Full-Auto Electric Washing Machine
Model : DWF-ELC55BGN / DWF-ELC55GPN
INSTRUCTION MANUAL
Applying One-Touch Operation System.
Realizing calm washing through the innovational low-noise
design.
Before operating this washer, please read this instruction
completely. Thank you.
CONTENTS
PARTS AND FEATURES....................................................................................................................2
WASHER SAFETY .............................................................................................................................3
INSTALLATION INSTRUCTIONS ......................................................................................................4
ELECTRICAL REQUIREMENTS .......................................................................................................5
INLET HOSE CONNECTION .............................................................................................................6
OPERATING YOUR WASHER ...........................................................................................................7
THE FUNCTIONS OF THE CONTROL PANEL .................................................................................8
WASHING PROCEDURE AND COURSE SELECTION ....................................................................9
GENERAL PROCEDURE FOR OPERATION ..................................................................................13
CARING FOR YOUR WASHER .......................................................................................................14
HOW TO CLEAN THE FILTER .........................................................................................................15
REMOVING STAINS ........................................................................................................................16
TROUBLE SHOOTING ....................................................................................................................17
SPECIFICATION ..............................................................................................................................18
A NOTE TO YOU
Thank you for buying a DAEWOO appliance.
DAEWOO washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer property and safely.
Please read it carefully.
DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 1
Page
16. 7. 8. 오후 12:08
Advertisement
Table of Contents
Related Manuals for Daewoo DWF-ELC55BGN
Summary of Contents for Daewoo DWF-ELC55BGN
-
Page 1: Table Of Contents
A NOTE TO YOU Thank you for buying a DAEWOO appliance. DAEWOO washers are easy to use, save time, and help you manage your home better. This manual contains valuable information about how to operate and maintain your washer property and safely. -
Page 2: Parts And Features
• DRAIN HOSE • ADJUSTABLE LEG ACCESSORIES COVER UNDER (OPTION) WATER TAP ADAPTER INLET HOSE DRYTEN DRYTEN DRYTEN DRYTEN DRYTEN DRYTEN HOSE DRAIN (FOR PUMP) HOSE DRAIN CLAMP HOSE DRAIN (FOR NON-PUMP) CONNECTOR INLET DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 2 16. 7. 8. 오후 12:08... -
Page 3: Washer Safety
• Cleaning and user maintenance shall not be made by children without supervision. • Children of less than 3 years should be kept away unless continuously supervised. • No accessing of child to vinyl bags which may cause a suffocation. DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 3 16. 7. 8. 오후 12:08... -
Page 4: Installation Instructions
Drain Outlet Drain hose Drain hose NOTES • Carpet does not obstruct the openings for washing machines with ventilation openings in the base. DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 4 16. 7. 8. 오후 12:08... -
Page 5: Electrical Requirements
(C). If a mating wall receptacle is not available, it is the personal responsibility and obligation of the customer to have the proper earthed wall receptacle installed by a qualified electrician. DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 5 16. 7. 8. 오후 12:08... -
Page 6: Inlet Hose Connection
. Connector inlet Rubber Connector Rubber Packing Connector Packing * Cheek the packing in the inlet Hose Connector Hose Connector DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 6 16. 7. 8. 오후 12:08... -
Page 7: Operating Your Washer
- increase wrinkling and some synthetic knits. These items - create excessive lint should have more room to move in the - wear out items faster (because of pilling) water than heavy items (towels, jeans) DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 7 16. 7. 8. 오후 12:08... -
Page 8: The Functions Of The Control Panel
• Operation and temporary stop is repeated as it is pressed. • When you want change program in operating; press the "START/PAUSE" button → select the program that you want to Start/Pause Temp. Course change → press the "START/PAUSE" button again. DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 8 16. 7. 8. 오후 12:08... -
Page 9: Washing Procedure And Course Selection
• If you want to smart wash, press the program button to adjust to “SMART WASH”. • Procedure to press the button. adjust to Adjust to water level and "WATER water temperature SAVING" Power Power Start/Pause Start/Pause Power Start/Pause Water Temp. Water Temp. Course Course Water Temp. Course DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 9 16. 7. 8. 오후 12:08... - Page 10 • Operation and temporary stop is repeated as it is pressed. • When you want change program in operating; press the "START/PAUSE" button → select the program that you want to change → press the "START/PAUSE" button again. DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 10 16. 7. 8. 오후 12:08...
- Page 11 ( Do not use the chlorine bleach. ) • If you clean the tub once a month, it is possible to keep the tub clean all the time. adjust to Adjust to water level and "TUB CLEAN" water temperature DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 11 16. 7. 8. 오후 12:08...
- Page 12 • If you don t want spin process, you must adjust spin time to 0 min. • Press the Start button. CONVENIENT OPERATION FOR SPIN ONLY • If you want spin only, it is convinient to operate the button as following. DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 12 16. 7. 8. 오후 12:08...
-
Page 13: General Procedure For Operation
• If you open the Door(Lid) When wash and rinse processing, the PULSATOR is not working with "LE" signal on the PCB and Buzzer alarm. • And if close the Door(Lid), the remain process will be done continuously. DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 13 16. 7. 8. 오후 12:08... -
Page 14: Caring For Your Washer
• Unplug the power supply cord or turn off eletrical power to the washer. • Turn off the water supply to the washer . This helps avoid accidental flooding (due to a water pressure surge) while you are away. DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 14 16. 7. 8. 오후 12:08... -
Page 15: How To Clean The Filter
5 Put the filter into the case. 6 Turn the cap clockwise removing the foreign And turn the cap to adjust tightly. stuffs. the prominence of the filter to the hole of the case. STOPPER FILTER CASE STOPPER DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 15 16. 7. 8. 오후 12:08... -
Page 16: Removing Stains
Paint-water based Treat while still wet, rinse in WARM water and wash normally. Scorch marks Dampen a cloth with hydrogen peroxide, lay it over the affected area and press with a fairly hot iron. DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 16 16. 7. 8. 오후 12:08... -
Page 17: Trouble Shooting
• The sound "wing" heard during water supply is the operating sound made by the water inlet valve. • The sound "sha" heard in stopping the tub is the sound that comes from the autobalancer of the tub. DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 17 16. 7. 8. 오후 12:08... -
Page 18: Specification
SPECIFICATION MODEL NO. DWF-ELC55BGN / DWF-ELC55GPN Dimension (WxHxD, mm) 525 x 948 x 535 Unit Weight 26Kg Standard Water Consumption 130ℓ Standard Water Level • HIGH (58ℓ) • MED (44ℓ) • LOW (31ℓ) Operating Water Pressure 29kPa ~ 784kPa (0.3kgf/cm² ~ 8kgf/cm²) DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 18... -
Page 19: About This Manual
언 어 영어 F. MODEL ELC 사용설명서 B. MODEL DWF-ELC55BGN / DWF-ELC55GPN B U Y E R 호주향 M E M O 총 18p (192 x 260) 16.07.07-표지, 7p, 8p, 9p, 10p, 11p, 13p, 18p _ 8p 16.07.08-10p, 11p, 12p _ 3p NO NEED PRINT DWF-ELC55BGN,DWF-ELC55GPN(영)_호주향.indd 19...
