Electrical connections
ANTENNA
CONNECTOR
SUB WOOFER
POWER ANTENNA
BLUE/WHITE
AMP TURN
ON LED
CONSTANT
12 VOLTS
FRONT
LEFT
SPEAKER
REAR
LEFT
SPEAKER
14
LINE OUT
(FRONT)
L (WHITE)
R (RED)
LINE OUT
(REAR)
L (WHITE)
R (RED)
LINE IN
L (WHITE)
R (RED)
ISO A/B PLUG
BLUE
YELLOW
+ WHITE
– WHITE/BLACK
+ GREEN
– GREEN/BLACK
ISO CONNECTOR
B
A
BLUETOOTH
MICROPHONE
BLACK
GROUND (–)
RED
IGNITION SWITCH (12 V)
GREY +
GREY/BLACK –
VIOLET +
VIOLET/BLACK –
FRONT
RIGHT
SPEAKER
REAR
RIGHT
SPEAKER
