APPENDIX A: HMS-10 ACCESSORIES

The following HMS-10 accessories are available from Meyer Sound.
HMS-10 Accessories
Part Number Accessory
09.183.001.01 MPS-488
09.183.001.02 MPS-488
420.027 MPS-488 Fuse Replacement
484.065 Phoenix 5-pin female cable mount connector
524.014 1502R (regular) bulk cable
524.015 1502P (plenum) bulk cable
NOTE: Belden 1502 is a composite cable comprised of two 18 AWG wires for DC power, two 22 AWG wires
for balanced audio, and one 24 AWG wire for the audio shield. This single cable can deliver both DC power
and balanced audio to loudspeakers at cable runs of up to 150 feet with only 1 dB of loss in peak SPL. Longer cable
runs are possible with heavier gauges for DC power and separate cables for balanced audio. For more information,
see "HMS-10 Current Draw and Cable Requirements" on page 15.
external power supply with U.S. power cord
P
external power supply with CE power cord
P
Notes
Powers up to four HMS-10s; connect only to channel
outputs 1, 3, 5, and 7
Powers up to four HMS-10s; connect only to channel
outputs 1, 3, 5, and 7
2-amp, 250-volt slow-blow fuse (T2A-250V)
Connects to MPS-488 channel output connectors
P
and HMS-10 loudspeaker connectors
500-ft spool, no connectors
500-ft spool, no connectors
