SETTING THE KEYPAD ADDRESS
The keypad can either be set for an address of 00-30, or to
the non-addressable mode (31). The keypad's default
address is 31.
To change the keypad's address, do the following:
1. Enter address mode: Power up the keypad. Within 60
seconds of power-up, press and hold down the [1] and [3]
keys at the same time for 3 seconds. (If unable to enter
address mode, power up and try again.)
The current keypad address will be displayed, and the
cursor will be under the "tens" digit. If 10 seconds have
passed with no key entry, the keypad automatically
exits address mode. You must power down, power up
and start address mode again.
NOTE: The keypad will not enter address mode if the
panel to which it is connected is in programming mode.
2. Set the current address to "00": Press [0] to clear the
current "tens" digit. The cursor will move to the "ones"
digit position. Press [0] to clear the current "ones" digit.
The cursor will move back to the "tens" digit position.
3. Enter the keypad's address: Enter the proper "tens" digit
of the keypad's address. The cursor will move to the
"ones" digit position. Enter the proper "ones" digit of the
keypad's address. Note that address "31" sets the
keypad to non-addressable mode.
4. Exit address mode:
Press [ ] to save the displayed address and exit address
mode.
VIEWING THE KEYPAD ADDRESS
Press and hold down the [1] and [3] keys at the same time
for about 3 seconds. The current address is displayed. No
key entry is allowed. Press any key to exit or wait 10
seconds to exit viewing mode.
KEYPAD COLOR INSERTS
All three models include a cool gray color insert.
additional RED label is provided with the FA560KP should
any local agency require it.
REFER TO INSTALLATION INSTRUCTIONS FOR THE CONTROL PANEL WITH WHICH THIS DEVICE IS USED
FOR WARRANTY INFORMATION AND LIMITATIONS OF THE ENTIRE ALARM SYSTEM.
¬. 9Pl
K3590-1V1 8/00
FUNCTION KEY LABELS
A set of adhesive-backed labels with some typical function
symbols (i.e., fire, police, personal emergency, etc.) is provided.
These labels can be placed on or next to the keys to identify
each key's function for the end user (as determined by the
control panel's capability and programming; see the control's
instructions).
SPECIFICATIONS
Physical:
FA215KP:
FA260KP:
FA560KP:
Wiring (all Keypads):
DI (Green):
- (Black):
+ (Red):
DO (Yellow):
Displays:
FA215KP,
FA260KP:
FA560KP:
Sounder:
FA215KP:
FA260KP,
FA560KP:
Current:
FA215KP:
An
FA260KP:
FA560KP:
175 Eileen Way, Syosset, New York 11791
Copyright © 2000
5-5/8"H x 4-3/8"W x 1-5/16"D
6-5/8"H x 4-7/8"W x 1-5/16"D
7-5/16"H x 5-3/8"W x 1-3/8"D
"Data In" to control panel
Ground
+12VDC (Aux. Power)
"Data Out" from control panel.
Fixed-Word LCD
Fixed-Word LCD (backlit).
2 x 16 alpha-numeric supertwist LCD, backlit.
Piezo-electric (fire alarm is loud, pulsing single
tone; (all Keypads) burglary alarm is loud,
continuous, dual tone).
Speaker.
Speaker.
55mA sounder on
35mA standby (alarm sounder off).
150mA backlight and sounder on
75mA standby mode (backlight on).
150mA backlight and sounder on
80mA standby mode (backlight on).
