INTEGRATION IBUS 2.1 - FLAT SUBWOOFER + 2 CHANNELS
/
AMPLIFIER
Traditional wiring:
Installation
If your car radio is without ISO connector, you must get an ISO adapter.
Photo legend page 12
A
Power supply wire +12 Volts (Red)
B
Ground cable (Black)
C
Remote cable (Blue)
D
Power supply connector
E
Power supply connector and speakers
U s e r m a n u a l
F
Speaker connector
G
High level connector
H
Power supply connector and car speakers
I
Car radio connectors
J
Remote control wire
K
Remote control
