Icom IC-M504 Service Manual page 17

SECTION 6
• IC-M504
[REPLACEMENT UNITS]
ORDER NO.
0329140101 U M504 #01 FRONT
0329140301 U M504 #03 FRONT
[LOGIC BOARD]
REF ORDER
NO. NO.
IC2 1110006380 S.IC LM2904PWR
IC3 1140008650 S.IC HN58X2464TI
IC4 1110005771 S.IC S-80942CNMC-G9CT2G
IC6 1170000352 S.IC PC357N6J000F
IC8 1180000421 S.IC TA78L05F (TE12R F)
IC9 1130013100 S.IC KIC7W14FK RTK/P
IC10 1130013200 S.IC TC74LCXR164245 (E F)
IC11 1180002380 S.IC S-817B33AMC-CWW-T2G
Q1 1520000651 S.TR 2SB1201S-TL-E
Q2 1530003900 S.TR KTC4075 BL-RTK/P
Q3 1530003900 S.TR KTC4075 BL-RTK/P
Q4 1530003960 S.TR KTC2875-B-RTK/P
Q5 1530002280 S.TR 2SC4081 T106 S
Q6 1590003580 S.TR KRC404 RTK/P
Q7 1530002280 S.TR 2SC4081 T106 S
Q8 1510000510 S.TR 2SA1576A T106R
Q9 1560000810 S.FET 2SK1069-4-TL
D1 1790001561 S.DIO 1SS372 (TE85R F)
D2 1750001320 S.DIO KDS4148U RTK/P
D3 1750001180 S.DIO KDS122 RTK/P
D4 1730002360 S.ZEN MA8062-M (TX)
D5 1750001180 S.DIO KDS122 RTK/P
D43 1790001810 S.VSR AVR-M1005C080MTABB
X1 6050012041 S.XTL CR-790A (9.8304 MHz)
R2 7030003560 S.RES ERJ3GEYJ 103 V (10 k
R7 7030003640 S.RES ERJ3GEYJ 473 V (47 k
R22 7030003680 S.RES ERJ3GEYJ 104 V (100 k
R23 7030003800 S.RES ERJ3GEYJ 105 V (1 M
R24 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
R25 7030003560 S.RES ERJ3GEYJ 103 V (10 k
R26 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
R31 7030003560 S.RES ERJ3GEYJ 103 V (10 k
R32 7030003560 S.RES ERJ3GEYJ 103 V (10 k
R33 7030003560 S.RES ERJ3GEYJ 103 V (10 k
R34 7030003560 S.RES ERJ3GEYJ 103 V (10 k
R35 7030003560 S.RES ERJ3GEYJ 103 V (10 k
R36 7030003650 S.RES ERJ3GEYJ 563 V (56 k
R37 7030008051 S.RES ERA3YKD 184V (180 k
R38 7030003320 S.RES ERJ3GEYJ 101 V (100)
R41 7030003680 S.RES ERJ3GEYJ 104 V (100 k
R43 7030003570 S.RES ERJ3GEYJ 123 V (12 k
R44 7030003640 S.RES ERJ3GEYJ 473 V (47 k
R45 7030003640 S.RES ERJ3GEYJ 473 V (47 k
R46 7030003320 S.RES ERJ3GEYJ 101 V (100)
R48 7030003640 S.RES ERJ3GEYJ 473 V (47 k
R49 7030003640 S.RES ERJ3GEYJ 473 V (47 k
R51 7030006060 S.RES ERJ12YJ100U (10)
R54 7030004120 S.RES ERJ3GEYJ 203 V (20 k
R55 7030003560 S.RES ERJ3GEYJ 103 V (10 k
R56 7030003590 S.RES ERJ3GEYJ 183 V (18 k
R57 7030003560 S.RES ERJ3GEYJ 103 V (10 k
R58 7030004120 S.RES ERJ3GEYJ 203 V (20 k
R59 7030003560 S.RES ERJ3GEYJ 103 V (10 k
R60 7030003590 S.RES ERJ3GEYJ 183 V (18 k
R61 7030003560 S.RES ERJ3GEYJ 103 V (10 k
R62 7030003630 S.RES ERJ3GEYJ 393 V (39 k
R63 7030003660 S.RES ERJ3GEYJ 683 V (68 k
R64 7030003440 S.RES ERJ3GEYJ 102 V (1 k
R65 7030003560 S.RES ERJ3GEYJ 103 V (10 k
R66 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
R71 7030003370 S.RES ERJ3GEYJ 271 V (270)
R72 7030003370 S.RES ERJ3GEYJ 271 V (270)
R74 7030003320 S.RES ERJ3GEYJ 101 V (100)
R75 7030003320 S.RES ERJ3GEYJ 101 V (100)
R76 7030003320 S.RES ERJ3GEYJ 101 V (100)
PARTS LIST
UNIT NAME COLOR
(including HM-126B-3 ACC)
(including HM-126G ACC)
DESCRIPTION M.
LOCATION
B 72.9/41.6
B 120.3/30.8
B 134.9/61.9
B 59.5/47.6
B 132/25.3
B 62.4/40.4
B 89.3/53.7
B 107/76.3
B 137.5/69.5
B 128.7/67.8
B 129.3/70.9
B 123.1/36
B 62.5/52.6
B 63.1/48.5
B
B 62.8/32.5
B 62.8/35.6
B 125.9/35.1
B 59.5/52.6
B 61.8/55.4
B 65.1/57.6
B 129.2/35.1
B 126.2/17
B 116.5/64.3
B 101/39.3
B 139.3/48.7
B 72.8/44.3
B 72.8/38.9
B 77.7/40.4
B
B 68.3/41.2
B 119.8/36.9
B 120.3/35.6
B 128.4/18.8
B 129.2/17
B 143.5/17.1
B 100.1/59.4
B 100.8/61.4
B 127.7/17
B 102.8/29
B 137.1/58.2
B 137.1/59.4
B 134.4/58.2
B 115.7/59.9
B 139.3/51.3
B 139.3/52.6
B 135.3/75.2
B 98.8/70.6
B 100/70.6
B 101.2/70.6
B 102.4/70.6
B 103.6/70.6
B 104.8/70.6
B 106/70.6
B 107.2/70.6
B 97.6/70.6
B 127.4/70.8
B 130.6/67.5
B 131.9/70.3
B 131.9/67.5
B 49.4/15.9
B 134.2/17.5
B 90.7/26.9
B
B
[LOGIC BOARD]
REF ORDER
NO. NO.
R77 7030003320 S.RES ERJ3GEYJ 101 V (100)
R79 7030003680 S.RES ERJ3GEYJ 104 V (100 k
BLACK
R80 7030003680 S.RES ERJ3GEYJ 104 V (100 k
GRAY
R81 7030003680 S.RES ERJ3GEYJ 104 V (100 k
R82 7030003440 S.RES ERJ3GEYJ 102 V (1 k
R83 7030003580 S.RES ERJ3GEYJ 153 V (15 k
R84 7030003440 S.RES ERJ3GEYJ 102 V (1 k
H/V R85 7030003680 S.RES ERJ3GEYJ 104 V (100 k
R86 7030003210 S.RES ERJ3GEYJ 120 V (12)
R87 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
R88 7030003680 S.RES ERJ3GEYJ 104 V (100 k
R89 7030003640 S.RES ERJ3GEYJ 473 V (47 k
R91 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
R92 7030003280 S.RES ERJ3GEYJ 470 V (47)
R93 7030003430 S.RES ERJ3GEYJ 821 V (820)
R94 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
R95 7030003440 S.RES ERJ3GEYJ 102 V (1 k
R96 7030003640 S.RES ERJ3GEYJ 473 V (47 k
R97 7030003440 S.RES ERJ3GEYJ 102 V (1 k
R98 7030003440 S.RES ERJ3GEYJ 102 V (1 k
R102 7030003860 S.RES ERJ3GE JPW V
R119 7030003680 S.RES ERJ3GEYJ 104 V (100 k
R120 7030003680 S.RES ERJ3GEYJ 104 V (100 k
R121 7030003680 S.RES ERJ3GEYJ 104 V (100 k
R122 7030003680 S.RES ERJ3GEYJ 104 V (100 k
R123 7030003680 S.RES ERJ3GEYJ 104 V (100 k
60/32.8
R126 7030003680 S.RES ERJ3GEYJ 104 V (100 k
R127 7030003680 S.RES ERJ3GEYJ 104 V (100 k
C1 4510008540 S.ELE EEE1CA100SR
C2 4030016930 S.CER ECJ0EB1A104K
C5 4030017460 S.CER ECJ0EB1E102K
C6 4030017730 S.CER ECJ0EB1E471K
C15 4030016790 S.CER ECJ0EB1C103K
C16 4030016790 S.CER ECJ0EB1C103K
C21 4030011600 S.CER C1608 JB 1E 104K-T
C31 4030016790 S.CER ECJ0EB1C103K
C32 4030016930 S.CER ECJ0EB1A104K
C33 4030016930 S.CER ECJ0EB1A104K
C35 4030016790 S.CER ECJ0EB1C103K
C36 4030016790 S.CER ECJ0EB1C103K
C37 4030016790 S.CER ECJ0EB1C103K
C38 4030016790 S.CER ECJ0EB1C103K
C39 4030016790 S.CER ECJ0EB1C103K
C40 4030016790 S.CER ECJ0EB1C103K
C41 4030017480 S.CER C1608 JB 1A 474K-T
68.3/44
C42 4030017480 S.CER C1608 JB 1A 474K-T
C44 4030017030 S.CER ECJ0EB1A273K
C45 4030017400 S.CER ECJ0EC1H220J
C46 4030017400 S.CER ECJ0EC1H220J
C52 4030017460 S.CER ECJ0EB1E102K
C81 4030017920 S.CER ECJ0EB1A683K
C82 4030016790 S.CER ECJ0EB1C103K
C83 4030016930 S.CER ECJ0EB1A104K
C86 4030016930 S.CER ECJ0EB1A104K
C87 4030017460 S.CER ECJ0EB1E102K
C88 4030017460 S.CER ECJ0EB1E102K
C89 4030017460 S.CER ECJ0EB1E102K
C90 4030017460 S.CER ECJ0EB1E102K
C91 4550007750 S.TAN TEESVA 1V 225M8R
C92 4550007750 S.TAN TEESVA 1V 225M8R
C93 4550007750 S.TAN TEESVA 1V 225M8R
C94 4550007750 S.TAN TEESVA 1V 225M8R
C95 4550007650 S.TAN F931V105MAABMA
C96 4550007650 S.TAN F931V105MAABMA
C97 4550007650 S.TAN F931V105MAABMA
C98 4550007650 S.TAN F931V105MAABMA
C99 4550007650 S.TAN F931V105MAABMA
C101 4030017460 S.CER ECJ0EB1E102K
C102 4510008540 S.ELE EEE1CA100SR
C104 4030017460 S.CER ECJ0EB1E102K
C105 4030017460 S.CER ECJ0EB1E102K
C106 4030016790 S.CER ECJ0EB1C103K
C107 4030016790 S.CER ECJ0EB1C103K
C108 4030016790 S.CER ECJ0EB1C103K
C109 4510008540 S.ELE EEE1CA100SR
C111 4030016930 S.CER ECJ0EB1A104K
C141 4030016930 S.CER ECJ0EB1A104K
C142 4030016930 S.CER ECJ0EB1A104K
C334 4030017420 S.CER ECJ0EC1H470J
54.7/23
C336 4030017420 S.CER ECJ0EC1H470J
74/74.3
C337 4030017460 S.CER ECJ0EB1E102K
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
