- Page 1 22.3 °C -13.2 °C 33.4 °C Normal heating mode Unit 2 We 09:36 Menu HEATING CIRCUIT 1 Operating manual Dok. Nr. 111080 19/08 Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page of 36...
-
Page 2: Table Of Contents
Note/ explanation! 7.1 Technical data MB 6100 / MB 6400 ..................7.2 Sensor resistance values ..................... 7.3 Explanation of terms and abbreviations ................Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36... - Page 3 This manual will give you basic information how to use the remote control HFB 6101. The SC 6001 is built into the heat pump, this is operated by this HFB 6101 remote control. All errors and informations from the HSC 6001 heat pump controller are displayed on this remote control HFB 6101 remote control.
-
Page 4: Overview
Normally if the display light is switched off, you can switch it on by pushing any button. To activate its functions, push it once again. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page... -
Page 5: B Quick Select Heating Circuit 1 Or 2
- by turning the button B the comfort level may be adjusted by up up to +/-3K. It affects the normal and the energy saving/economic temperature. - to save the set value, push the button B Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56... -
Page 6: C Quick Select Global Function
The latest saved time will be shown after pushing the soft key 1. To set it, just turn button B. To save it, just push button B. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12... -
Page 7: Quick Select Hot Water Circuit
The hot water set point temperature (e.g. 50°C), will be shown after pushing the Soft key 1. To make adjustments in it (e.g. 45°C), just turn button B. To save it, just push button B. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12... -
Page 8: Quick Select Heat Pump
Soft key 4. To list the temperatures and operating data, just turn button B. To return to the above shown display, just push ESC-button. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12... -
Page 9: Errors
If this error keeps indicated, please call your installer. Low pressure caused by sensor Low pressure sensor was activated. Please call your installer. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page... -
Page 10: Menu Levels
It shows the menu up to deepest level using the example of heating circuit 1. The other menus (Heating circuit 2, hot water) have the same structure. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12... - Page 11 Manual HFB 6101 Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page of 36...
-
Page 12: G Display, Operating Elements, Structure
Manual HFB 6101 Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36 16:56... - Page 13 Gen. flow temperature (measured value) (measured value) Source return temperature Gen. return temperature (measured value) (measured value) Actual function Actual selected heating generator Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page of 36...
- Page 14 Manual HFB 6101 Operating structure: Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36 16:56...
-
Page 15: Installation And Start-Up Of The Controller 1 Adjustments Mb 6100 / Mb 6400
• found units their functions can be found under “Select func tions. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page of 36... -
Page 16: Accessories Should Not Be Opened. Re- 1.2 Start - Reset - Settings Mb (Uncoded)
6. The MB is now in the function selection controller selected in the example, “Unit 2”. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36 16:56... -
Page 17: Compensation Room Temperature (Uncoded)
1.5 K witch is added. (22.3 °C + 1.5 K = 23.8 °C) The correction value of the room temperature sensor remains stored also after a power-off. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page... -
Page 18: Change Function Name (Uncoded)
19 8. Press the Esc button several times, until the actual function list appears. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36... -
Page 19: Settings Mb (Coded)
5. After a timeout of 2 minutes the display switches to the list of functions without code. To get to the coded functions, the code has to be inserted again. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page... -
Page 20: Mb Master Nr (Coded)
4‘th Heat-generator 5‘th Heat-generator 4‘th Slave controller 5‘th Slave controller 6‘th Slave controller 7‘th Slave controller 6‘th Heat-generator 7‘th Heat-generator 8‘th Heat-generator Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36 16:56... -
Page 21: Zone Mapping (Coded)
5. The standard display shows the room temperature (example 22.3 °C) measured by the intern room sensor. • If no room sensor is assigned, 0°C appears. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page of 36... -
Page 22: Quick-Select Menu
The comfort function can be reached also by turning the rotary knob while being at step 2. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36... -
Page 23: Select Operating Mode
Operate the mixer manually! Request help from an expert! The exact function range can be found in the operating instructions of the selected control device. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56... -
Page 24: Adapting Room Temperature Temporarily
Rotating quickly speeds up the input. existing program cancelled by rotating the knob to the left side until it shows “0 min”, see pos. 3, 4. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36 16:56... -
Page 25: Vacation Program
4. The set/changed time can be stored by pressing the rotary knob. Afterwards, the Date function can be selected and the date set in the same way. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page of 36... -
Page 26: Settings Heating Circuit/Heat-Generator
You will get the password from a technician. If the password is wrong, the controller jumps back to step 2. The Password MB and Password controller are different. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36 16:56... -
Page 27: Explanation Of Terms And 4.2 Query Setpoint- And Measured Values
All following adjusters can be set/ changed in the same way. For a list of adjusters, see the controller operating instructions. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page of 36... -
Page 28: Output-Functions Check
• -100 % = Mixer CLOSED The relay test has a time-out of 4 minutes. For a list of relay outputs, see the controller operating instructions. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36... -
Page 29: Clock Program Setting
10.Press the Esc button several times until the heating circuit display appears with the current time program. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page of 36... -
Page 30: In This Document The Following 5. Dimensions And Installation
Connection lines to the controller are to be installed separately from power lines. Connection to the terminal (polariza- tion-independent) 5.2 Dimensions MB 6x00 -► Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36 16:56... -
Page 31: Start Up And Help In Solving Problems
2. In the lower line is shown the software version (e.g. 0.98) 3. By pressing the ENTER-button the controller will be started, the internal function test was successful Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page of 36... -
Page 32: Error Info
As long as the error hasn’t been resolved, the MB 6x00 always jumps to the function display of the existing error. Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36... -
Page 33: Technical Data
Resistance NTC 5 kΏ 7.2 Sensor resistance values 48’535 36’475 27’665 21’165 16’325 12’695 9’950 7’855 6’245 5’000 4’029 2’663 1’802 1’244 Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page of 36... -
Page 34: Explanation Of Terms And Abbreviations
Time period for heating mode or reduced heating mode, witch can be programmed Reduced mode Economical heating mode Normal mode Heating mode with room temperature setpoint Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36 16:56... - Page 35 Quick-select menu RESET Select operating mode Sensor resistance values Settings Settings heating circuit/heat-generator Settings MB (uncoded) Settings MB with code Start Start up Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 16:56 Page of 36...
- Page 36 Manual HFB 6101 Art-Nr.: BED1062 We reserve the right to make product changes without notice! 05/2012 Hautec GmbH An der Molkerei 9 D-47551 Bedburg-Hau/ Hasselt Tel.: +49(0)2821-7612-3 Fax: +49(0)2821-7612-76 23.05.12 Page of 36 16:56...
