Icom IC-M504 Service Manual page 25

• HM-126B/G
[CHASSIS PARTS]
REF. ORDER
DESCRIPTION
NO. NO.
W1 8900014820 Cable OPC-948 [Gray]
8900013590 Cable OPC-949 [Black]
MP1 8210022750 2352 front panel-1 [Gray]
8210021410 2352 front panel (A)-1 [Black]
MP2 8210020380 2352 rear panel [Gray]
8210020120 2352 rear panel (A) [Black]
MP3 8930052160 2352 key
MP4 8930052150 2352 PTT rubber
MP5 8930052140 2352 PTT holder
MP6 8930052690 2352 MIC rubber
MP7 8930052120 2352 rubber
MP8 8930052110 2352 main seal
MP9 8610010870 2352 hanger knob
MP10 8310048760 2352 R-plate
MP11 8310048780 2352 mic plate
MP12 8820001150 2352 screw
MP13 8850001850 ICOM washer (Y)
MP14 8930052340 O ring (AE)
MP15 8930052350 O ring (AF)
MP16 8930053870 2352 sheet (A)
MP17 8930053040 2352 SP net
MP18 8850001610 Spring washer M4 SUS
Screw PH BT 2 × 6 NI
MP19 8810009260
Screw PH M3 × 6 NI
MP20 8810008900
Screw BiH M4 × 10 ZK
MP21 8810009240
MP24 8930061010 2715 mic sheet
MP8 (C)
SP1 (M)
MP17 (C)
MP6 (C)
MP24 (C)
MP3 (C)
MP1 (C)
MP11 (C)
[MAIN UNIT]
REF. ORDER
QTY. DESCRIPTION
NO. NO.
1 MC1 7700002120 Microphone KUC2123-030245
1
SP1 2510001080 Speaker S36G04K-9
1
1
1 Screw abbreviations BT: Self-tapping
1
PH: Pan head
1
ZK: Black
1
NI: Nickel
1
1
1
1
1
1
1
5
5
5
1
1
1
1
3
1
1
1
MP9 (C)
MP19 (C) MP15 (C)
MAIN UNIT
MC1 (M)
MP16 (C)
MP18 (C)
MP21 (C)
MP12 (C)
MP13 (C)
MP14 (C)
MP2 (C)
MP10 (C)
MP4 (C)
MP20 (C)
MP5 (C)
MP7 (C)
W1 (C)
Unit abbreviations (C) : CHASSIS PARTS
(M) : MAIN UNIT
7 - 3
SECTION 8
• TRANSISTORS AND FET's
2SA1576A T106 R
(Symbol: FR)
QTY.
1 B
C
1
E
2SK1069 4 TL
BiH: Binding head
(Symbol: FJ)
SUS: Stainless
S
G
D
KRC404 (Symbol: ND)
KTC2875-B (Symbol: MB)
KTC3880S (Symbol: HG)
B
C
E
• DIODES
1SS372
(Symbol: N9)
HVC350B
(Symbol: B0)
A C
L308CCB
(Symbol: CC)
SEMICONDUCTOR INFORMATION
2SB1143 S 2SB1201 S 2SC4081 T106 S
(Symbol: B1143) (Symbol: B1201) (Symbol: BS)
E
E
B
B
C
C
C
B B
C
E
E
3SK292 FMW1 T148 KRA304 (Symbol: PD)
KTA2015Y (Symbol: ZY)
(Symbol: UK) (Symbol: W1)
B1 C1
D G2
E
S G1 B2
C2
KTC4075 BL (Symbol: LBL) PMBFJ310 TPC6104
KTC4080 (Symbol: HH)
(Symbol: M10) (Symbol: S3D)
B S
G
C
E
D
AVR-M1005C080MTABB DSA3A1 HSB88WSTR
(Color: Green) (Symbol: Silver line)
green
HVC358B KDS122 KDS4148U
(Symbol: B2) (Symbol: C3) (Symbol: UH)
A C
MA77 MA8036 L MA8062 M
(Symbol: 4B) (Symbol: 3_6) (Symbol: 6-2)
A C
A C
8 - 1
2SC4226 T1 R25
(Symbol: R25)
B B
C C
E E
KRC402
(Symbol: NB)
B
B
C
C
E
E
XP6501 AB
(Symbol: 5N)
D D
C1
E1
D D B1
E2
B2 C2
G S
HSM88ASR TR
(Symbol: C3)
KDV214E
(Symbol: UO)
A C
A C
A C
