Congratulations. You have just purchased an advanced spreader from C-Dax Ltd. C-Dax Ltd is committed to
providing you, the farmer, with quality applicating systems.
The C-Dax C-DIT400 is a ground-driven spreader designed for application of pelleted fertilisers. It can also
be used for application of other products such as grass seed and magnesium oxide. The uniquely designed
400-litre translucent non-corrosive polyethylene hopper is specially profiled for good product flow and ease of
filling. The convenient polyethylene cover is easy to remove, install and store if not required. A high-quality
stainless steel agitator and shutter ensures even flow of product to the spinner. A unique spinner design
ensures wide, even spread of products over 180 degrees (Urea). The heavy-duty galvanised frame is fitted
with knobbly turf tyres as standard equipment. The drive train uses high quality steel and a double sealed
self-aligning bearing and heavy-duty gearbox for maximum durability. While seated, the operator has access
to the control handle. This handle allows disengagement and engagement of the clutch and setting of
product feed rate all in one motion. Also standard are mudguards, swivel tow-hitch and a fully shrouded
polyethylene front deflector to further protect the operator from product being thrown off the spinner.

Specifications

(Specifications subject to change without notice)
Dry Weight
Dimensions
Capacity
Drive
Wheels
Tyre pressure
Clutch
Control
Agitator
Spinner
Hopper
Hopper cover
Frame
Gearbox
Gearbox oil
Axle Bearings
Clutch bearing
Axle grease
Application Rate
Spread width
Towing speed

Order Information

Standard CDIT400
C-Dax Ltd warrants to the original purchaser that the equipment is sold free from defects in materials and
workmanship for a period of 12 months from date of retail sale (6 Months from date of retail sale for all
equipment sold in the U.K.).
Accordingly, C-Dax Ltd undertakes to repair the equipment, or at our option replace, without cost to the
original purchaser either for materials, parts or labour, any part which within the specified warranty period
from time of delivery is found to be defective. PROVIDED that the equipment has been used for normal
purposes in accordance with the instructions, and has not been subject to neglect, misuse or accident, and
has not been repaired, serviced or dismantled by any person other than a service agent or person authorised
by C-Dax Ltd.
The warranty does not extend to cover: consequential damage; repair or replacement of parts due to fair
wear and tear; or damage resulting from neglect, misuse, accident or hireage. SPECIFICALLY the warranty
excludes battery damage, damage arising from chemical attack, and units built to customers specifications.
All goods returned to C-Dax Ltd are freight paid by the sender and if subject to a warranty claim, must be
accompanied by a completed warranty claim form. Warranty claim forms are available from C-Dax dealers.

INTRODUCTION

120 Kg
W1900mm, H1400mm, L1850mm
400 litre (320Kg Urea)
Ground driven (single wheel)
18x950x8 knobbly turf tyres
15PSI (100Kpa)
Lever operated mechanical clutch
Adjustable stainless steel slide with index handle
Mechanical arm, stainless steel
Galvanised steel with three-position adjustable vanes
Non-corrosive polyethylene, ergonomically designed for ease of filling and
inspection
Polyethylene plastic
Galvanised steel
Heavy duty with double sealed bearings
400ml SAE30
Sealed ball races
Heavy-duty phosphor-bronze bush
General Purpose
140Kg per hectare @ 10 kph (nominal, Urea)
18M (nominal, Urea @ 15 Kph)
15 Kph (Maximum recommended)

DESCRIPTION

NZ , AUST & UK
P/N 3004

WARRANTY

5
