Page 1: Washing Machine
WW10H8***** Washing Machine User manual Imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please visit www.samsung.com Untitled-5 1 2014-02-06 7:04:08... -
Page 2: Table Of Contents
Content Safety information What you need to know about the safety instructions ....... . 3 Important safety symbols . -
Page 3: Safety Information
Safety information Congratulations on your new Samsung washing machine. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your washing machine’s many benefits and features. -
Page 4: Important Safety Precautions
Important safety precautions WARNING: To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: Do not let children (or pets) play in or on your washing machine. The washing machine door does not open easily from the inside and children may be seriously injured if trapped inside. - Page 5 CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility. WARNING: Critical installation WARNINGS The installation of this appliance must be performed by a qualified technician or service company.
- Page 6 Do not use an electric transformer. • This may result in electric shock or fire. Do not use a damaged power plug, damaged power cord, or loose wall socket. • This may result in electric shock or fire. Do not pull or excessively bend the power cord. Do not twist or tie the power cord.
- Page 7 • Failure to do so may result in electric shock or fire. If any foreign substance enters into the appliance, unplug the power plug and contact you nearest Samsung Customer Service. • This may result in electric shock or fire.
- Page 8 Using the product for business purposes qualifies as a product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
- Page 9 Water drained during a high-temperature wash or drying cycle is hot. Do not touch the water. • This may result in burns or injury. Do not wash, spin, or dry water-proof seats, mats, or clothing (*) unless your appliance has a special cycle for washing these items.
- Page 10 • Failure to do so may result in injury due to abnormal vibrations. Do not use hardened detergent. • If it accumulates inside the washing machine, it may result in a water leak. Make sure that the pockets of all the clothing items to be washed are empty. •...
-
Page 11: Installation
What’s included Make sure all the parts are included in the product package. If you have a problem with the washing machine or the parts, contact a local Samsung customer centre or the retailer. Detergent drawer Door... -
Page 12: Installation Requirements
Installation requirements Electrical supply and grounding • AC 220-240 V / 50 Hz fuse or circuit breaker is required • Use an individual branch circuit specific to the washing machine To ensure proper grounding, the washing machine comes with a power cord featuring a three- prong grounding plug for use in a properly installed and grounded outlet. -
Page 13: Water Temperature
Drain Samsung recommends a standpipe in height of 60~90cm. The drain hose must be connected through the hose clip to the standpipe, and the standpipe must fully cover the drain hose. Flooring For best performance, the washing machine must be installed on a solid floor. Wood floors may need to be reinforced to minimize vibration and/or unbalanced loads. -
Page 14: Step-By-Step Installation
Step-by-step installation STEP 1 - Select a location Location requirements: • Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • Adequate room for ventilation and wiring • The ambient temperature is always higher than the freezing point (0 ˚C) •... - Page 15 STEP 4 - Connect the water hose Connect the water supply hose to the water tap. 1. Remove the adaptor (A) from the water supply hose (B). 2. Use a Philips screwdriver to loosen four screws on the adaptor. 3. Hold the adaptor and turn part (C) in the arrow direction to loosen it by 5 mm (*).
- Page 16 WARNING Stop using the washing machine if there is a water leak, and contact a local Samsung service centre. Otherwise, this may cause electric shock. CAUTION Do not stretch the water supply hose by force.
-
Page 17: Environment
Aqua hose (applicable models only) The aqua hose alerts users of a risk of water leaks. It senses the water flow and turns red on the centre indicator (A) in case of a leak. STEP 5 - Position the drain hose The drain hose can be positioned in three ways: Over the edge of a wash basin The drain hose must be placed at a height of between 60 cm and... -
Page 18: Before You Start
Before you start Initial settings Run Calibration (recommended) Calibration ensures accurate weight detection by the washing machine. Make sure the drum is empty before running Calibration. 1. Press the Power button to turn on the washing machine. 2. Press and hold the Temp. and Delay End buttons simultaneously for more than 3 seconds. The washing machine enters the Calibration mode with a message of “Cb”... -
Page 19: Laundry Guidelines
Laundry guidelines STEP 1 - Sort Sort the laundry according to these criteria: • Care Label: Sort the laundry into cottons, mixed fibres, synthetics, silks, wools, and rayon. • Colour: Separate whites from colours. • Size: Mixing different-sized items together in the drum improves the washing performance. •... - Page 20 STEP 5 - Determine the load capacity Do not overload the washing machine. Overloading may cause the washing machine to not wash properly. For the load capacity for the type of clothing, see page 25. When washing bedding or bedding covers, the wash time may be lengthened or the spin efficiency may be reduced.
-
Page 21: Detergent Drawer Guidelines
Detergent drawer guidelines The washing machine provides a three-compartment dispenser: the left compartment for the main wash, the front-right for fabric softeners, and the rear-right for the preliminary wash. Prewash detergent compartment Main wash detergent compartment: powder detergents, water softeners, pre-soaking agents, bleach, and stain removers Fabric softener compartment CAUTION... - Page 22 4. If selecting the Prewash option, apply an appropriate amount of detergent to the rear-right compartment ( ). 5. Slide the detergent drawer inward to close it. Liquid detergent container (Applicable models only) To use a liquid detergent, first put the provided liquid detergent container in the main wash detergent compartment ( ).
-
Page 23: Operations
Operations Control panel Turn the dial to select a course. Course Selector Display area Displays information of remaining washing time, and settings. Press to change the water temperature for the current course. Temp. Press and hold for 3 seconds to turn on/off the Drum Light. Press to change the rinse times for the current course. -
Page 24: Simple Steps To Start
Simple steps to start 1. Press the Power button to turn on the washing machine. 2. Turn the Course Selector to select a course. 3. Change the course settings (Temp., Rinse, and Spin) as necessary. 4. To add an option, press the Options button repeatedly until the corresponding option icon(s) turns on. -
Page 25: Course Overview
Course overview Standard courses Course Description & Max load (kg) • For cottons, bed linens, table linens, underwear, towels, or shirts. COTTON • The washing time and the number of rinse cycles are automatically adjusted according to the load. • Optimal performance with lower energy for cotton fabrics, bed linens, table linens, underwear, towels, or shirts. - Page 26 Course Description & Max load (kg) • Featuring an additional rinse after applying fabric softener to RINSE+SPIN the laundry. • Cleans the drum by removing dirt and bacteria from the drum. • Perform once every 40 washes with no detergent or bleach applied.
-
Page 27: Delay End
Prefer Mode Mode Description • This changes the course settings to reduce the overall washing time. Speed Wash • The recommended laundry load is less than 6.0 kg for the COTTON course with Speed Wash enabled. • This changes the course settings to save the overall power Eco Wash consumption. -
Page 28: Settings
Settings Child Lock To prevent accidents by children or infants, Child Lock locks all buttons. • To activate the Child Lock, press and hold both the Options and Prefer Mode buttons for 3 seconds. • To suspend or deactivate the Child Lock, press and hold both the Options and Prefer Mode buttons once for 3 seconds to suspend it, or press them twice to deactivate it. -
Page 29: Maintenance
Maintenance Keep the washing machine clean to prevent deteriorated performance and to preserve its life cycle. DRUM CLEAN Perform this course regularly to clean the drum and to remove bacteria from it. 1. Press the Power button to turn on washing machine. 2. -
Page 30: Smart Check
Smart check To enable this function, you must first download the Samsung Smart Washer/Dryer at the Play Store or the Apple Store, and install it on a mobile device featuring the camera operation. The Smart Check function has been optimized for: Galaxy &... -
Page 31: Emergency Drain
Emergency drain In case of a power failure, drain the water inside the drum before taking out the laundry. 1. Unplug the power cord of the washing machine from the main socket. 2. Gently press the top area of the filter cover to open. 3. -
Page 32: Cleaning
Cleaning Surface of the washing machine Use a soft cloth with a nonabrasive household detergent. Do not spray water onto the washing machine. Mesh filter Clean the mesh filter of the water supply hose once or twice a year. 1. Turn off the washing machine, and unplug the power cord. 2. - Page 33 Debris filter It is advisable to clean the debris filter 5 or 6 times a year to prevent its clogging. A clogged debris filter may reduce the bubble effect. 1. Turn off the washing machine, and unplug the power cord. 2.
- Page 34 Detergent Drawer 1. While holding down the release lever (A) on the inner of the drawer, slide open the drawer. 2. Remove the release lever and the liquid detergent container from the drawer. 3. Clean the drawer components in flowing water using a soft brush.
-
Page 35: Recovery From Freezing
Recovery from freezing The washing machine may freeze when it drops below 0 °C. 1. Turn off the washing machine, and unplug the power cord. 2. Pour warm water over the water tap to loosen the water supply hose. 3. Disconnect the water supply hose, and soak it in warm water. 4. -
Page 36: Troubleshooting
The door stays locked as long as the washing machine is still hot The door won’t open. inside after a heating operation. • Deactivate the Child Lock if activated. If a problem persists, contact a local Samsung service centre. English - 36 Untitled-5 36 2014-02-06 7:04:16... -
Page 37: Information Codes
The laundry load is unbalanced. Spread the laundry evenly. cE/3E/Uc • This is not user-repairable. Contact a local Samsung service centre. If any information code keeps appearing on the screen, contact a local Samsung service centre. English - 37 Untitled-5 37 2014-02-06... -
Page 38: Specifications
Specifications Protecting the environment • This appliance is manufactured from recyclable materials. If you decide to dispose of this appliance, please observe local waste disposal regulations. Cut off the power cord so that the appliance cannot be connected to a power source. Remove the door so that animals and small children cannot get trapped inside the appliance. -
Page 39: Fabric Care Chart
Fabric care chart The following symbols provide garment care directions. The care labels include four symbols in this order: washing, bleaching, drying and ironing (and dry cleaning when necessary). The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow the care label directions to maximize garment life and reduce laundry problems. -
Page 40: Specification Sheet
Specification sheet FRONT LOADING WASHING TYPE MACHINE MODEL NAME WW10H8***** DIMENSIONS W600×D600×H850(mm) WATER PRESSURE 50 kPa ~ 800 kPa WATER VOLUME 78 ℓ NET WEIGHT 73 kg WASH AND SPIN CAPACITY 10.0 kg 220 V 150 W WASHING 240 V 150 W 220 V 2000 W... - Page 41 Memo Untitled-5 41 2014-02-06 7:04:17...
- Page 42 Memo Untitled-5 42 2014-02-06 7:04:17...
- Page 43 Memo Untitled-5 43 2014-02-06 7:04:17...
- Page 44 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT AUSTRALIA 1300 362 603 www.samsung.com/au/support DC68-03379A Untitled-5 44 2014-02-06 7:04:17...
