Pro-face AGP-3300 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

AGP-3300 Series
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGP-3300 Series and is the answer not in the manual?

Questions and answers

Masao Seki
February 25, 2025

Based on the spec of AGP3300 series, backlight is CFL. Is this CFL backlight "Cold cathode fluorescent lamps (CCFLs)"?

0
1 comments:
Mr. Anderson
February 25, 2025

Yes, the CFL backlight of the Pro-face AGP-3300 Series refers to a Cold Cathode Fluorescent Lamp (CCFL).

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Pro-face AGP-3300 Series

Summary of Contents for Pro-face AGP-3300 Series

  • Page 1 AGP-3300 Series User Manual...

  • Page 2: Preface

    Preface Thank you for purchasing Pro-face's AGP-3300 Series Programmable Operator Interface (Hereafter referred to as the “AGP unit”). Before operating your AGP unit, be sure to read this manual to familiarize yourself with the AGP unit's operation proce- dures and features.

  • Page 3: Essential Safety Precautions

    Essential Safety Precautions All safety-related procedures stated in this document must be followed to operate the AGP correctly and safely. Be sure to read this and any related documents thoroughly to understand the correct operation and functions of the AGP unit. Safety Icons Throughout this manual, these icons provide essential safety information for AGP operation procedures requiring special attention.
  • Page 4 To prevent an accidental machine operation error, Pro-face suggests you use the AGP unit's built-in burn- out detection feature. This feature will automatically detect a backlight burnout and disable the touch screen.
  • Page 5 Installation Be sure all cable connectors are securely attached to the AGP unit. A loose connection may cause incor- rect input or output signals. Wiring Be sure to ground the AGP unit's FG wire separately from other equipment FG lines. Also, be sure to use a grounding resistance of 100Ω...
  • Page 6 Do not operate or store the AGP in locations where it can be exposed to direct sunlight, high tempera- tures, excessive dust, moisture or vibration. Do not operate or store the AGP where chemicals evaporate, or where chemicals are present in the air. Corrosive chemicals: Acids, alkalines, liquids containing salt Flammable chemicals: Organic Solvents Do not use paint thinner or organic solvents to remove dirt or oil from the AGP unit's surface.

  • Page 7: Information Symbols

    Information Symbols This manual uses the following icons: Indicates a warning or a product limitation. Be sure to follow the instructions given with this icon to ensure the safe operation of the AGP. Screen Editor Indicates the Pro-Designer software (version 4.2 or higher). Abbreviation for Programmable Logic Controller.

  • Page 8: Agp-3300 Series Model Names

    AGP-3300 Series Model Names The term “AGP-3300” Series refers to the following AGP model numbers: Series Model Name Model Type Comments AGP-3300L AGP3300-L1-D24 AGP-3300 Series AGP-3300S AGP3300-S1-D24 AGP-3300T AGP3300-T1-D24 AGP-3300 UL/c-UL/CSA Series Approved, CE Marked AGP-3301L AGP3301-L1-D24 AGP-3301 Series AGP-3301S...

  • Page 9: Ul/C-Ul/Csa Approval

    UL/c-UL/CSA Approval The AGP3300-L1-D24/AGP3300-S1-D24/AGP3300-T1-D24/AGP3301-L1-D24/AGP3301-S1-D24/AGP3302-B1-D24 are UL/c-UL/CSA listed products. UL File No.E182139 UL File No.E220851 AGP3300-L1-D24 (UL/CSA Registration Model:3280007-03) AGP3300-S1-D24 (UL/CSA Registration Model:3280007-02) AGP3300-T1-D24 (UL/CSA Registration Model:3280007-01) AGP3301-L1-D24 (UL/CSA Registration Model:3280007-13) AGP3301-S1-D24 (UL/CSA Registration Model:3280007-12) AGP3302-B1-D24 (UL/CSA Registration Model:3280007-24) These products conform to the following standards: UL508 Industrial Control Equipment UL1604...

  • Page 10: Ce Marking

    CE Marking The AGP3300-L1-D24/AGP3300-S1-D24/AGP3300-T1-D24/AGP3301-L1-D24/AGP3301-S1-D24/AGP3302-B1-D24 units are CE marked, EMC compliant products. These units also conform to EN55011 Class A, EN61000-6-2 directives. For detailed CE marking information, please contact your local AGP distributor.
  • Page 11 Memo...

  • Page 12: Table Of Contents

    Contents Preface ........................1 Essential Safety Precautions..................2 Information Symbols....................6 AGP-3300 Series Model Names ................7 Package Contents ..................... 7 UL/c-UL/CSA Approval....................8 CE Marking........................ 9 Contents ........................11 CHAPTER 1 Introduction 1.1 System Design....................1-2 1.2 Accessories ....................1-9 CHAPTER 2 Specifications 2.1 General Specifications ..................
  • Page 13 3.2.3 Grounding ......................3-11 3.2.4 I/O Signal Line Placement .................. 3-11 3.3 Ethernet Cable Connector ................3-12 3.4 CF Card Insertion and Removal ..............3-13 3.4.1 CF Card Handling ....................3-15 3.5 Attaching the USB Cable Clamp..............3-16 CHAPTER 4 Settings 4.1 Types of Settings ....................

  • Page 14: Chapter 1 Introduction

    Introduction 1. System Design 2. Accessories This chapter describes peripheral devices that can be connected to AGP Series units.
  • Page 15 AGP-3300 Series User Manual 1.1 System Design AGP-3300/3301 Series Units The following diagram illustrates the standard range of items that can be connected to AGP-3300/3301 Series units. For host controller (PLC, etc.) connection information, refer to the “Pro-Designer External Device Drivers”.
  • Page 16 Chapter 1 Introduction Mitsubishi PLC (11) FX-Series Connection Cable CA3-CBLFX/1M-01 CA3-CBLFX/5M-01 (11) Mitsubishi PLC A-Series Connection Cable CA3-CBLA-01 Host Controller PLC etc. RS-422 Cable CA3-CBL422/5M-01 AGP RS-422 Cable CA3-CBL422-01 COM Port (11) Conversion Adapter AGP 2 Port CA3-ADPCOM-01 Adapter Cable Mitsubishi PLC A, QnA, FX Series' 2 Port Adapter II CA3-MDCB11...
  • Page 17 AGP-3300 Series User Manual AGP Edit Mode Peripherals AGP Unit To an Ethernet Network USB Port USB Transfer Cable CA3-USBCB-01 PCMCIA Slot CA3-CFCALL/64MB-01 CF Card CA3-CFCALL/128MB-01 CF Card Adapter CA3-CFCALL/256MB-01 GP077-CFAD10 CA3-CFCALL/512MB-01 Screen Editor Software Pro-Designer Personal Computer (version 4.2...
  • Page 18 Chapter 1 Introduction AGP-3302 Series Units The following diagram illustrates the standard range of items that can be connected to AGP-3302 Series units. For host controller (PLC, etc.) connection information, refer to the “Pro-Designer External Device Drivers”. AGP RUN Mode Peripherals AG P Unit Bar-Code Rea der (Commercial type)
  • Page 19 AGP-3300 Series User Manual Mitsubishi PLC FX -Ser i es Connec tion Cable CA3 -CBL FX/1M-01 CA3 -CBL FX/5M -01 Mitsubishi PLC A-Ser i es Connec tion Cable CA3 -CBLA-01 Host Con t roller PLC et c. RS-422 Cable CA3 -CBL422 / 5M-01...
  • Page 20 Chapter 1 Introduction AGP Edit Mode Peripherals AGP Unit USB Port USB Transfer Cable CA3-USBCB-01 Screen Editor Software Pro-Designer Personal Computer (version 4.2 (Commercial type) or higher) COM Port PC Connection Cable for PS PSP-CB01 AGP Interfaces (1) USB Host (2) Serial Interface (COM1) Must be MS-DOS NECPC-PR201/PL, EPSON ESC/P24-J84(C), HP Laser Jet PCL 4 command printer or its equivalent.
  • Page 21 AGP-3300 Series User Manual Recommended Units The following table lists I/O devices that have been tested and confirmed to be compatible with AGP Series units. If you connect a device that is not listed here, be sure to test that your AGP operates normally prior to using it in your system.

  • Page 22: Accessories

    Chapter 1 Introduction 1.2 Accessories All accessories listed here are produced by Digital Electronics Corporation. Software Product Name Model No. Description Pro-Designer Software used to create AGP unit project PS-DWE01-V42 (version 4.2 or higher) data. Installed in a personal computer. Serial Interface Items Product Name Model No.
  • Page 23 AGP-3300 Series User Manual Connects a host controller to the AGP for GP230-IS12-0 (n:1) communication. Multi-link Cable (5m) (9-pin <-> 25-pin RS422 conversion cable is required.) Connects a host controller to the AGP and RS-232C Isolation Unit CA3-ISO232-01 provides isolation.

  • Page 24: Chapter 2 Specifications

    Specifications 1. General Specifications 2. Functional Specifications 3. Interface Specifications 4. Part Names and Functions 5. Dimensions This chapter describes the general, functional and interface specifications of the AGP as well as its part names and dimensions.

  • Page 25: Electrical

    AGP-3300 Series User Manual 2.1 General Specifications 2.1.1 Electrical AGP-3300/3301 AGP-3302 Series Series Input Voltage DC 24V Rated Voltage DC19.2V to DC28.8V Allowable Voltage Drop 5ms (max.) 10ms (max.) Power Supply Allowable Ripple Ratio 5% (max.) Power Consumption 26W (max.) 18W (max.)

  • Page 26: Structural

    Chapter 2 Specifications 2.1.3 Structural Functional grounding: Grounding resistance of 100 Ω, 2mm Grounding thicker wire, or your country’s applicable standard. (Same for FG and SG terminals) Rating: Equivalent to IP65f NEMA #250 TYPE 4X/12 Structure (Front face of installed unit) Installation Cooling Natural air circulation...

  • Page 27: Functional Specifications

    AGP-3300 Series User Manual 2.2 Functional Specifications 2.2.1 Display AGP-3300S AGP-3300L AGP-3300T AGP-3302B AGP-3301S AGP-3301L Type TFT color LCD STN color LCD monochrome monochrome (B&W) LCD (Blue mode) LCD Resolution W320 x H240pixels Dot Pitch W0.36mm[0.01 in] x H0.36mm[0.01 in] Effective Display Area W115.2mm[4.54 in] x H86.4mm[3.40 in]...

  • Page 28: Memory

    Chapter 2 Specifications 2.2.2 Memory AGP-3300/3301 Series AGP-3302 Series 16MB FLASH EPROM Application 256KB SRAM 128KB SRAM Data Backup Uses a lithium battery The capacity of the implemented memory. A Lithium battery’s lifetime is: 10 years when the battery’s ambient temperature is 40°C or less. 4.1 years when the battery’s ambient temperature is 50°C or less.

  • Page 29: Interfaces

    AGP-3300 Series User Manual 2.2.4 Interfaces AGP-3300 Series COM1: RS-232C/RS-422 Asynchronous transmission Data Length: 7 or 8 bits Parity: none/even/odd Stop Bits: 1 or 2 Transmission Rate: 2400bps to 115200bps Connector: D-sub 9-pin plug Serial Interface COM2: RS-422 (RS-485) Host...
  • Page 30 Chapter 2 Specifications AGP-3302 Series COM1: RS-232C Asynchronous transmission Data Length: 7 or 8 bits Parity: none/even/odd Stop Bits: 1 or 2 Transmission Rate: 2400bps to 115.2Kbps Host Connector: D-sub 9-pin plug Serial Interface Interface COM2: RS-422 Asynchronous transmission Data Length: 7 or 8 bits Parity: none/even/odd Stop Bits: 1 or 2 Transmission Rate: 2400bps to 115.2Kbps...

  • Page 31: Interface Specifications

    AGP-3300 Series User Manual 2.3 Interface Specifications • The AGP unit’s serial port is not isolated. When the host (PLC) unit is also not isolated, be sure to connect the #5 SG (Signal Ground) terminal to reduce the risk of damaging the RS-232C/RS-422 circuit.
  • Page 32 Chapter 2 Specifications AGP Connector: XM2C-0942-502LX <OMRON Co.> Recommended cable Connector: XM2D-0901 <OMRON Co.> Recommended cable Cover: XM2S-0913 <OMRON Co.> Jack Screw: XM2Z-0073 <OMRON Co.> #4-40 inch screws are used. Communication method is switched via software. The RI/VCC selection for Pin #9 is switched via software. The VCC output is not protected against overcurrent.
  • Page 33 AGP-3300 Series User Manual AGP-3302 Series Serial Interface (COM1) This interface is used to connect an RS-232C cable. A D-sub 9-pin plug connector is used. RS-232C Pin # Signal Arrangement Direction Meaning Name Input Carrier Detect RD(RXD) Input Receive Data...
  • Page 34 Chapter 2 Specifications Serial Interface (COM2) This interface is used to connect an RS-422 serial cable. A D-sub 9-pin socket connector is used. RS-422 Pin # Signal Arrangement Direction Meaning Name Input Receive Data A (+) Input Receive Data B (-) Output Send Data A (+) Output...

  • Page 35: Part Names And Functions

    AGP-3300 Series User Manual 2.4 Part Names and Functions The following images are of an AGP-3300 Series unit. A: Display The AGP monitor screen displays the screen setup and corresponding host (PLC) data. B: Touch Panel Performs any screen change operations and sends data to the PLC.
  • Page 36 Chapter 2 Specifications F: Ethernet Interface (10BASE-T/100BASE-TX) The Ethernet transmission interface conforms to IEEE802.3u (10BASE-T/100BASE-TX). An RJ-45 type modular jack connector (8-pole) is used. The LED turns on or off to indicate the current status. The AGP-3301/3302 Series does not include this interface.
  • Page 37 AGP-3300 Series User Manual (AGP-3302 Series units are not equipped with a CF Card socket.) M: Dip Switches Designate the CF Card’s serial settings. Factory set- tings are all OFF. (AGP-3302 Series units have no CF Card socket.) 1 2 3 4...

  • Page 38: Dimensions

    2.5 Dimensions The following dimensions apply to all AGP Series units. (AGP-3300/3301/3302) The dimensions of the AGP-3300, AGP-3301 and AGP-3302 are the same. The following drawings show the AGP-3300. 2.5.1 AGP-3300 Series External Dimensions Unit: mm [in.] 155.5[6.12] 59.5[2.34] 167.5[6.60] 5[0.20]...
  • Page 39 AGP-3300 Series User Manual The following drawing shows the AGP-3300 Series unit with cables. Unit: mm [in.] AGP-3301/3302 Series units are not equipped with an Ethernet interface. 18[0.71] 29[1.14] 25 [0.98] Back Right Left • Depending on the type of connection cable used the dimensions shown above will change.

  • Page 40: Panel Cut Dimensions

    Chapter 2 Specifications 2.5.2 Panel Cut Dimensions Unit: mm [in.] +0.04 [6.14 under 4-R3 2.5.3 Installation Fasteners Unit: mm [in.] 16 [0.63] 16.6 [0.65] 31 [1.22] 2-17...
  • Page 41 AGP-3300 Series User Manual Memo 2-18...

  • Page 42: Installation

    Installation and Wiring 1. Installation 2. Wiring Precautions 3. Ethernet Cable Connector 4. CF Card Insertion and Removal 5. Attaching the USB Cable Clamp...

  • Page 43: Installation Procedures

    AGP-3300 Series User Manual 3.1 Installation 3.1.1 Installation Procedures Follow the steps given below when installing the AGP. Check the Installation Gasket’s Seating It is strongly recommended that you use the installation gasket, since it absorbs vibration in addition to repel- ling water.
  • Page 44 Chapter 3 Installation and Wiring Creating a Panel Cut Create the correct sized opening required to install the AGP, using the installation dimensions given. 2.5.2 Panel Cut Dimensions (page2-17) Panel Panel Cut Area • Check that the installation panel or cabinet’s surface is flat, in good condition and has no jagged edges.
  • Page 45 AGP-3300 Series User Manual • Be sure that the ambient operation temperature and the ambient humidity are within their designated ranges. (Ambient operation temperature: 0 to 50°C, Ambi- ent humidity: 10 to 90%RH, Wet bulb temperature: 39°C max.) When installing the AGP on the panel of a cabinet or enclosure, “Ambient operation temperature”...
  • Page 46 Chapter 3 Installation and Wiring Installing the AGP (1) Insert the AGP into the panel cut, as shown. (2) Insert the installation fasteners into the AGP’s insertion slots, at the top and bot- tom of the unit. (total: 4 slots) •...
  • Page 47 AGP-3300 Series User Manual (4) Use a Phillips screwdriver to tighten each fastener screw and secure the AGP in place. • Tightening the screws with too much force can damage the AGP unit’s plastic case. • • The necessary torque is 0.5 N...

  • Page 48: Wiring Precautions

    Chapter 3 Installation and Wiring 3.2 Wiring Precautions 3.2.1 Connecting the Power Cord To avoid an electric shock, prior to connecting the AGP unit's power cord terminals to the power terminal block, confirm that the AGP unit's power supply is completely turned OFF, via a breaker, or similar unit.
  • Page 49 AGP-3300 Series User Manual Power Plug Specifications Insertion Direction Grounding Terminal connected to the AGP. Left Side Power Connector Power Plug Wiring When connecting the Power Cord, use the following items when performing wiring. (Items are made by Phoenix Contact.) * Recommended Driver SZF 1-0.6x3.5 (1204517)
  • Page 50 Chapter 3 Installation and Wiring Connecting the AGP Power Cord When connecting the power cord, be sure to follow the procedures given below. (1) Confirm that the AGP unit’s Power Cord is unplugged from the power supply. (2) Remove the power plug. (3) Strip the power cord, twist the core wire ends and connect them to the power plug.

  • Page 51: Connecting The Power Supply

    AGP-3300 Series User Manual 3.2.2 Connecting the Power Supply • When supplying power to the AGP unit, please sepa- rate the input/output and operation unit lines, as shown. AGP Unit Main Power AGP Power • To increase the noise resistance quality of the power...

  • Page 52: Grounding

    Chapter 3 Installation and Wiring 3.2.3 Grounding Do not use common grounding, since it can lead to an accident or machine breakdown. (a) Exclusive Grounding (BEST) • When supplying power to the AGP unit, be sure to sep- arate the input/output and power lines, as shown. Other AGP Unit •...

  • Page 53: Ethernet Cable Connector

    AGP3301 Series.) Ethernet Interface (10BASE-T/100BASE-TX) Left Face (AGP-3300 Series unit) • It is strongly recommended that your Ethernet network is installed by a trained engineer. • 1:1 connections using a cross cable may not be possible depending on the type of personal com- puter and network card you are using.

  • Page 54: Cf Card Insertion And Removal

    Chapter 3 Installation and Wiring 3.4 CF Card Insertion and Removal CF Cards can only be used with AGP-3300/3301 Series units. When using the AGP Unit and a CF Card, observe the following precautions: Prior to inserting or removing a CF Card, be sure to turn the AGP unit’s CF Card ACCESS switch OFF and to confirm that the ACCESS lamp is not lit.
  • Page 55 AGP-3300 Series User Manual (2) Insert the CF Card in the CF Card Slot, until the eject button is pushed forward. (3) Close the cover. (As shown.) (4) Confirm that the CF Card Access LED turns ON. • The AGP cannot access the CF Card if the CF Card cover is already opened. If, however, the CF Card Cover is opened while the AGP is accessing the CF Card, access will not be interrupted.

  • Page 56: Cf Card Handling

    Chapter 3 Installation and Wiring 3.4.1 CF Card Handling The CF Card has a data overwrite limit of approximately 100,000 times. Therefore, be sure to back up all CF Card data regularly to another storage media. (100,000 times assumes the overwriting of 500KB of data in DOS format.) Two methods are available for backing up data.

  • Page 57: Attaching The Usb Cable Clamp

    AGP-3300 Series User Manual 3.5 Attaching the USB Cable Clamp Attachment (1) Insert the USB holder into the slot in front of the AGP unit’s USB port and pull it down and forward. (2) Pass the band of the USB cable clamp through the bridge of the USB holder.
  • Page 58 Chapter 3 Installation and Wiring Release Lower the tab and lift the clamp to release the plug Clamp 3-17...
  • Page 59 AGP-3300 Series User Manual Memo 3-18...

  • Page 60: Chapter 4 Settings

    Settings 1. Types of Settings...
  • Page 61 AGP-3300 Series User Manual 4.1 Types of Settings The AGP unit includes the [Settings] menu to specify various items necessary to use the AGP. You can dis- play the [Settings] menu at two times: “When the AGP starts up” or “When Pro-Designer Runtime is acti- vated.”...
  • Page 62 Chapter 4 Settings [Settings] menu The [Settings] menu has two tabs, [Offline] and [System]. Touch the desired tab to bring up those settings. Offline System...

  • Page 63: Offline Settings

    When any [Offline] tab switches are touched, the following dialog will appear. Touching the [OK] key will automatically restart the AGP and the corresponding setting screen will appear. When a selection is set that cannot be used with an AGP-3300 Series unit, the following dialog appears. Network The following information explains how to enter the AGP unit’s network settings.
  • Page 64 Chapter 4 Settings The following buzzer sound settings are available. The factory setting is [When Press Touch Object]. • None Selecting this will turn the buzzer off. • When Press Touch Object The buzzer will only sound when a Touch Object is touched. •...
  • Page 65 (3) To automatically turn the backlight off after a specified period of time, touch the [Wait] selection and set the “idle time” period. Self Test Performs the AGP unit’s self test. For details, see 5.2 SELF TEST. OP. Switch (This setting is disabled with AGP-3300 Series units.)
  • Page 66 Chapter 4 Settings Pro-eView Limits the access to Pro-eView. This setting is disabled with AGP-3301/3302 Series units. The default setting is [Allow access from all IP]. • Only when Pro-Designer is set to [Use Pro-eView] are these settings enabled. For details, refer to [Pro-Designer Online Help].
  • Page 67 AGP-3300 Series User Manual When the [Add] button is touched, the IP address input screen appears. Touch the appropriate fields to display a keypad and enter setting values. Case 1 Case 2 • You can specify either individual IP addresses (Case 1) or a range of IP addresses (Case 2).

  • Page 68: System Settings

    Chapter 4 Settings 4.1.2 System Settings Stylus Calibrates the analog touch panel. Touch center of the cross. Touch center of the cross. Touch center of the cross. Touch center of the cross. Touch center of the cross. Touch center of the cross. •...
  • Page 69 AGP-3300 Series User Manual Setting procedure (1) In the [Settings] menu, touch the [System] tab. (2) Touch the [Stylus] icon. (3) Touch the exact center of each + mark displayed on the screen. Continue touching it until the + mark moves or disappears.

  • Page 70: Language Selection

    Chapter 4 Settings Language Selection Designates the language used with the [System] and [Offline] tabs and User Applications. The System Setting screen's language selection is [0 English] and others. Languages other than English must be first set in Pro-Designer to be displayed as selections in this dialog box. For User Applications, select the default language specified with the Pro-Designer software.
  • Page 71 AGP-3300 Series User Manual Version Information Calls up the Pro-Designer runtime version and the current project’s version and build numbers. Setting procedure (1) In the [Settings] menu, touch the [System] tab. (2) Touch the [Ver. Info] icon. 4-12...
  • Page 72 Chapter 4 Settings Memory Displays the total amount of memory available and the amount of memory currently being used. Setting procedure (1) In the [Settings] menu, touch the [System] tab. (2) Touch the [Memory] icon. Brightness Adjusts the brightness and contrast of the screen. •...
  • Page 73 AGP-3300 Series User Manual Option This setting can only be selected when using a monochrome display (AGP-3300L/3301L/3302B only). Selects whether or not to reverse the black and white areas on the screen. Setting procedure (1) In the [Settings] menu, touch the [System] tab.
  • Page 74 AGP-3300 Series User Manual Memo 4-15...
  • Page 75 AGP-3300 Series User Manual 4-16...

  • Page 76: Chapter 5 Troubleshooting

    Troubleshooting 1. Troubleshooting Checklists 2. SELF TEST This section explains how to find and correct AGP unit problems. The AGP unit can be connected to a wide range of devices, including a host (PLC), however, this manual can not discuss every possible device, or problem. Therefore, regarding problems not directly related to the AGP unit, refer to that device’s manual.
  • Page 77 AGP-3300 Series User Manual 5.1 Troubleshooting Checklists The primary AGP unit problems that occur are: 1) The panel display is blank. 2) Connected devices cannot be used. When a problem occurs, be sure to first read each checklist item and follow the instructions given.

  • Page 78: No Display

    Chapter 5 Troubleshooting 5.1.1 No display Use the flowchart below when the screen does not display when powering up, or if the screen turns OFF by itself during RUN mode. No Screen Display Are all Pro-Designer screens Send the screen data to the AGP unit. sent to the AGP unit? Is the [Initial Panel ID]...
  • Page 79 AGP-3300 Series User Manual The backlight has burned out. Is the Status LED’s orange 6.3 Replacing the backlight (page6-4) light ON? Did the above procedure correct If not, →Hardware problem the problem?

  • Page 80: No Agp/Host Communication

    Chapter 5 Troubleshooting 5.1.2 No AGP/Host Communication When the AGP cannot communicate with the host PLC, follow the flowchart below to find the cause of the problem and the solution. Or, if an error message displays on the screen, check the error code to find the appropriate solution. No PLC communication Turn the power supply OFF.

  • Page 81: Self Test

    AGP-3300 Series User Manual 5.2 SELF TEST The AGP unit is equipped with a number of self diagnosis features that can be used to check its System and Interfaces for possible problems. 5.2.1 SELF TEST item list The SELF TEST items are as follows: •...

  • Page 82: Self Test - Details

    Chapter 5 Troubleshooting 5.2.2 SELF TEST - details This section explains the SELF TEST selections. Char. Pattern Character pattern check of each font (Japanese, Korean, Taiwanese, Chinese and European languages). Checks each language's font image. For Korean, Taiwanese and Chinese, this check is available only for the fonts which the user has downloaded. Disp.
  • Page 83 AGP-3300 Series User Manual AGP-3302 Series Checks the RS-232C and RS-422 SIO lines for communication problems. To perform the check, connecting the SIO cable is necessary. If all is normal, OK displays; if there is a problem, an error message appears.

  • Page 84: Chapter 6 Maintenance

    Maintenance 1. Regular Cleaning 2. Periodic Check Points 3. Replacing the backlight This chapter explains cautions and inspection criteria that will ensure trouble-free use of the AGP.

  • Page 85: Cleaning The Display

    AGP-3300 Series User Manual 6.1 Regular Cleaning 6.1.1 Cleaning the Display When the surface or frame of the display become dirty, soak a soft cloth in water with a neutral detergent, wring the cloth tightly, and wipe the display. • Do not use paint thinner, organic solvents, or a strong acid compound to clean the unit.
  • Page 86 Chapter 6 Maintenance (3) Attach the new gasket to the AGP. Be sure to insert the gasket into the AGP’s groove so that the gasket’s groove sides are vertical. (4) Check that the gasket is attached correctly to the AGP. •...

  • Page 87: Periodic Check Points

    AGP-3300 Series User Manual 6.2 Periodic Check Points To keep your AGP unit in its best condition, please inspect the following points periodically. AGP Operation Environment • Is the operating temperature within the allowable range (0°C to 50°C)? • Is the operating humidity within the specified range (10%RH to 90%RH, dry bulb temperature of 39°C or less)? •...

  • Page 88: Index

    AGP Operation Environment ....... 6-4 Dot Pitch .............. 2-4 AGP RUN Mode Peripherals ......1-2, 1-5 Dust ..............2-2 AGP-3300 Series Model Names ......7 Allowable Ripple Ratio ........2-2 Allowable Voltage Drop ........2-2 Effective Display Area ......... 2-4 Ambient Humidity ..........
  • Page 89 Interface Specifications........2-8 SELF TEST...........5-6, 5-7 Interfaces ............. 2-6 Self Test ...............4-6 Introduction ............1-1 Serial Interface 1-9, 2-6, 2-7, 2-8, 2-9, 2-10, 2-11, 2- Service Life of Backlight ........2-4 Language Fonts........... 2-4 Service Life of Display Element ......2-4 Language Selection ........... 4-11 Settings ............4-1, 4-2 Specifications............2-1 Status LED ............2-12...
