Preparing the pushchair for use and instructions for use

The illustration numbers correspond to the text
(see illustrations on pages 3 to 5).
Please note: The left and right sides are as seen from the
handlebar/back of the Quinny Zapp.
Start:
Mounting the wheels onto the frame
(1) Insert the rear wheel with axle into the Quinny Zapp
frame until you hear a 'click'.
(2) Slide the double front wheel onto the front axle of
the Quinny Zapp frame until you hear a 'click'.
Unfolding the frame
(3) Gently lift the Quinny Zapp by the adapter
attachments. The frame will unfold itself.
(4) Pull the coupling outwards until you hear a 'click'.
(5) Press release button 1. The button will stay pressed by
itself.
(6) Press release button 2, whilst at the same time raising
the upper section of the Quinny Zapp. Release button
2 and lift up further until you hear a 'click'.
(7) Extend the upper lock into the horizontal position.
The Quinny Zapp is now ready for use.
Parking brake
Always use the parking brake, even when standing still for
only a few moments!
(8) Push down on the red button (P) to set the parking
brake. Push down on the other pedal to release the
brake.
Maxi-Cosi:
Using with a Maxi-Cosi child car seat
Maxi-Cosi infant carriers are suitable for children from birth
to 12 months and weighing up to 13 kg (as indicated on the
Maxi-Cosi child car seat).
Installing the adapters
(9) Slide off the covers of the adapter attachments and
store them carefully in the storage compartment in
the Quinny Zapp carrying bag.
(10) Slide the adapters into the adapter attachments until
you hear a 'click'.
Installing the Maxi-Cosi child car seat
(11) Place the child car seat onto the adapters with the
head end at the front until you hear a 'click'. Check to
make sure everything is attached securely.
Removing the Maxi-Cosi child car seat
(12) Press the control buttons on both sides while at the
same time lifting the car seat from the Quinny Zapp.
Removing the adapters
(13) Press the button and slide the adapters out of the
adapter attachments.
(14) Slide the covers back onto the adapter attachments.
Quinny Zapp pushchair seat:
Using as a pushchair
The Quinny Zapp seat is suitable for children ages 6 months
to 4 years (maximum of 18 kg). The Quinny Zapp seat can
be used as soon as your child is able to sit up unassisted.
10

Preparing the Quinny Zapp seat for use

(15) Fasten the cover to the foot end of the seat.
(16) Place the Quinny Zapp in a half-open position and tilt
the frame until it is resting on the rear wheels and
adapter attachments.
(17) The ends of the cover have markings that correspond
to the markings at the end of the cover grooves.
(18) First slide each end piece into the corresponding
groove and then pull the cover into place.
(19) Slide the cover stops into the cover grooves.
(20) Fasten the hooks to the tubes and unfold the Quinny
Zapp completely.
Using the Quinny Zapp:
Hood
(21) Slide off the covers of the adapter attachments and
store them carefully.
(22) Slide both ends of the hood into the adapter
attachments until you hear a 'click'.
(23) Fasten the hood to the top of the Quinny Zapp using
the snaps and Velcro. Check to make sure the hood is
fastened securely.
(24) The hood can be adjusted to two different positions:
folded out or folded back. Note: The Quinny Zapp
can be folded without removing the hood. To remove
the hood, unfasten the snaps and Velcro and pull the
hood out of the adapter attachments. Slide the covers
back onto the adapter attachments.
GB <<

Placing your child in the Quinny Zapp

Set the brake on the Quinny Zapp before placing your child
in it. Make sure the safety harness is unhooked before
placing your child in the pushchair seat.
(25) Slide the buckle sections together. Fasten the lap and
shoulder belts to the crotch strap by 'clicking' the
buckle sections into the buckle.
(26) Adjust the belts to the size of your child by
lengthening or shortening them using the clasps.
(27) Push both buttons to open the belt buckle. There are
D-rings for attaching an additional safety harness.
Make sure it complies with all safety standards
(i.e. BS EN 13210:2004) before using it.
(28) Important! The fasteners on the side of the safety
harnesses are for attaching the footmuff only.
Locking the swivel wheel
It is advisable to lock the swivel wheel into a fixed position
when using the pushchair in a straight direction for a
longer period.
(29) Push the swivel wheel lock downwards and turn the
front wheel into the backward position until you hear
a 'click'. The front wheel is now locked into the fixed
position. To unlock the swivel wheel, push the swivel
wheel lock upwards.
