Summary of Contents for Unitron uTV
- Page 1 ™ guide...
-
Page 2: Table Of Contents
Table of contents Your uTV™ ..............1 Overview of your uTV™..........2 Package contents ............3 uTV™ description............4 Installation ..............6 Daily usage of the Unitron uTV™ .........15 Warnings...............23 Troubleshooting guide..........26 Declaration of Conformity ..........29... -
Page 3: Your Utv
Your uTV™ Hearing healthcare professional: _____________________ _________________________________________________ Telephone: _______________________________________ Serial number of uTV: ______________________________ Warranty: ________________________________________ Date of purchase: __________________________________... -
Page 4: Overview Of Your Utv
Please read this user guide to discover how easy it is to benefit from all the features of your uTV. (k) Audio cable for 3.5 mm For further information, please visit the Unitron jack sockets website www.unitron.com. -
Page 5: Utv™ Description
The uTV is connected to your TV (or any other audio source) and wirelessly sends audio signals from your The Unitron uTV connects your hearing instruments TV to your uDirect within a range of up to 30 meters wirelessly to your TV or other audio devices. -
Page 6: Installation
RCA/Cinch plugs to the matching red and white Place the uTV next to your TV. Connect the mini-USB RCA/Cinch output sockets on your TV. plug of the power supply to the power input (“Power”) of the uTV. Plug the power supply into the wall socket. - Page 7 You can also connect your uTV to the 3.5 mm headset socket of your TV, using the 3.5 mm audio cable (k): Plug one end of the audio cable (k) into the uTV and the other end into the SCART adaptor. Then plug the Connect the 3.5 mm stereo plug to the audio input of...
- Page 8 MP3 player, PC or home sound system using the stereo plug cable k). To use the uTV, all devices must to be switched on. 1. Switch on your TV or other audio source. 2. Make sure your hearing instruments are switched on and properly in place.
- Page 9 Step 3: Pairing uDirect and uTV 4. Switch on the uTV by a short press of the ON/OFF button (a) as shown in fig. 2. The status light (g) Before starting to use the uTV, it must be paired with will illuminate green initially and may switch to your uDirect.
-
Page 10: Daily Usage Of The Unitron Utv
4 neckloop plug If the uTV status light g) is not flashing blue already, press the ON/OFF button ( ( a a ) ) for 5 seconds until the Bluetooth indicator g) is fast flashing blue as shown in fig 4. - Page 11 If the uDirect moves out of range of the uTV the wireless audio transmission will be terminated. If uDirect is then moved back into range of the uTV, it will automatically resume streaming to your hearing instruments.
- Page 12 TV via uTV. In the case of an incoming call, uDirect devices are set to a medium level for best audio automatically stops transmitting the audio signal from quality results.
- Page 13 • The uDirect battery indicator will be yellow to show indicator that uDirect is charging. ON/OFF • The uTV can either be ON or OFF during charging. fig. 8 Its status light (g) does not indicate the charging process. • Once the battery is fully charged, the uDirect battery...
-
Page 14: Warnings
For safety reasons, recharge the battery only transmission to communicate to your hearing with chargers supplied by Unitron. If other chargers instruments. Although unlikely, interference with are used they must be USB certified (5.0 VDC / 500 medical devices such as pacemakers is possible. -
Page 15: Information On Product Safety
Protect all devices from excessive moisture Keep the uTV at least 30 cm (1 ft) from the body (bathing or swimming areas) and heat sources during operation. (radiator, TV top). Protect devices from excessive shock and vibration. -
Page 16: Troubleshooting Guide
• Bring devices closer to each other. uDirect and the uTV is 30 meters (100 ft) is the maximum in Both indicator lights on uDirect and uTV (g) are solid blue but I cannot too great free field hear the TV To avoid streaming interruptions, make •... -
Page 17: Declaration Of Conformity
Most probable cause Remedy The volume during streaming is not comfortable (too low or too high) Hereby Unitron declares that this uTV meets the • If uTV is connected to the RCA/Cinch • The different TV audio requirements of the Radio and Telecommunications... - Page 18 Unitron Hearing Ltd. Changes or modifications made to this device not 20 Beasley Drive, P.O. Box 9017, expressly approved by Unitron may void the FCC Kitchener, ON N2G 4X1 Canada authorization to operate this device. European Representative FCC/IC RF Radiation Exposure Statement Max-Eyth-Straße 20, 70736...
- Page 19 Distributor www.unitron.com D/11-051 029-5836-02...
