Icom IC-R5 Service Manual page 2

INTRODUCTION
This service manual describes the latest service information
for the IC-R5 COMMUNICATIONS RECEIVER at the time of
publication.
MODEL Version
Europe
U.K.
Italy
U.S.A.
IC-R5
France
Spain
Export-01
Export-02
Canada
To upgrade quality, all electrical or mechanical parts and
internal circuits are subject to change without notice or oblig-
ation.
DANGER
NEVER connect the receiver to an AC outlet or to a DC
power supply that uses more than 6.5 V. Such a connection
could cause a fire hazard and/or electric.
DO NOT expose the receiver to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the receiver.
DO NOT apply an RF signal of more than 20 dBm (100mW)
to the antenna connector. This could damage the re-
ceiver's front end.
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
8930058920 LCD contact
8810009560 Screw PH BO M2x6 ZK IC-R5
Addresses are provided on the inside back cover for your
convenience.
1. Make sure a problem is internal before disassembling the receiver.
2. DO NOT open the receiver until the receiver is disconnected from its power source.
3. DO NOT force any of the variable components. Turn them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insulated turning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the receiver is defective.
6. READ the instructions of test equipment thoroughly before connecting equipment to the receiver.
SYMBOL AC ADAPTER
EUR BC-149D
UK
ITA
USA BC-149A
FRA BC-149D
ESP BC-149D
EXP-01 BC-136A
EXP-02 BC-136D
CAN BC-149A
IC-R5 LOGIC UNIT 5 pieces
CHASSIS 10 pieces
REPAIR NOTES
