SATA Data and
Power Connector
Technical Support
If you need any assistance to get your unit functioning properly, please have your
product information ready and contact Addonics Technical Support at:
Hours: 8:30 am - 6:00 pm PST
Phone: 408-453-6212
Email: http://www.addonics.com/support/query/
User Guide
mSATA - SATA
HDD Adapter
(ADMSAHDD)
mSATA SDD
slot
v7.1.11
Hardware Installation:
Step 1: Insert mSATA SSD into the slot diagonally.
Step 2: Push the mSATA SDD down so the holes on the mSATA SDD are aligned
with the screw holes on the mSATA - SATA HDD Adapter.
Step 3: Using the two included screws, secure the mSATA SDD onto the adapter.
Step 4: Connect adapter onto a computer with 15-pn SATA power connector and
7-pin SATA data connector to access data on the mSATA SSD, or replace 2.5" SATA
hard drive inside a notebook.
Note:
Optional mounting brackets can be purchased to mount the adapter
into any 3.5" drive enclosure, 3.5" drive bay, 2.5" drive enclosure, or slim CD
bay.
