Icom IC-R5 Service Manual page 24

[LOGIC UNIT]
REF ORDER
NO. NO.
J2 6450002010 S.CONNECTOR HSJ1501-011010
J3 6510020560 S.CONNECTOR AXK5S40340P
J500 6450002130 CONNECTOR
DS1 5030001990 LCD
S6 2250000390 ENCODER
S9 2230001070 S.SWITCH
S10 2230001070 S.SWITCH
W2 7030010040 S.JUMPER
W3 7030010040 S.JUMPER
W4 7030010040 S.JUMPER
W5 7030010040 S.JUMPER
W7 7030010040 S.JUMPER
W14 7030010040 S.JUMPER
W16 7030003860 S.JUMPER
W17 7030010040 S.JUMPER
W200 7030010040 S.JUMPER
W600 9026050001 WIRE
EP1 6910012350 S.BEAD
EP2 6910012350 S.BEAD
EP3 6910014600 E.OTHER
EP4 8930058920 LCD CONTACT SRCN-2605-SP-N-W
EP5 0910055724 PCB
EP9 6910013310 S.BEAD
EP10 6910014680 S.BEAD
EP11 6910014680 S.BEAD
EP12 6910014690 S.BEAD
EP13 6910014690 S.BEAD
[RF UNIT]
REF ORDER
NO. NO.
IC1 1110005230 S.IC
IC2 1110003200 S.IC
IC3 1130007610 S.IC
IC4 1110005180 S.IC
IC10 1110005230 S.IC
IC11 1110005180 S.IC
Q1 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q2 1560000540 S.FET
Q4 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q5 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q6 1530003610 S.TRANSISTOR FH102-TL
Q14 1530003610 S.TRANSISTOR FH102-TL
Q24 1530003590 S.TRANSISTOR 2SC5277D2-TL
Q26 1530003590 S.TRANSISTOR 2SC5277D2-TL
Q28 1530003260 S.TRANSISTOR 2SC5006-T1
Q29 1590001940 S.TRANSISTOR DTC144EE TL
Q30 1530003260 S.TRANSISTOR 2SC5006-T1
Q31 1530003610 S.TRANSISTOR FH102-TL
Q33 1590001810 S.TRANSISTOR XP1113 (TX)
Q35 1590002650 S.TRANSISTOR UPA805T-T1
Q36 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q37 1530003630 S.TRANSISTOR 2SC4617 TLS
Q40 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q41 1590002430 S.TRANSISTOR DTA144EE TL
Q43 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q44 1590001660 S.TRANSISTOR XP4312 (TX)
Q45 1530003010 S.TRANSISTOR 2SC4117-GR (TE85R)
Q46 1590001660 S.TRANSISTOR XP4312 (TX)
Q501 1590002430 S.TRANSISTOR DTA144EE TL
Q502 1590001810 S.TRANSISTOR XP1113 (TX)
Q503 1590001810 S.TRANSISTOR XP1113 (TX)
Q504 1590001810 S.TRANSISTOR XP1113 (TX)
Q505 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
DESCRIPTION
04-730A1-02BKA
TTR5169 UPFDHW
TP90N00E20-16F-1995
JPM1990-2711R
JPM1990-2711R
ERJ2GE-JPW [EUR], [FRA] only
ERJ2GE-JPW [USA], [UK] only
ERJ2GE-JPW
[USA], [FRA], [ESP] only
ERJ2GE-JPW
except [EUR], [UK], [USA]
ERJ2GE-JPW [FRA] only
ERJ2GE-JPW
ERJ3GE JPW V
ERJ2GE-JPW
ERJ2GE-JPW
71/98/036/X98/X98
MMZ1608Y 102BT
MMZ1608Y 102BT
CV1071 RX2605
B 5887D
MMZ1608D121B
MMZ1608Y 121BT
MMZ1608Y 121BT
MPZ1608S221A-T
MPZ1608S221A-T
DESCRIPTION
µPC2757TB-E3
TA31136FN (EL)
µPD3140GS-E1 (DS8)
µPC2746TB-E3
µPC2757TB-E3
µPC2746TB-E3
2SK880-Y (TE85R)
[RF UNIT]
REF ORDER
NO. NO.
Q506 1590002430 S.TRANSISTOR DTA144EE TL
Q507 1530003590 S.TRANSISTOR 2SC5277D2-TL
Q508 1590001660 S.TRANSISTOR XP4312 (TX)
Q509 1590002430 S.TRANSISTOR DTA144EE TL
Q510 1590001540 S.TRANSISTOR UMD6N TR
Q513 1590001650 S.TRANSISTOR XP4601 (TX)
Q514 1590001540 S.TRANSISTOR UMD6N TR
Q515 1590001940 S.TRANSISTOR DTC144EE TL
D1 1720000780 S.VARICAP
D2 1720000780 S.VARICAP
D3 1790001620 S.DIODE
D4 1720000780 S.VARICAP
D5 1720000780 S.VARICAP
D11 1790001620 S.DIODE
D13 1790001620 S.DIODE
D17 1720000700 S.VARICAP
D18 1720000780 S.VARICAP
D20 1790001590 S.DIODE
D21 1790001590 S.DIODE
D25 1790001620 S.DIODE
D29 1790001620 S.DIODE
D31 1790000850 S.DIODE
D32 1790001620 S.DIODE
D34 1790001620 S.DIODE
D36 1790001620 S.DIODE
D42 1790001260 S.DIODE
D43 1790001260 S.DIODE
D44 1790001260 S.DIODE
D46 1790001260 S.DIODE
D47 1790001620 S.DIODE
D50 1790001620 S.DIODE
D52 1790001620 S.DIODE
D53 1790001250 S.DIODE
D54 1720000650 S.VARICAP
D55 1790000850 S.DIODE
D56 1790000850 S.DIODE
D57 1790000660 S.DIODE
D58 1790001260 S.DIODE
D59 1790001260 S.DIODE
D60 1790001260 S.DIODE
D61 1790001260 S.DIODE
D62 1790000660 S.DIODE
D63 1790001260 S.DIODE
D64 1790001260 S.DIODE
D65 1790001260 S.DIODE
D66 1790001260 S.DIODE
D67 1790001260 S.DIODE
D68 1720000240 S.DIODE
D69 1790001260 S.DIODE
D70 1790001260 S.DIODE
D71 1790001620 S.DIODE
D72 1790001620 S.DIODE
D73 1790001620 S.DIODE
D74 1790001620 S.DIODE
D75 1790001620 S.DIODE
D76 1790001260 S.DIODE
D100 1720000820 S.VARICAP
D101 1790001260 S.DIODE
FI1 2040001200 S.SAW
FI2 2020001270 CERAMIC
FI3 2010002280 S.MONOLITH
X1 6050010210 S.XTAL
L1 6200007740 S.COIL
L2 6200005720 S.COIL
L3 6200005700 S.COIL
L4 6200005700 S.COIL
L5 6200005680 S.COIL
L7 6200005710 S.COIL
L8 6200005630 S.COIL
L9 6200005720 S.COIL
L10 6200005700 S.COIL
L11 6200005680 S.COIL
L12 6200005660 S.COIL
L13 6200005630 S.COIL
6 - 3
DESCRIPTION
HVU350B TRF
HVU350B TRF
1SV308 (TPL3)
HVU350B TRF
HVU350B TRF
1SV308 (TPL3)
1SV308 (TPL3)
1SV305 (TPL3)
HVU350B TRF
MA6S718 (TX)
MA6S718 (TX)
1SV308 (TPL3)
1SV308 (TPL3)
MA132WK (TX)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
MA2S111-(TX)
1SV286 (TPH3)
MA132WK (TX)
MA132WK (TX)
MA728 (TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA728 (TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
1SV172 (TE85R)
MA2S077-(TX)
MA2S077-(TX)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
MA2S077-(TX)
SVC347S/T-TL
MA2S077-(TX)
EFCH266MKQP1
CFWLB450KE2A-B0 (CFWM450E)
FL-293 (19.650 MHz)
CR-593 (19.200 MHz)
LQW2BHN47NJ01L (LQN21A 47NJ04)
ELJRE 33NG-F
ELJRE 22NG-F
ELJRE 22NG-F
ELJRE 15NG-F
ELJRE 27NG-F
ELJRE 5N6Z-F
ELJRE 33NG-F
ELJRE 22NG-F
ELJRE 15NG-F
ELJRE 10NG-F
ELJRE 5N6Z-F
S.=Surface mount
