Outdoor Lifestyles ODVILLA-36H Owner's Manual

Outdoor woodburning fireplace
Table of Contents

Advertisement

Models:
Outdoor Woodburning Fireplace
ODVILLA-36H
ODVILLA-36T
ODVILLA-42H
ODVILLA-42T
Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfi re. Overfi ring will void your
warranty.
• Comply with all minimum clearances to
combustibles as specifi ed. Failure to
comply may cause house fi re.
Installation and service of this fi replace
should be performed by qualifi ed personnel.
Hearth & Home Technologies suggests NFI
certifi ed or factory-trained professionals, or
technicians supervised by an
NFI certifi ed professional.
Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13
NOTICE
DO NOT DISCARD THIS MANUAL
Read, understand
and follow these
instructions for safe
i n s t a l l a t i o n a n d
operation.
Owner's Manual
Leave this manual with
party responsible for
use and operation.
WARNING
Hot screen/mesh and glass doors will cause burns.
DO NOT touch screen/mesh or glass doors until
cooled
NEVER allow children to touch screen/mesh or glass
doors
Keep children away
CAREFULLY SUPERVISE children in same room as
fi replace.
Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other
fl ammable materials.
Keep clothing, furniture, draperies and other
fl ammable materials away.
WARNING
Fire Risk
For use with solid wood fuel or decorative
gas appliance only.
DO NOT install unvented gas logs.
Installation and Operation
HOT SURFACES!
Screen/mesh, glass doors
and other surfaces are hot
during operation AND cool
down.
1

Advertisement

Table of Contents
loading

Summary of Contents for Outdoor Lifestyles ODVILLA-36H

  • Page 1 • For use with solid wood fuel or decorative technicians supervised by an gas appliance only. NFI certifi ed professional. • DO NOT install unvented gas logs. Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 2: Congratulations

    CONTACT: HEARTH & HOME TECHNOLOGIES INC., 1915 W. SAUNDERS ST., MT. PLEASANT, IA 52641. Note: An arrow ( ) found in the text signifies change in content.  Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 3: Table Of Contents

    Inspect Fireplace and Components Framing & Clearances A. Selecting Fireplace Location B. Clearances C. Sidewalls/Surrounds D. Frame the Fireplace E. Chimney Requirements Installation of Fireplace A. Position the Fireplace Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 4: Warranty

    Warranty Outdoor Lifestyles by Hearth & Home Technologies, Inc.™ Limited Warranty Hearth & Home Technologies, Inc. (“HHT”) extends the following warranty for all Outdoor Lifestyles by HHT™ brand products (“Products”) that are purchased from an HHT authorized dealer. WARRANTY COVERAGE:...
  • Page 5 The duration of any implied warranty is limited to the duration of the warranty period specified herein. Outdoor Lifestyles Warranty - 2108-975A - 10/05/09 - page 2 Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 6: Listing And Code Approvals

    NOTICE: This fireplace is tested and approved as a decorative fireplace. It should not be factored as a primary heat source in residential heating calculations. Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 7: User Guide

    Section 2.I. Firescreen Wood Fuel (not shown) Section 2.M. Section 2.E. Hearth Glass Doors (not shown) Section 2.G. Clear Space Section 2.L. Figure 2.1 General Operating Parts Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 8: Seasoned Wood

    CAUTION! Odors and vapors released during initial operation may be irritating to sensitive individuals. Open windows for air circulation. Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 9: Glass Doors

    See page 14 48 in. (1219 mm) Clear Space 12 in. (305 mm) Front of Fireplace Clear Space Sides of Fireplace (from the FP opening) Figure 2.3 Clear Space Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 10: Wood Fuel

    Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 11: Maintenance And Service

    Section ST375 TS345/TS345P TCT375 TR344/TR342 Square Square Terra Cotta Round Termination Cap Termination Caps Termination Cap Termination Cap DT SERIES Figure 3.1 Chimney & Termination Cap Cleaning Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 12: Check Firebox Refractory

    • Light deposits Use household glass cleaner • Heavy deposits Use wood ash on damp cloth or, Use commercial fireplace glass cleaner (consult with your dealer) Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 13: Troubleshooting Guide

    Add glass doors to slow down air flow. Overdrafting Check for correct vent height; too much vertical height creates overdrafting. Check location of vent termination (refer to chimney assembly section). Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 14: Getting Started

    Decorative facing level and trim (Section 11.D.) Hearth extension Combustible framing/header (Section 11.C.) on top of V-shaped standoffs (Section 6.D.) Factory-built fireplace Protective metal hearth strip(s) (Section 7.C.) Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 15: Design And Installation Considerations

    Hearths should slope away from the front of the fireplace and chase at 1/8 in. to 1/4 in. per foot. Spark strips must be on top of any combustible hearth materials used for moisture management. Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 16: Tools And Supplies Needed

    This fireplace system requires: • Fireplace • Hearth Refractory • Grate Assembly • Hearth Extension (required, sold separately) • Chimney System (required, sold separately) • Termination Cap (required, sold separately) Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 17: Framing & Clearances

    1067 1270 1724 1511 1219 opening to any 73 7/8 65 1/2 37 1/4 52 1/4 21 1/2 inches perpendicular ODVILLA-42 1219 1422 1876 1664 1327 wall. Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 18: Clearances

    0 in. to level of standoffs 1/2 in. (13 mm) to back & sides of appliance 48 in. 1219 mm 0 in. to floor Figure 6.2 Clearances to Combustible Materials Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 19: Sidewalls/Surrounds

    * If interior of chase will be drywalled, add the thickness to this measurement. ** Adjust header height for a raised floor under fireplace. Figure 6.4 Framing the Fireplace Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 20: Chimney Requirements

    • Maximum unsupported chimney height above 10.67 the fireplace • Minimum overall straight height if fireplace is 3.048 freestanding Note: A maximum of two pairs of offsets and returns may be used. Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 21: Installation Of Fireplace

    • Check fireplace opening for square to ensure proper fit of glass doors. Measure diagonals of fireplace opening to make sure they are equal. Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 22: Install Cooling Air Hoods (Provided)

    Caution ! Risk of Fire or Asphyxiation! Do not draw outside air from wall, floor, or ceiling cavity, or enclosed spaces such as an attic or garage. Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 23: Chimney Assembly

    Ceiling firestops are required where chimney passes through ceiling or floor Figure 8.1 Typical Chimney System - Guidelines for Chimney System Installation Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 24: Chimney Requirements

    39 1/2 in. (1003 mm) 20 ft. (6.1 m) min. height/double offset-return Effective Height fumes into the living areas. 90 ft (27.43 m) max. height Figure 8.2 Chimney Requirements Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 25: Using Offsets/Returns

    94-1/2 2400 Proper assembly of air-cooled chimney parts result in an overlap at chimney joints of 1-1/4 in. (32 mm). Effective length is built into this chart. Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 26: Assemble Chimney Sections

    • Secure chimney returns with hanger straps provided; fasten to studs or joists. • Vertical straight runs of chimney must be supported every 35 ft (10.7 m). Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 27: Install Ceiling Firestops

    (use 600° F sealant). Catalog # Angle FS338 14-1/2 14-1/2 0° FS339 14-1/2 18-3/8 15° FS340 14-1/2 30° Figure 8.5 Installing the Ceiling Firestop Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 28: Cut Out Hole In Roof

    All nail heads must be caulked with a roofing sealant. • Caulk the overlap seam of any exposed pipe sections that are located above the roof line to prevent leaks. Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 29: Chimney Termination Requirements

    In a staggered installation with both gas and wood terminations, the wood termination cap must be higher than the gas termination cap. Figure 8.7 Multiple Chimney Locations Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 30: Chase Installations

    False Ceiling False Ceiling • Failure to prevent contact between insulation or other Chimney materials and chimney system may cause overheating and fire. Figure 9.1 Chase Assembly Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 31: Install Fireplace & Chimney

    WARNING! Risk of Fire! DO NOT caulk the pipe to the Galvanized chase top collar. Chase Top • Caulk all seams to prevent leaks. • Refer to Figure 9.3. Figure 9.3 Chase Top Construction Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 32: Install Termination Cap

    Figure 9.4 Installing a TR344 Round Termination Cap Termination cap pipe and chimney section must overlap 1-1/2 in. (38 mm) Figure 9.6 Installing an ST375 Square Termination Cap Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 33 7 in. (178 mm) Chase Chimney Pipe Termination cap pipe and chimney section must overlap 1-1/2 in. (38 mm) Figure 9.8 Installing a TCT375 Terra Cotta Cap Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 34: Shrouds

    Min. Opening Width 17 x 17 22 x 22 20 x 20 432 x 432 559 x 559 508 x 508 Figure 10.2 Open Top Shroud Dimensions Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 35 27 x 27 27 x 27 686 x 686 686 x 686 Min. Height Above Radiation Shield Min. Opening Width Min. Opening Height Figure 10.4 Roofed Style Shroud Dimensions Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 36: Finishing

    Common Brick 0.20 5-1/8 in. Ceramic Tile 12.50 0.08 12-1/4 in. Armstrong™ Privacy Guard Plus 0.46 2.18 1/2 in. Marble 14.3-20.0 0.07-0.05 14-5/8 in. - 20-3/8 in. Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 37 Metal Hearth Strip is required other combustible material under the front of the fireplace equivalent insulation Figure 11.2 Hearth Extension Construction Figure 11.4 Raised Platform Hearth Extension-Framing Materials Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 38 Non-combustible Sealant Figure 11.6 Place Non-combustible Sealant Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 39: Finishing Material

    2 in. (51 mm) Figure 11.8 Decorative Facing Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 40: Combustible Mantel

    Combustible trim must not cover the metal surfaces of the fireplace. Mantel clearance is in accordance with Section 7-3.3.3 of ANSI/NFPA211. • Figure 11.9 Clearances to Mantels or other Combustibles above Fireplace Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 41: Sidewalls/Surrounds

    Combustible or non-combustible mantel legs, surrounds and stub walls may be constructed per Figure 11.10. Figure 11.10 Mantel Leg or Wall Projections (acceptable on both sides of opening) Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 42: Accessories

    Repack beyond 4 in. (102 mm) insulation from fireplace side. knockout 4 in. (102 mm) Figure 12.1 Gas Line Installation Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 43: Reference Materials

    Reference Materials A. Fireplace Dimensions Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 44: Optional Components

    1/2 in. HX3 Hearth Extension (13 mm) 66 in. (1676 mm) 20 in. (508 mm) Bifold Glass Doors ODVGF-36, ODVGF-42 1/2 in. HX4 Hearth Extension (13 mm) Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 45: Chimney Components

    4-3/4 in. (121 mm) Diameter Termination Cap”) Effective Height 10-1/2 in. CT-3A Adapter - May be used with the following copper caps (267 mm) CT-Series SL3 Vent Stabilizer DT-Series Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 46 TR342 Round Telescoping Termination Cap CT-3A 15-5/8 in. (397 mm) 15-3/4 in. (400 mm) TR-TVK ST375 Square Termination Cap TR344 Round Termination Cap TR Top Vent Kit Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 47 (413 mm) 26 1/2 in. (673 mm) 28 5/8 in. (727 mm) LDS-BV Decorative Shroud Catalog # 18 in. 12.5 15.5 (457 mm) LDS-BV TS345/TS345P Square Termination Cap Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 48: D. Service Parts

    Door Pivot Clip Qty 2 req 31527 Strip Protector 18320 Hair Pin Clip Pkg of 24 101025/24 Installation Instructions and Owner’s Manual 4072-137 Additional service parts following page. 11/13 Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 49 Side Refractory, Right, 17.25” W x 18.21” H 4072-108 16.4 Side Refractory, Left, 17.25” W x 18.21” H 4072-109 16.5 Corner Shield Qty 2 req 4072-145 16.6 Retainer Qty 3 req 11847 Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 50 Door Pivot Clip Qty 2 req 31527 Strip Protector 18320 Hair Pin Clip Pkg of 24 101025/24 Installation Instructions and Owner's Manual 4072-137 Additional service parts following page. 11/13 Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 51 Side Refractory, Right, 17.25” W x 18.21” H 4072-109 16.4 Side Refractory, Left, 17.25” W x 18.21” H Corner Shield Qty 2 req 4072-145 16.5 Retainer Qty 3 req 11847 16.6 Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
  • Page 52: Contact Information

    Outdoor Lifestyles by Hearth & Home Technologies Inc.• 4072-137 Rev F • 11/25/13...
