• NEVER allow children to climb into the stroller unassisted. Stroller may tip over and injure child. • NEVER place or hang parcels, bags or accessories on the handle or canopy. The stroller may tip over or the canopy may collapse.
• Do not return this product to the place of purchase. If any parts are missing, call Consumer Relations at (800) 951-4113. Or visit our website at www.quinny.com. • Include the model number and manufacture date (found on the back of the stroller) and a brief description of the part.
“click” (Figure 2). Repeat for other front wheel. Pull to confirm it is assembled securely. Unfold Stroller Gently lift the stroller by the hinge points. The frame will start to unfold itself (Figure 3). Pull the coupling (labeled 3) outward until you hear a “click”...
Page 6
(Figure 6a). Fasten the canopy to the top of the stroller using the snaps and adhesive patches (Figure 6b). Check to make sure the canopy is fastened securely. The canopy can be adjusted...
Swivel Wheel TIP: Lock the swivel wheel when using the stroller in a straight direction for a long period. To lock, push the swivel wheel lock downward and turn the front wheel into the backward position until you hear a “click”...
Page 8
To avoid serious injury: • Use ONLY Mico infant car seat (not included) with this stroller (model 01474). • Please refer to the manufacturer’s instructions for the use of your infant car seat. • ALWAYS install car seat facing to the rear of the stroller.
Page 9
WARNING • For proper installation of the restraint system, make sure both anchors lay flat against the back board. • NEVER use stroller without BOTH restraint and crotch straps. Anchors To Use...
Page 10
(Figure 13b). Ensure that the handle crossbar is folded inward (Figure 13c). Hold onto the stroller by the hinge points and push release pedal down, and push coupling (labeled 3) forward (Figure 13d).
• Shopping basket • To order parts call (800) 951-4113. • Include the model number and manufacture date (found on the stroller) and a brief description of the part. One-Year Limited Warranty Dorel Juvenile Group, Inc. warrants to the original purchaser that this product (Zapp manship defects when used under normal conditions for a period of one (1) year from the date of purchase.
Page 12
Contenido Advertencias Lista de piezas Armado Cómo utilizar Cuidado y mantenimiento Piezas reemplazables Garantía 12-14 15-18...
ADVERTENCIA POR LA SEGURIDAD DE SU HIJO, POR FAVOR LEA LAS SIGUIENTES ADVERTENCIAS E INSTRUCCIONES DE ENSAMBLE, Y GUÁRDELAS PARA CONSULTA FUTURA . • El armado debe ser realizado por un adulto. PRECAUCIÓN: Durante el armado, mantenga las piezas pequeñas fuera del alcance de los niños. •...
Si faltan piezas, llame al Departamento de Relaciones con el Consumidor, (800) 951-4113, o visite nuestro sitio web www.quinny.com. • Incluya el número de modelo y la fecha de fabricación, que se encuentran en la parte posterior de la carriola, así...
NOTA: Si las ruedas rechinan, rocíe los ejes con lubricante. Instalación de las ruedas traseras Inserte el eje de una rueda trasera en el armazón hasta oír un “clic” (Figura 1). Repita el proceso con la otra rueda trasera. Tire de ellas para verificar que estén armadas firmemente.
Page 16
Armado Freno de estacionamiento Utilice siempre el freno de estacionamiento, ¡incluso cuando la carriola esté detenida tan solo por unos minutos! Para aplicar el freno de estacionamiento, empuje hacia abajo el pedal rojo (P) ubicado detrás de la rueda trasera (Figura 4). Presione el pedal opuesto para quitar el freno de estacionamiento.
Rueda oscilante CONSEJO: Trabe la rueda oscilante cuando utilice la carriola en una dirección recta durante un período prolongado. Para trabarla, empuje la traba hacia abajo y gire la rueda delantera en la posición orientada hacia atrás hasta oír un “clic”...
Page 18
Cómo utilizar ADVERTENCIA Para evitar lesiones graves: • Utilice ÚNICAMENTE el autoasiento Mico™ (no incluido) para esta carriola (modelo 01474). • Consulte las instrucciones del fabricante para el uso del autoasiento de bebé. • SIEMPRE instale el autoasiento mirando hacia atrás de la carriola.
Page 19
ADVERTENCIA • NUNCA DEJE AL NIÑO SIN SUPERVISIÓN. • EVITE UNA LESIÓN GRAVE por caída o resbalamiento. Siempre use el cinturón de seguridad. Revise con frecuencia para asegurarse que esté asegurado. Los cinturones deben pasarse exactamente como se muestra (Figura 11b). •...
Page 20
Cómo utilizar Cómo plegar el carriola NOTA: No es necesario retirar la capota antes de plegar la carriola. Cierre la capota (Figura 13). Párese detrás de la carriola y presione el botón de liberación 1 (Figura 13a). El botón se mantendrá presionado.
Cuidado y mantenimiento • Limpie las manchas del acojinado con agua fría y jabón suave. Deje secar al aire. • De vez en cuando revise que no haya tornillos flojos, piezas desgastadas, material rasgado ni costuras sueltas. Apriete ocambie las piezas según sea necesario. Piezas de repuesto •...
