Getting Started

Operating the Buttons

To operate any of the three buttons, push down or use the Pen vertically above the
button and touch the Pen Tip to the button and hold for several seconds.
On/Off Button
Press the On/Off Button for three seconds to activate the Mobi. The Mobi will go
into Sleep Mode after X minutes of inactivity.
Navigation Buttons
The Navigation Buttons to the right of the KWIK screen allow for moving through
the KWIK Screen options.
Connect Button
The Connect button on bottom of the Mobi allows for it to communicate with the
Workspace RF Hub and is recessed to avoid accidental activation.

Mobi Status Indicators

The following table identifies the icons associated with the Mobi status within the
KWIK screen.
Icon Indicates
Mouse Mode
Paired with
computer
USB
In Prox
In Menu
Battery Life
Indicator
Pen Charge
Interwrite Mobi™
Used To
Mobi is being used as a mouse
on the computer.
Mobi is paired with the
computer. This flashes when
paired with the computer.
It is blank when there is no
connection.
Mobi is connected to the
computer via the USB port.
Pen is within the proximity and
can be detected by the Mobi
The KWIK menu is in use. This
icon is blank if it is out of prox.
Indicates amount of battery life
left before charging. The battery
icon shows it is filling as it is
charging
Pen is charging within the pen
slot.
