- Page 1 A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y O U T D O O R R E F R I G E R A T O R V T - R E F O U T 1 5 O W N E R ’...
-
Page 2: General Operating Instructions
Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged. Contact our customer service at 1-800-777-8466 or info@vinotemp.com. READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE - Save these instructions - W W W . -
Page 3: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..........4 ELECTRICAL CONNECTION ............5 CORD INSTRUCTIONS ..............5 PARTS AND SPECIFICATIONS ............6 TECHNICAL DATA ............... 6 INSTALLATION INSTRUCTIONS............. 7 OPERATING YOUR REFRIGERATOR ..........8 CARE AND MAINTENANCE ............9 TROUBLESHOOTING GUIDE ............10 TERMS AND CONDITIONS ............ -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electrical shock or injury when using your appliance, follow these basic precautions: • Do not operate this or any other appliance with a damaged cord. • Always unplug the appliance before performing any care or maintenance. •... -
Page 5: Electrical Connection
ELECTRICAL CONNECTION Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, frayed or shows cracks or abrasions across its length, have it replaced at an authorized service center. For your protection, this unit is equipped with a 3-conductor cord set that has a molded 3-prong grounding-type plug, and should be used in combination with a properly connected grounding- type outlet. -
Page 6: Parts And Specifications
PARTS AND SPECIFICATIONS TECHNICAL DATA Model No. VT-REFOUT15 Voltage AC 115V Frequency 60 Hz Rated Current 2.0A Input Power 150W Power Consumption 1.47kwh/24hr Refrigerant R134a, 1.94oz High/Low side pressure (psig) 190/90 Ambient Temperature Range 25°-100°F Control Temperature Range 35°- 50°F Capacity Approx. -
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS Before Using Your Unit • Remove all packing material before using your refrigerator. • Check to be sure the appliance is in good condition and that you have all of the following parts: o 3 chrome-plated wire shelves o 1 wire basket o 1 instruction manual •... -
Page 8: Operating Your Refrigerator
OPERATING YOUR REFRIGERATOR IMPORTANT: Before connecting your refrigerator to the power source, let the unit stand upright for 24 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. Controls The refrigerator has a rotary temperature control knob (thermostat) inside the unit featuring three primary settings (OFF-COLD-COLDEST), in order of increasing coldness. -
Page 9: Care And Maintenance
CARE AND MAINTENANCE IMPORTANT: Always unplug your refrigerator before cleaning or performing maintenance. Never use harsh cleansers or scouring pads to clean any part of the refrigerator. Cleaning the Refrigerator • Exterior: Use a cloth dampened with warm soapy water. Dry thoroughly with a soft cloth. To clean the door gasket, use only warm soapy water. -
Page 10: Troubleshooting Guide
PROBLEMS WITH YOUR REFRIGERATOR Most common problems can be solved easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before contacting Vinotemp at info@vinotemp.com. TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE •... -
Page 11: Terms And Conditions
Any claim for damages incurred during shipment by the carrier of the goods are insured and handled directly with the carrier and must be noted at time of delivery. Any damages due to manufacture defects will be handled directly with Vinotemp International, subject to the limited warranty. -
Page 12: Service & Important Notice
Rancho Dominguez, CA 90221 www.vinotemp.com Vinotemp is a registered trademark of Vinotemp International. All products, features, and services are subject to change without notice. We cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.
