The Internet Indicators
Internet Green. The Internet LED lights up when a successful con-
nection is made between the Router and your cable or DSL
modem or WAN.
Diag Red. The Diag LED lights up when the Router goes through
its self-diagnosis mode during every boot-up. It will turn off
upon successful completion of the diagnosis.
If this LED stays on for one minute or longer, see "Appendix
A: Troubleshooting."
Proceed to "Chapter 3: Connect the Router."
8
Network Everywhere Series
™
Cable/DSL 4-Port Router

Chapter 3: Connect the Router

Overview

Unlike a hub or a switch, the Router's setup consists of more than simply plug-
ging hardware together. You will have to configure your networked PCs to
accept the IP addresses that the Router assigns them (if applicable), and you
will also have to configure the Router with setting(s) provided by your Internet
Service Provider (ISP).
The installation technician from your ISP should have left the setup informa-
tion for your modem with you after installing your broadband connection. If
not, you can call your ISP to request the data.
Once you have the setup information you need for your specific type of Internet
connection, you can begin installation and setup of the Router.
Figure 3-1
Note: You have two methods of installing the Router: using the Setup
Wizard or using the manual installation instructions. Network
Everywhere recommends you run the Setup Wizard on the Setup
Wizard CD-ROM. Insert the Setup Wizard CD-ROM into your PC's
CD-ROM drive. The Setup Wizard will run automatically. Then follow
the Setup Wizard's instructions to install the Router.
If you prefer to manually install the Router, then proceed to the next
section of the User Guide.
