Outdoor Gas Fireplace
Installation & Operating Instructions
Models:
ODGSR36A, ODGSR42A
INSTALLER/CONSUMER
SAFETY INFORMATION
PLEASE READ THIS MANUAL
BEFORE INSTALLING AND USING
APPLIANCE.
WARNING: If the information in this
manual is not followed exactly, a fire or
explosion may result causing property damage,
personal injury or loss of life.
—
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance
—
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
•
If you cannot reach your gas
supplier, call the fire department.
—
Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
WARNING: Improper installation,
adjustment, alteration, service or
maintenance can cause injury or
property damage. Read the installation, operating
and maintenance instructions thoroughly before
installing or servicing this equipment.
ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17
7114
ODGSR
cover
WARNING!
11/03
For Outdoor Use Only.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future
reference.
Installation and service of this appliance should be performed by
Advertisement
Table of Contents
Related Manuals for Outdoor Lifestyles ODGSR36A
Summary of Contents for Outdoor Lifestyles ODGSR36A
- Page 1 Installation and service of this appliance should be performed by property damage. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17...
-
Page 2: Table Of Contents
ODGSR Series Outdoor Gas Fireplace Table of Contents Thank you and Congratulations on your purchase of a Outdoor Lifestyles fireplace. PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING THE APPLIANCE IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. -
Page 3: Installation & Operating Instructions
This fireplace is not designed to be water tight. There- to the design parameters as detailed below. fore, when installing this unit against an exterior wall, the wall must be finished before setting unit in place. ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17... -
Page 4: Fireplace Dimensions
Low Voltage (1067mm) 14¹⁄₄" Wire Access (362mm) 7¹⁄₂" 3³⁄₄" (191mm) (95mm) 14¹⁄₄" 3" 46" 6¹⁄₂" (362mm) (76mm) (1168mm) (165mm) Gas Line Access Fig. 2 ODGSR42A specification and framing dimensions. 7114 ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17 ODUVSR42A specs 11/03... -
Page 5: Moisture Resistance
A hearth is not mandatory but is recommended for aesthetic Side ............0” (0 mm) purposes. We recommend a noncombustible hearth. Back ............0” (0 mm) Perpendicular Sidewall ......0” (0 mm) Top of unit to ceiling ......36” (914 mm) Front of unit to combustibles .....36” (914 mm) ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17... -
Page 6: Moisture Resistance
When installed on surfaces where water may collect or cause damage: Outdoor Lifestyles recommends a slope of 1/8 in to 1/4 in per foot towards the drain port suggest- ed. The fireplace can be shimmed level. ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17... -
Page 7: Gas Specifications
(Fig. 5) 2. Lift the brick with the Outdoor Lifestyles logo on it. (Fig. ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17... -
Page 8: Exterior Chase Installation
Fig. 9 Exterior chase installation. 1/2" x 3/8" Shut-off Valve FP1416 3/8" Nipple ODUVSR part id 3/8" Union 11/24/03 djt 3/8" Nipple FP598 Fig. 10 Typical gas supply installation. GF598 ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17 nvb GAS SUPPLY INSTALL 12/4/97... -
Page 9: Remote Wall Switch
HV105 Fig. 11 Remote switch wiring. OPEN HV105 Generic Gas Valve MD706-7 Wrong Correct 9/22/99 djt Fig. 12 Correct door position during operation. MD706-7 Glass Door Position 1/20/99 ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17... -
Page 10: Operating Instructions
After each lighting, vapor may condense and fog 11/24/03 djt the glass; this moisture disappears in a few minutes Log Right of burning. Ember Log Left Ember Grate LG318 Fig. 14 ODGSR42A log placement. ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17... -
Page 11: Flame Adjustment
It is important to periodically perform a visual check of the FLAME ADJUSTMENT KNOB 12/4/97 11/21/96 pilot and the burner flames. Compare them to the illustra- tions below (Figs. 16, 17, 18). If any of the flames appear abnormal call a service person. Red Glow LG319 Fig. 17 ODGSR36A flame appearance. LG319 ODUVSR36 log flames 11/24/03 djt LG320 Fig. 18 ODGSR42A flame appearance. ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17... -
Page 12: Optional Weather Enclosures
Metal Screws 4/1/04 djt Sensor Plate Slot FP1635 Screen Fig. 21 Secure stainless steel hood with five (5) sheet metal screws. Hearth Brick FP1635 Valve Access Cover ODGSR hood 6/06 KT458 Fig. 20 Push bottom of weather enclosure into firebox. KT458 place we bottom 4/1/04 djt ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17... -
Page 13: Lighting & Operating Instructions
"OFF". Do not force. 2. Turn off all electric power to the fireplace if 5. Close control access panel. service is to be performed. ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17... -
Page 14: Troubleshooting
Wall switch is not turned on. Watch for grounded wires! Pilot Lights Main Thermopile needs a minimum Burner 325mV Plugged burner ori ce System OK FP396 NVC-standing pilot troubleshooting 5/6/98 FP396 ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17... -
Page 15: Maintenance
Typically, the top 3/8" or 1/2" of the thermopile should be engulfed in the pilot flame. (Fig. 16) To adjust pilot burner, turn pilot screw marked "pilot" for proper flame size. The air shutter is set at factory no adjustment should be necessary. ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17... - Page 16 20007158K 20007241K Right Hearth Brick* 20007157K 20007240K Piezo 057958 057958 12a. Pilot Top Convertible - Natural (3 Way Assembly) 10002264 10002264 12b. Pilot Top Convertible - LP (3 Way assembly) 10002265 10002265 Thermopile 18" 26D0566 26D0566 ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17...
-
Page 17: Replacement Parts
Model # ____________________________ 3. A description of the part. Serial # ____________________________ Should you need additional information beyond what your dealer can furnish, contact: Hearth & Home Technologies 7571 215th Street West, Lakeville, MN 50044 www.hearthnhome.com ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17... -
Page 18: Accessories
ODGSR Series Outdoor Gas Fireplace Accessories The following accessories are available from your local Outdoor Lifestyles Fireplaces distributor. Each accessory comes with a separate installation instruction for mounting to the particular firebox. Be sure to read each instruction thoroughly before installing. Accessory Description Model Number 4" Stainless Steel For heater up to 40,000 BTU's and mantels UV36SH4 Hood 8"... -
Page 19: Warranty
• This warranty is limited to the repair of or replacement of part(s) found ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 20007114 Rev. B • 09/17... - Page 20 Hearth & Home Technologies 7571 215th Street West, Lakeville, MN 50044 www.hearthnhome.com ODGSR36A/ODGSR42 Outdoor Fireplace Install Instructions • 2007114 Rev. A • 03/17...
