- Page 1 ® ™ Monitored Security System Installer's Guide 2000™ Monitored Security System, Model Pro 2000™...
- Page 2 Also, the telephone company can make changes to its lines, equipment, operations, or If necessary, consult X-10 Pro Technical procedures that could affect the operation of Support for additional suggestions. this console. The telephone company notifies The security console’s telephone dialer is...
-
Page 3: Table Of Contents
Door/Window Sensor ................11 Motion Detector ..................12 Power Horn ....................14 Lamp Module ..................... 15 Other X-10 PRO Products ..............16 Monitoring Station Setup ..............17 Introduction ....................17 Options downloaded for the monitoring station ........17 Setting up for Monitoring Service ............20 Battery Information ................ -
Page 4: Introduction
• Up to 16* Keychain Remotes with arm/disarm/panic and security light functions. • Up to 16* Handheld Security Remote with arm/disarm and panic functions, and buttons to control the security light and up to four additional X-10 Pro Home Automation modules to operate lights and appliances around the home. -
Page 5: Installation
Installation Locating Security System components Locating the Security Console Choose a location for the Security Console which is as central as possible in the house, while providing access to a modular telephone jack and an AC outlet. Fix the console to the wall using the mounting bracket and screws provided. -
Page 6: Mounting The Security Console
Installation Security Console Mounting the console The Security Console is designed to be installed on a hollow section wall or mounting panel. A hole is cut into the wall to allow the telephone and power cables to run out behind the console. A metal bracket is provided which is screwed to the panel. Hooks on the bracket locate in slots at the back of the console. -
Page 7: Attaching Cables/Rj31X Jack Installation
Installation Attaching cables/RJ31X Jack Installation A telephone cord terminated with an RJ31X connector is provided for telephone connection. This ensures that the Console will ALWAYS dial out when tripped, even if the phone line is busy at the time. Note the RJ31X jack to which you connect the Console might have to be installed by the phone company. -
Page 8: Back-Up Battery Installation
Installation Installation Fitting backup batteries Slide out the battery drawer from the bottom of the console and insert four AA Alkaline batteries. Refit the drawer making sure it is fully home in the cabinet. When AC power is applied the battery LED on the front panel will go out. It is not necessary to disconnect power to the console when fitting or replacing batteries. -
Page 9: Security Remote
Installation Security Remote Registering the Security Remote with the Security Console • Set the code dial on the Security Remote to the same House Code as the programmed in the Security Console. Note: The House Code for the Security System is downloadable. The default setting is House Code A. -
Page 10: Keychain Remote
Installation Keychain Remote Registering the Keychain Remote with the Security Console • Fit two AAA Alkaline batteries in the battery compartment in the back of the Keychain Remote. • Press and hold the ARM button for about a second. The LED indicator flashes twice when you release it. -
Page 11: Door/Window Sensor
Installation Door/Window Sensor Ideal location Two windows (requires accessory magnetic switch pair) Sliding window Installing the Door/Window Sensor • Attach the Door/Window Sensor to the wall using the mounting screws provided. • Fit the Door/Window Sensor as high as possible at the top of the door/window. •... -
Page 12: Motion Detector
Installation Motion Detector Installing the Motion Detector • Attach the Motion Detector to a wall at a height of 5 to 6ft using the mounting bracket and screws provided. Note: The Motion Detector has a special lens that 'looks' downwards. It must therefore be mounted to face outwards horizontally, i.e. -
Page 13: Testing The Motion Detector
Installation Testing the Motion Detector • Set the slide switch on the Motion Detector to position 1. • Press and hold the TEST button for about a second. The LED flashes twice when you release it. • Wait 20 seconds for the sensor to settle. •... -
Page 14: Power Horn
• Press the ON button followed by the OFF button, followed again by the ON button, on any X-10 controller or remote which is set to the same House Code and Unit Code as the Power Horn. The siren will activate and will continue for 4 seconds, or until two OFF commands are received in succession. -
Page 15: Lamp Module
Installation Lamp Module Installing the Lamp Module to control the security light • Set the House Code and Unit Code dials to match the security light code downloaded by the installing security firm. This allows it to be controlled from the security light buttons on the remotes, and to be flashed by the console during an alarm. -
Page 16: Other X-10 Pro Products
Telephone Responder which allows the owner to use any touch tone 'phone to call home and control X-10 Pro modules, and products which allow any Windows™ or DOS PC to control X-10 functions. -
Page 17: Monitoring Station Setup
Automatic lighting control When the X-10 PRO2000 Security System is armed in the away mode, an automatic timer can be activated to turn lights, stereos, TVs, etc. on and off at random times to make the home look lived in. - Page 18 Monitoring Service Setup The above screen shows the options that can be downloaded to the Console. 1. Account number- The customer's 4 digit account number. 2. 1st Monitoring Station Number- The 1st number the console will dial to call the monitoring station.
- Page 19 Check the box for pulse dialing. 18. X-10 flashing during alarm- If this option is turned off, the lights will not flash when the alarm is triggered, although the console will still dial out. The default is flashing.
-
Page 20: Setting Up For Monitoring Service
27. Disable Daylight savings - Check if daylight savings is not observed in your State. 28. All Lights Flash- Check to flash All lights connected to X-10 PRO Lamp and Wall Switch Modules (set to the same Housecode as downloaded) when the alarm trips. - Page 21 Monitoring Service Setup If the modem does not initialize you might not have the correct initialization string set for your type of modem. The default setting is for a US Robotics modem, and is as follows. AT&F1 &N1 S9=1 S10=250 S27=1 Where: &F1 *restores the factory profile 1 (hardware flow control).
-
Page 22: Battery Information
Battery Information General X-10 PRO Door/Window Sensors, Motion Detectors and Security, Keychain remotes are designed to operate for approximately two years when fitted with alkaline batteries. However, since environmental and operating conditions vary from installation to installation it is recommended that all batteries are replaced once a year. -
Page 23: Door/Window Sensor And Motion Detector
Battery Information Door/Window Sensors and Motion Detectors Battery Replacement If any of the Console's zone indicators flash slowly, the Motion Detector or Door/Window Sensor for that zone has not reported in during the last four hours. This is most likely caused by a dead battery. -
Page 24: Troubleshooting
Troubleshooting PROBLEM SOLUTION If the system does not arm. • Check that the slide switch under the SET UP flip door is set to RUN1 or RUN2. • Check that the battery indicator on the Remote Control turns on when you press ARM. - Page 25 Troubleshooting PROBLEM SOLUTION If you hear a repetitive trouble alarm Check the zone indicators. If a door or when you try to arm the system, and it window is open, its zone indicator is on. If does not arm. there is a problem with a Sensor or Motion Detector, its zone indicator flashes slowly.
- Page 26 Troubleshooting PROBLEM SOLUTION You open a door or window and the • Check that the system is armed. alarm does not trip. • Be sure the slide switch under the SET UP flip door is in the RUN1 or RUN2 position. •...
- Page 27 Troubleshooting PROBLEM SOLUTION If you do not hear a chime from the With the Console in the RUN 2 mode, Consol e when you pr ess TEST to install check that it chimes when you press a Door/Window Sensor or Motion TEST on the sensor/motion detector.
- Page 28 Troubleshooting PROBLEM SOLUTION If the armed indicator is flashing. This indicates that there has been an intrusion. Also, if a zone indicator is on, this indicates which zone was violated. To turn the zone indicator off, and stop the armed indicator from flashing press ARM then DISARM on the remote control.
-
Page 29: Special Notes
However, if you continue to have a troubled RF area, you can use an X-10 PRO PSX01 Smart Repeater (located half way between the Console and the Sensor) to repeat the signals to and from the troubled area. -
Page 30: Installation Notes And Set-Up Sheets
14. Unit Code 1(Security Light) to flash lights and turn on at dusk- 15. Unit Codes 2, 3, 4 for Lived-in look- 16.Unit Code 5 - 17. Tone or Pulse dialing- 18. X-10 flashing during alarm- 19. Dialing enabled- 20. No Console Siren during alarm- 21. Enable Unit Code 5- 22. - Page 31 Notes 24. Monitor alert set- 25. 50 Hz Operation- 26. Daylight savings active- 27. Disable Daylight savings - 28. All Lights Flash- 29. Enable Entry Light- PRO2000 Zone and Remote Set-up Zone # Type Name Delay/Instant (Door/Window/Motion) (front door, etc.) (D/I) Number of HandHeld Remotes______ Number of Keychain Remotes______...
