Icom IC-F5020 Series Instruction Manual page 9

WIDE/NARROW KEY
Push to toggle the IF bandwidth between wide and narrow.
• The wide passband width can be selected from 25.0 or 20.0 kHz
using the CS-F3020/F5020
cloning software
only) Ask your dealer for details.
DTMF AUTODIAL KEY
➥ Push to enter the DTMF channel selection mode. And
then select the desired DTMF channel using [CH Up]/
[CH Down].
➥ After selecting the DTMF channel, push again to transmit
the selected DTMF code.
RE-DIAL KEY
Push to transmit the last-transmitted DTMF code.
• TX memories are cleared after turning the transceiver OFF.
CALL KEYS
Push to transmit a 2/5-tone ID code.
• Call transmission is necessary before calling another station
depending on your signalling system.
• [Call A] and/or [Call B] may be available when your system
employs selective 'Individual/Group' calls. Ask your dealer which
call is assigned to each key.
EMERGENCY KEY
Push and hold this for specified period to transmit an emer-
gency call.
. (PMR operation
• The emergency call transmits with beeps; the display does not
change.
• The transceiver can transmit an emergency call with no beep emis-
sion and LCD indication change depending on the pre-setting. Ask
your dealer for details.
• If you want to cancel the emergency call, push and hold the key
again before transmitting the call.
• The emergency call is transmitted one time only or repeatedly until
receiving a control code, depending on the pre-setting.
SURVEILLANCE KEY
Push to turn the surveillance function ON or OFF.
When this function is turned ON, the beep is not emitted and
the LCD backlight does not light when a signal is received or
a key is pushed, etc.
SIREN
Push to emit a siren.
TX CODE ENTER KEY (PMR operation only)
Push to enter the TX code edit mode directly.
Then set the desired digit using [CH Up]/[CH Down]. (p. 10)
PANEL DESCRIPTION
