Check the Bair Hugger therapy website to ensure you have the most recent version of this document.
Warning: Electrical Shock Hazard. There are electrically live parts within the
warming unit when it is connected to a power source, even when the switches are
in the OFF or STANDBY position.
Please forward to Biomedical Engineering Department
BAir HUggEr MoDEll 505 TEMPErATUrMAnAgEMEnTgEräT SErVicE gEBrAUcHSAnlEiTUng
Vorsicht: Gefährliche elektrische Spannung. In einem an das Stromnetz angeschlossenen
Wärmegerät stehen bestimmte elektrische Komponenten auch dann unter Strom, wenn
der Schalter auf AUS oder BEREITSCHAFTSMODUS geschaltet ist.
Bitte an die Abteilung für biomedizinische Technik weiterleiten
UniTé DE gESTion DE TEMPérATUrE BAir HUggEr MoDèlE 505 SErVicE MAnUEl
Mise en garde : Risque d'électrocution. Certaines pièces sont électriquement chargées
dans les appareils de réchauffement, lorsque ceux-ci sont connectés à une source
d'alimentation et ce, même si l'appareil est en position OFF (arrêt) ou STANDBY (attente).
A transmettre au Service d'ingénierie biomédicale
To t a l Te m p e r a t u r e M a n a g e m e n t S y s t e m
Bair Hugger
Model 505 Warming Unit
Service Manual
www.bairhugger.com
*
reorder #200597D
Advertisement
Table of Contents
Related Manuals for Bair Hugger Security Systems
Summary of Contents for Bair Hugger Security Systems
- Page 1 Check the Bair Hugger therapy website to ensure you have the most recent version of this document. www.bairhugger.com reorder #200597D Bair Hugger Model 505 Warming Unit Service Manual Warning: Electrical Shock Hazard. There are electrically live parts within the warming unit when it is connected to a power source, even when the switches are in the OFF or STANDBY position.
- Page 2 Bair Hugger Model 505 Warming Unit Service Manual English Deutsch Français...
-
Page 3: Table Of Contents
Symbol Definitions ............28 Bair Hugger Model 505 Service Manual... -
Page 4: Introduction
Description of the Total Temperature Management* System The Bair Hugger brand Total Temperature Management system consists of a Bair Hugger forced-air warming unit and disposable components, including Bair Hugger forced-air blankets and the 241* blood/fluid warming set, and Bair Paws* patient warming gowns. -
Page 5: Warnings
3. Do not warm patients with the temperature management unit hose alone. Thermal injury may result. Always connect the hose to a Bair Hugger blanket or Bair Paws gown before providing therapy. Do not place the non-perforated side of the blanket on the patient. -
Page 6: Cautions
Except for specific blanket models, Bair Hugger blankets are not sterile and are all intended for single patient use ONLY. Placing a sheet between the Bair Hugger blanket and the patient does not prevent contamination of this product. Monitor the patient’s temperature and cutaneous response every 10-20 minutes or according to institutional protocol and monitor the patient’s vital signs regularly. -
Page 7: Read Before Servicing Equipment
Safety Inspection Perform a safety inspection after making repairs to the Bair Hugger warming unit and before returning the warming unit to service. A safety inspection should include a test of the operating temperatures (described in this service manual), the Over Heat alarm system, as well as a leakage current test. -
Page 8: Service Procedures
45° angle in the grooved blower outlet, then snap the hose into place. (See Figure 1.) Figure 1. Attaching the replacement Hose Press this Insert flange into tab to groove and snap into release place hose Bair Hugger Model 505 Service Manual... -
Page 9: Power Fuse Replacement
Record the maintenance action taken and the hours of operation (read from the hour meter) in the Maintenance Log section. Detail Figure 2. location of Power Fuse Fuse carrier Power entry module (see detail) Spare fuse Bair Hugger Model 505 Service Manual... -
Page 10: Control Board Fuse Replacement
See Figure 3 for location of the fuse. Remove the fuse and replace with the new one. CAUTION: Replace only with the fuse capacity and type that is indicated on the adjacent label. Bair Hugger Model 505 Service Manual... - Page 11 Board Fuse Flip the top cover to access the control board Phillips screws Control board fuse Retainer bracket Retainer bracket hooks into top cover and is secured by screws through two front “feet” Bair Hugger Model 505 Service Manual...
-
Page 12: Air Filter Replacement
Reconnect the warming unit to the power source. Record the hour meter reading and maintenance action taken in the Maintenance Log section. Figure 4. location of Air Filter and Hour Meter Hour meter Air filter Bair Hugger Model 505 Service Manual... -
Page 13: Over Heat Alarm Testing
Model 22110 Temperature test unit. Arizant Healthcare Inc. assumes no responsibility for the reliability, safety, or performance of the Bair Hugger system if warming unit temperature testing or adjustments are made in any other manner than that described here. - Page 14 The alarm and manual reset constitutes one cycle. NOTE: If the alarm does not turn off, allow the unit to alarm for 1 more minute before turning the warming unit to STANDBY, then ON again. Bair Hugger Model 505 Service Manual...
- Page 15 53° ± 3°C (127.4° ± 5.4°F) or less at the end of the hose, as determined by the Model 221 Temperature Test Kit or the Model 22110 Temperature Test Unit. Bair Hugger Model 505 Service Manual...
-
Page 16: Over Heat Alarm Thermostat Adjustment
Connect the warming unit to the power source and turn the warming unit power ON. NOTE: The temperature setting will not affect the over heat adjustment. Using the Phillips-head screwdriver, remove the screw on the alarm test panel. Lift and remove the panel. Bair Hugger Model 505 Service Manual... - Page 17 Record the maintenance action taken and the hours of operation (read from the hour meter) in the Maintenance Log section. Figure 7. location of over Heat Alarm Thermostat Over heat alarm thermostat access (detail) Bair Hugger Model 505 Service Manual...
-
Page 18: Normal Operating Temperature Testing
Model 22110 Temperature Test Unit. Arizant Healthcare Inc. assumes no responsibility for the reliability, safety, or performance of the Bair Hugger system if warming unit temperature testing or adjustments are made in any other manner than that described here. - Page 19 43° ± 3°C (109.4° ± 5.4°F) MED: 38° ± 3°C (100.4° ± 5.4°F) LOW: 32° ± 3°C (89.6° ± 5.4°F) Note: Air temperature reaching the patient is approximately 2°C lower than the listed temperatures. Bair Hugger Model 505 Service Manual...
-
Page 20: Normal Operating Temperature Adjustment
NOTE: Do not block the rear air vents on the test device. Turn the warming unit power ON, and allow it to operate at HIGH for about 3 to 5 minutes before adjusting the potentiometer. Bair Hugger Model 505 Service Manual... - Page 21 Record the maintenance action taken and hours of operation (read from the hour meter) in the Maintenance Log section. Figure 9. location of operating Temperature Adjustment Potentiometer Operating temperature potentiometer access Bair Hugger Model 505 Service Manual...
-
Page 22: Specifications
2°C lower than the listed temperatures. Operating Temperatures Average temperature at the end of the hose: HIGH: 43° ± 3°C (109.4° ± 5.4°F) MED: 38° ± 3°C (100.4° ± 5.4°F) LOW: 32° ± 3°C (89.6° ± 5.4°F) Bair Hugger Model 505 Service Manual... -
Page 23: Key To Figure 10
Motor 115V, 60Hz Heater 120V Handle Top Warning Label Control Board Fuse 200mA Overtemp Switch Electrical Shield Control Panel Label Back Plate Power Entry Module Power Fuses (2) Filter Bracket Elbow Assembly Hose Assembly Bair Hugger Model 505 Service Manual... - Page 24 Figure 10. Exploded Drawing Detail of control Board Bair Hugger Model 505 Service Manual...
-
Page 25: Technical Support And Customer Service
1-952-947-1400 When You call for Technical Support We will need to know the serial number of your Bair Hugger unit when you call us. On Model 505 units, the serial number label is affixed to the rear panel. in-Warranty repair and Exchange USA Replacement parts to correct a problem are delivered at no charge. -
Page 26: Returning Units For Service
Apply the shipping label addressed to Arizant Healthcare Inc. Using the marking pen, write your RA number (from Technical Support) on the outside of the carton. Figure 11. Service carton Upper foam pad Hose elbow Lower foam pad Bair Hugger Model 505 Service Manual... -
Page 27: Troubleshooting
Poor wire connections at thermostat. Reattach any loose connections to thermostat. (See Figure 10). Warming unit alarms at too lower Over heat thermostat not in calibration. See Over Heat Alarm Thermostat too high a temperature. Adjustment procedure. Bair Hugger Model 505 Service Manual... -
Page 28: Maintenance Log
Maintenance log Date Maintenance Action Performed Hour Meter Bair Hugger Model 505 Service Manual... - Page 29 Maintenance Log Date Maintenance Action Performed Hour Meter Bair Hugger Model 505 Service Manual...
- Page 30 Maintenance Log Date Maintenance Action Performed Hour Meter Bair Hugger Model 505 Service Manual...
-
Page 31: Symbol Definitions
ON/OFF push button switch Temperature Control Equipotentiality plug (Ground) Fuse Attention (see appropriate documents) Dangerous Voltage Type BF Equipment (patient applied) Voltage, Alternating Current (AC) Special Refuse, discard separately Protective earth ground No free hosing Bair Hugger Model 505 Service Manual...
