S/N:. WF5510SE02
Service Manual
Auto Washer
Model : DWF-650
DWF-6521P
• Caution:
In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
Nov. 1999
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo DWF-650
Summary of Contents for Daewoo DWF-650
-
Page 1: Service Manual
S/N:. WF5510SE02 Service Manual Auto Washer Model : DWF-650 DWF-6521P • Caution: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). -
Page 2: Table Of Contents
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASH- AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER... -
Page 3: Specifications
1. SPECIFICATIONS DWF-5510 DWF-5511 DWF-5520 DWF-5521 DWF-6010 DWF-6011 DWF-6020 DWF-6021 ITEM 1 POWER SOURCE AVAILABLE IN ALL LOCAL AC VOLTAGE POWER 50Hz 250W CONSUMPTION 60Hz 270W 32.5 32.5 32.5 33.5 MACHINE WEIGHT GROSS 532X855X542 532X920X542 532X887X542 532X952X542 532X855X542 532X920X542 532X887X542 532X952X542 4 DIMENSION (WXHXD) 5 MATERIAL OF INTERNAL TUB... -
Page 4: Functions Of The Control Panel
FUZZY HIGH START LIGHT WASH / HOLD POWER HEAVY RINSE COLD RES. SUIT SPIN è § § Dwf-5520/5521/6020/6021 DAEWOO AUT OMAT IC WASHER FUZZY HIGH START LIGHT WASH / HOLD POWER HEAVY RINSE COLD RES. SUIT SPIN Power Switch POWER •... -
Page 5: Reserved Washing
è § § Reserved Washing 1 Set your program as the above 2 Press reservation button until the 3 Press Start/Hold to start. procedure, remaining last step. digital monitor displays the finish- ing time you want. • Press the course selection button. START •... -
Page 6: How To Install On An Inclined Place
5. DIRECTIONS FOR INSTALLATION AND USE Installing Place Install the washer on a horizon- tal solid floor. If the washer is Never install in these places installed on an unsuitable floor, it could make considerable ¡ The place where it would be noise and vibration. -
Page 7: Feature And Technical Explanation Feature Of The Washing Machine
6. FEATURE AND TECHNICAL EXPLANATION Feature of the Washing Machine 1 The first air bubble washing system in the world. 2 Quiet washing through the innovational low-noise design. 3 The wash effectiveness is much more enhanced because of the air bubble washing system. 4 The laundry detergent dissolves well in water because of the air bubble washing system. -
Page 8: Pulsator System
Pulsator System When the pulsator is rotated C.W or C.C.W at a high speed, it makes the cyclone water flow from the asymmetrically designed pulsator as shown below. Asymmetrically designed pulsator makes the cyclone water flow, which get rid of the washing dead zone to increase the washing effect and reduce the entanglement of laundry. -
Page 9: Softener Dispenser
Softener Dispenser This is the device to dispense the softener automatically by centrifugal force. This is installed inside the auto-balancer. FUNCTIONAL PRINCIPLE 1 Softener stays in room (A) when poured into softener inlet. 2 Softener moves from (A) to (B) by centrifugal force during intermittent spin process. 3 Softener flows from (B) to (C) during rinse process next to intermittent spin. -
Page 10: Automatic Unbalance Adjustment
Automatic Unbalance Adjustment This system is to prevent abnormal vibration during intermittent spin and spin process. FUNCTIONAL PRINCIPLE Contact of safety switch Lid closing 1 When the lid is closed, the safety switch contact is “ON” position. 2 In case that wash loads get uneven during spin, the outer tub hits the safety switch Lid opening due to the serious vibration, and the spin... -
Page 11: Lint Filter
Lint Filter Much lint may be obtained according to the kind of clothes to be washed and some of the lint may also sticks to the clothes. Filter Filter To minimize this possibility a lint filter is provided on the upper part of the tub to filter the wash water as it Bleach Bleach Inlet Inlet... -
Page 12: Gear Mechanism Ass'y
Gear Mechanism Ass’y The proper water currents is made by the rotation of pulsator at a low speed to prevent the damage to the small sized clothes. Pulsator shaft Spin shaft One way clutch bearing Gear unit as Sun gear Planetary gear Internal gear Clutch spring... -
Page 13: Functional Principle Of Bubble Washing Machine
PRINCIPLE OF INTAKE & OUTLET OF THE AIR INTAKE : ARMATURE moves up, and BELLOWS inhales the air. At the same time, protector B is open and A is close. OUTLET : ARMATURE moves down, and BELLOWS exhausts the air. At the same time, protector B is close and A is opend. -
Page 14: Directions For Disassembly And Adjustment
7. DIRECTIONS FOR DISASSEMBLY AND ADJUSTMENT Warning BEFORE ATTEMPTING TO SERVICE OR ADJUST ANY PART OF THE WASHING MACHINE, DISCON- NECT THE POWER CORD FROM THE ELECTRIC OUTLET. Gear Mechanism Ass’y Replacement Raise the top plate on the outer cabinet. Loosen the pulsator mounting screw and remove ¡... -
Page 15: Drain Motor And Valve
Drain Motor and Valve ¡ Lay the front of the washer on the floor. ¡ Separate the drain motor from the bracket. ¡ Loosen the adjustment screw and two bolts ¡ Turn the valve lid by using screw driver as shown mounting the drain motor. -
Page 16: Trouble Shooting Guide
8. TROUBLE SHOOTING GUIDE NOTES 1. When replace the P.C.B. ASS’Y do not scratch the surface of the P.C.B. ASS’Y. 2. Disconnect the power cord from the electric outlet. Concerning Water Supply PROBLEM CHECK POINT CAUSE SOLUTION Do you open the water Open the water tap. -
Page 17: Concerning Washing
PROBLEM CHECK POINT CAUSE SOLUTION Does the water supply The water inlet valve is Change the water inlet continue while the power defective. valve. is turned off? Does the water supply start The triac of P.C.B is Change the P.C.B ASS’Y. as soon as you press the defective. -
Page 18: Concerning Draining
Concerning Draining PROBLEM CHECK POINT CAUSE SOLUTION Install the drain hose Do you install the Improper installation properly. drain hose properly? Is the foreign matter Remove the foreign mat- Malfunction of drainage accumulated inside ter from the pump hous- THE WASHER by the foreign matter the pump housing? DOES NOT... -
Page 19: Concerning Spinning
Concerning Spinning PROBLEM CHECK POINT CAUSE SOLUTION Is the lid open? Close the lid. Safety switch is defec- Change the safety Does the safety switch tive. switch. operate normally? Is the connector of Connect the connector Improper connection of P.C.B ASS‘Y connected properly. -
Page 20: Concerning Operation
Concerning Operation PROBLEM CHECK POINT CAUSE SOLUTION Is the plug connect-ed Connect the plug. to electric outlet? THE INDICA- Is Fuse opended? Change Fuse LAMPS(L.E.D) Is the condition of DO NOT LIGHT Change P.C.B ASS’Y. Power button is defective power button good? UP WHEN THE POWER BUT- TON IS... -
Page 21: Presentation Of The P.c.b Ass'y
9. PRESENTATION OF THE P.C.B ASS’Y Concerning Error Message MESSAGE CAUSE SOLUTION Install drain hose properly. Improper installation of drain hose. Remove foreign matter from drain hose. The drain hose is blocked up by foreign matter. Change drain motor. Drain motor is inferior. Open the water tap. - Page 22 è § § [Pump] WIRING DIAGRAM...
- Page 23 è § § [pump, single valve] WIRING DIAGRAM...
-
Page 25: Parts List
3610602900 3618911700 9.4µF, CAN TYPE AC 220~230V/50HZ 3618911600 8.4µF, CAN TYPE AC 240V/50Hz, AC 220V/60Hz UNIT CAPACITOR AS 33.6µF, CAN TYPE (MEX) AC 110V/60Hz DWF-650 3618912000 30µF, CAN TYPE (MEX) DWF-6521P 3618911900 AC 127V/60Hz 3614201300 SENSER PRESSURE DC 5V CDN-D7... - Page 26 Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) LOC. PART NAME PART CODE SPECIFICATION...
- Page 28 Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) Parts List LOC.
- Page 30 In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) Parts List LOC. PART NAME PART CODE SPECIFICATION REMARK 4SOSE3000- DWF-650 5510,5511,5520,5521 BALANCER AS 3616104700 DWF-6010PN 6010,6011,6020,6021 SPECIAL SCREW 4505E05050 5.2x18...
- Page 32 Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) Parts List LOC.
