Board is a converter solution for the IDE port to have CF card interface. It has a standard 40 pin or 44-pin IDE port, which can interface to IDE host side and 50-pin Compact Flash socket in device side. This is a convenient interface that allows Compact Flash modules to be used in any system that has a standard IDE 40 pin or 44-pin connector.
