  • Page 1 GP-4100 Series Color Model Installation Guide...

  • Page 2: Table Of Contents

    Please read the “Warning/Caution Information” on the attached sheet before using the product. Safety Information Important Information..................5 Model Numbers Model Numbers....................7 Global Code ..................... 7 Overview Package Contents.................... 8 About the Manual..................... 8 Part Numbers and Functions Part Numbers and Functions ................9 Specifications Electrical Specifications .................
  • Page 3 RTC Battery Set Overview ......................34 Attaching the RTC Battery Set ..............34 Replacing the Battery..................36 Maintenance Cleaning this product ..................37 Standards Standards....................... 38...

  • Page 4: Safety Information

    Safety Information Important Information Notice Read these instructions carefully, and look at the equipment to become familiar with the device before trying to install, operate, or maintain it. The following special messages may appear throughout this documentation or on the equipment to warn of potential hazards or to call attention to information that clarifies or simplifies a procedure.

  • Page 5: Please Note

    PLEASE NOTE Electrical equipment should be installed, operated, serviced, and maintained only by qualified personnel. No responsibility is assumed by Pro-face for any consequences arising out of the use of this material. A qualified person is one who has skills and knowledge related to the construction and operation of electrical equipment and its installation, and has received safety training to recognize and avoid the hazards involved.

  • Page 6: Model Numbers

    *1 Includes models with additional alphanumeric characters at the end of the model number. Global Code A global code is assigned to every Pro-face product as a universal model number. For more information on product models and their matching global codes, please refer to the following URL.

  • Page 7: Overview

    However, should you find anything damaged or missing, please contact your local distributor immediately. About the Manual This manual describes wiring and installation procedures. For more detailed information, refer to the GP-4100 Series Color Model Hardware Manual. You can download the manual from our website at http://www.pro-face.com/trans/en/manual/1001.html.

  • Page 8: Part Numbers And Functions

    Part Numbers and Functions Part Numbers and Functions Ethernet type (Rear view) RS-232C type, RS-422/ 485 type (Rear view) A: Power Connector B: USB (Type A) Interface C: USB (mini-B) Interface D: RTC Battery Set Cover E: Ethernet Interface F: Serial Interface G: DIP Switch (see page 12) Only on RS-422/485 type.

  • Page 9: Specifications

    Specifications Electrical Specifications GP-4114T GP-4115T GP-4116T Rated input 12...24 Vdc voltage Input voltage limits 10.2...28.8 Vdc 12 Vdc: 1 ms or less Voltage drop 24 Vdc: 3 ms or less When power is not supplied to 3.9 W or less 3.4 W or less...

  • Page 10: Interface

    Interface Interface Caution Use only the SELV (Safety Extra-Low Voltage) circuit to connect the COM, USB, and LAN interfaces. DANGER ELECTRIC SHOCK AND FIRE When using the SG terminal to connect an external device to this product: • Verify that a short-circuit loop is not created when you set up the system. •...
  • Page 11 Interface RS-232C and RS-422/485 COM I/F Connector (9-pin, 2-piece terminal block) Cable connection Pin No. RS-232C RS-422/485 side Signal name Signal name CI(RI) CS(CTS) RS(RTS) DR(DSR) ER(DTR) RD(RXD) SD(TXD) NOTE : You can set a termination resistor using the DIP Switch (4-bit) on the rear of the RS-422/485 type.
  • Page 12 Interface Wiring the COM Interface Connector DANGER ELECTRIC SHOCK Always disconnect the connector from this product before wiring the connector. Failure to follow these instructions will result in death or serious injury. Step Action Use a flat-blade screwdriver (Size 0.4 X 2.5) to loosen the terminal screws.
  • Page 13 Interface NOTICE BROKEN ENCLOSURE Do not exert more than 0.196 N•m (1.735 lb-in) of torque when tightening the screws. Failure to follow these instructions can result in equipment damage.

  • Page 14: Installation

    Installation Panel Cutout Dimensions Based on the panel cutout dimensions, open a mount hole on the panel. Panel cutout dimensions for color model 77.5 112.5 1.5...6 mm 2...3 mm (0.06...0.24 in) (0.08...0.12 in) +0.04 (4.43 +0.04 (3.05 When installing to panel cutout for monochrome model (GP-410*) NOTE : The panel cutout adapter (model number: PFXZCFAD31) is required for this type of installation.

  • Page 15: Installation Requirements

    Installation Installation Requirements This product is designed for use on flat surfaces of Type 1, Type 4X (Indoor Use Only), Type 13 Enclosure or IP65F. Be aware of the following when building this product into an end-use product: • The rear face of this product is not approved as an enclosure. When building this product into an end-use product, be sure to use an enclosure that satisfies standards as the end-use product’s overall enclosure.
  • Page 16 Installation Be sure that the surrounding air temperature and the ambient humidity are within their designated ranges. Surrounding air temperature: 0 to 50 °C (32 to 122 °F); ambient humidity: 10 to 90% RH; wet bulb temperature: maximum 39 °C (102 °F) (see page 10). When installing this product in a cabinet or enclosure, the surrounding air temperature is the cabinet’s or enclosure’s internal temperature.
  • Page 17 Installation When installing this product in a slanted position, the product face should not incline more than 30°. When installing this product in a slanted position with an incline more than 30°, the ambient temperature must not exceed 40 °C (104 °F). You may need to use forced air cooling (fan, A/C) to ensure the ambient operating temperature is 40 °C or less (104 °F or less).

  • Page 18: Installation Procedure

    Installation Installation Procedure DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH • Remove all power from the device before removing any covers or elements of the system, and prior to installing or removing any accessories, hardware, or cables. • Unplug the power cable from both this product and the power supply. •...
  • Page 19 Installation Installing to panel cutout for Color Model Step Action Place this product on a clean and level surface with the screen facing down. Check that this product’s gasket is seated securely into the bezel’s groove, which runs around the perimeter of the display panel frame.
  • Page 20 Installation NOTICE BROKEN ENCLOSURE Do not exert more than 0.35 N•m (3.1 lb-in) of torque when tightening the fastener’s screws. Failure to follow these instructions can result in equipment damage. CAUTION RISK OF INJURY Do not drop this product when you remove it from the panel. •...
  • Page 21 Installation Installing to panel cutout for Monochrome Model (GP-410*) Step Action Place this product on a clean and level surface with the screen facing down. Remove the gasket from this product. Attach the panel cutout adapter (model number: PFXZCFAD31) to this product. Check that the panel cutout adapter is seated securely into the bezel’s groove, which runs around the perimeter of the display panel frame.
  • Page 22 Installation From the front of the panel, attach this product to the mount hole for the monochrome model (see page 15). NOTE : This product has two projections on the top to prevent falling during installation. Please insert this product into the panel at an angle to avoid hitting the projections.
  • Page 23 Installation NOTICE BROKEN ENCLOSURE Do not exert more than 0.35 N•m (3.1 lb-in) of torque when tightening the fastener’s screws. Failure to follow these instructions can result in equipment damage.

  • Page 24: Wiring

    Wiring Wiring DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH • Remove all power from the device before removing any covers or elements of the system, and prior to installing or removing any accessories, hardware, or cables. • Remove power before wiring this product’s power terminals. •...
  • Page 25 Wiring DC Power Cord Preparation • Make sure the ground wire is either the same or heavier gauge than the power wires. • Do not use aluminum wires in the power supply’s power cord. • If the ends of the individual wires are not twisted correctly, the wires may create a short circuit.

  • Page 26: Wiring Precautions

    Wiring How to Connect the DC Power Cord Step Action Confirm the power cord is not connected to the power supply. Check the rated voltage, and remove the “DC24V” sticker on the DC power supply connector. Remove the power connector (plug) from this product. Strip the membrane of the power cord, and connect them to the Power Connector.
  • Page 27 Wiring Improving Noise/Surge Resistance • This product’s power supply cord should not be bundled with or kept close to main circuit lines (high voltage, high current), power lines, or input/output lines, and their various systems should be kept separate. When power lines cannot be wired via a separate system, use shielded cables for input/output lines.
  • Page 28 Wiring Grounding • Check that the grounding resistance is 100 Ω or less. • The FG wire should have a cross sectional area greater than 2 mm (AWG . Create the connection point as close to this product as possible, and make the wire as short as possible.

  • Page 29: Connecting To The Usb Interface

    Connecting to the USB Interface Connecting to the USB Interface DANGER POTENTIAL FOR EXPLOSION • Verify that the power, input and output (I/O) wiring are in accordance with Class I, Division 2 wiring methods. • Substitution of any component may impair suitability for Class I, Division 2. •...

  • Page 30: Usb Clamp

    Connecting to the USB Interface USB Clamp When using a USB device, attach a USB clamp to the USB interface to prevent the USB cable from being disconnected. Attaching the USB Holder Step Action Attach the USB holder to the USB (Type A) Interface on this product.
  • Page 31 Connecting to the USB Interface Attach the USB cover to fix the USB cable in place. Insert the USB cover into the USB holder. 1 USB holder 2 USB cable 3 USB cover...
  • Page 32 Connecting to the USB Interface Removing the USB Holder Step Action Push down the tab of the USB cover and then remove the USB cover. 1 USB holder 2 USB cover 3 USB cable Remove the USB cable from the USB (Type A) interface. As shown in the following illustration, insert a screwdriver between this product and the USB holder to pry out the USB holder.

  • Page 33: Rtc Battery Set

    RTC Battery Set Overview RTC Battery Set (model number: PFXZGPRTC1) provides system date and time information and supports related functions requiring a real-time clock. To keep time continuity when power is off, use a non-rechargeable but replaceable battery provided with the RTC Battery Set. Replacing the battery initializes the clock data.
  • Page 34 RTC Battery Set Open the RTC Battery Set Cover on this product using the flat- blade screwdriver: 1 RTC Battery Set Cover Insert the top of the RTC Battery Set first, then press the bottom until it clicks to affix the RTC Battery Set onto this product. 2 RTC Battery Set Reconnect the power supply to this product.

  • Page 35: Replacing The Battery

    RTC Battery Set Replacing the Battery Use only the replacement battery (model number: PFXZGEBT1). DANGER EXPLOSION, FIRE, OR CHEMICAL HAZARD Follow these instructions for the lithium batteries: • Use this product's replacement battery only. • Protect battery from any potential short circuit. •...

  • Page 36: Maintenance

    Maintenance Cleaning this product NOTICE EQUIPMENT DAMAGE • Power off this product before cleaning it. • Do not use hard or pointed objects to operate the touch panel. • Do not use paint thinner, organic solvents, or a strong acid compound to clean the unit.

  • Page 37: Standards Standards

    Standards For information on certifications and standards, such as certified models and certificates, see the product markings or the following URL: http://www.pro-face.com/trans/en/manual/1002.html DANGER POTENTIAL FOR EXPLOSION • Suitable for use in Class I, Division 2, Groups A, B, C, and D Hazardous Locations.
  • Page 38 Inquiry Do you have any questions about difficulties with your unit? Please access our site any time that you need help with a solution. http://www.pro-face.com/trans/en/manual/1001.html Note Please be aware that Digital Electronics Corporation shall not be held liable by the user for any damages, losses, or third party claims arising from the...
