FIRST:
1390/1400 DRIVER FROM
EPSON.COM
Thanks for Purchasing the Flatbed Inkjet Printer！
Thanks to your support, and we are congratulating you now owned an multifunctional and
powerful flatbed inkjet printer which with unlimited media surface printable, it's a high performance &
wide application range inkjet style almighty printing machine, and you can call it individuation fashion
printing machine.
The follow is some important suggestion about using method & security to this printer, we sincere
hope the printer in your hands could be applied with no any malfunctions and freely, wish you have
careful read to this Manual before using this printer, and be notice to the information about "Note" &
"Alarm" on this Manual.
And, please have good placement to this manual; it is the best guider for you and your employees
to operate this printer.
Security Notice
Avoid destroying this printer & having harm to the human body, you must obey this rule be
indicated on this part of "
including the important information of operating and the else, unless, if have something destructed to
this printer which did not obey the user manual, we will not perform the quality maintaining jobs.
Announcement
Along with the quality be improved, please kindly understand that we might not have something
be modified on this manual in future.
PLS
DOWNLOAD
Warn" on this manual, Please also care for the part of "
EPSON
Note"
Advertisement
Table of Contents
Related Manuals for Epson 1390
Summary of Contents for Epson 1390
- Page 1 FIRST: DOWNLOAD EPSON 1390/1400 DRIVER FROM EPSON.COM Thanks for Purchasing the Flatbed Inkjet Printer！ Thanks to your support, and we are congratulating you now owned an multifunctional and powerful flatbed inkjet printer which with unlimited media surface printable, it’s a high performance &...
- Page 2 Flatbed Inkjet Printer ２ Contents Chapter one． The Installation of the Flatbed Inkjet Printer Page 05~09 A．The preparative before Installation B．The Diagrammatize of the Components C．The Installation of the Printer D．The ink injection E． The installation of the Driver Chapter Two． Use to the Printer Page 10~21 A．Sketch map of the operation to this printer...
- Page 3 Flatbed Inkjet Printer ３ Chapter one． The Installation of the Flatbed Inkjet printer A．The preparative before installation to the Flatbed Inkjet Printer. 1．Please have good placement to the printer with a space with conditions for no dust, faraway to heat sources &...
- Page 4 Flatbed Inkjet Printer ４ 4．Lifting Range — The space of movement about the flatbed。 5．Maintain Cover — the door for maintaining the quality of the printer。 6．The slot of installing for Column device。 7．Control Panel — the panel for operating the printer。 8．Scrap ink collector —...
- Page 5 Flatbed Inkjet Printer ５ 3．Keep enough space up & down for the movement of the flatbed。 4．When the power of printer in status of OFF, please be careful to insert power cord to the jack. 5．Then please switch on the power in the rear of the printer, press the “down”...
- Page 6 Flatbed Inkjet Printer ６ 3. Pump depose ink Open the depose ink protecting windows, please take the depose ink duct from the ink bottle, connect it with the Injector, (please notice that the cartridge should be in position initialized), draw back the injector and keep it with less volume ink in the injector, after this, please recover the depose Ink duct back to the depose ink bottle.
- Page 7 Flatbed Inkjet Printer ７ 1．When you inject ink to the printer, please according the seriation No. on the bottle of the printer, avoiding dust & eyewinker to pollute the printer, please do the course in short time, unless, the dust & eyewinker might block the print-head。 2．The ink which be applied by this printer is special for LOGE Series flatbed printer，please do not use it for the other printer, and, please do not use the other brand ink for this printer, unless, it might have damaged to this printer.
- Page 8 Flatbed Inkjet Printer ８ There has three steps for operating to this printer： 1, Image Settings By digital camera, scanner and other devices to gain image, to set the image be gained by processing software on your computer. 2．Have coat processing to the surface of the printing object. 3．By image processing software to process the software and make the printing outputting.
- Page 9 Flatbed Inkjet Printer ９ Multifunction Button, use together with reset button & batch Button complex application. Multifunction Button, use together with reset button & Set Button for complex application. Direction button: Lifting the Flatbed Direction button: Drop the Flatbed Button for automatic control the height of Flatbed. Direction button: Move back the Flatbed Direction...
- Page 10 Flatbed Inkjet Printer １０ 3．Set to “Image Size” We can set the really printing image size outputting for width & height by documents size in menu, the max differentiate about the image could be set to 300dpi/inche, and the least could be set at 200dpi/inche，when you have this setting, the quality of the image for printing outputting should be better。...
- Page 11 Flatbed Inkjet Printer １１ 6． To finish the image enantiomorph, please select the fist option of menu for “file”>”printing preview”。 7．In the window of “Printing Preview”, click “Page Setting”。 8．In the window of “Page Setting”, finish the size setting, click ”printer”。 １１...
- Page 12 Flatbed Inkjet Printer １２ 9．In the window of “page setting”, click “property”。 10．We can set the printing quality by window” property”. and set the “Image type” with media at “inkjet back shot film”, model at “custom”。 11．Single click ”Advanced”, please set the “printing quality” to set the printing precision in window of “advanced”...
- Page 13 Flatbed Inkjet Printer １３ 12．Finish setting, single click” Ensure”>”Property” window, single click”Ensure” and get back to the windows of “printing preview” to finish the setting, ignore position “centered ”, have the setting about “position” for the image “top”, and set the data value of “left” to “0”, therefore, the printing position of the image would as below, and please single click”...
- Page 14 Flatbed Inkjet Printer １４ Note：before clicking” Ensure”，the position of flatbed should at ” initialized position”。 In chapter ”the correct way to use the flatbed printer”, we will indicate the way of setting the flatbed to initialized position。 D．The Correct way to use the printer. One．Operate the printer 1,Connect to power, turn on the switcher on the front panel of the printer, LCD display will turn on and display: ”wait for online”...
- Page 15 Flatbed Inkjet Printer １５ b、 Press the button of “input”, please stop moving of the flatbed when the printing object on flatbed has moved to the underside of the gauge。 c 、 Press the key” up” to let the flatbed reach to the best position as image right: d、press the key”input”...
- Page 16 Flatbed Inkjet Printer １６ machine with metal be blocked, and with liquid be polluted, please cut the power and repair the machine by professional person。 2．During printing, please put the print media on the initialized position, please adjust the height of the print head with scale at 1.50mm, before printing, please move the print-head to get back to initialized position。...
- Page 17 Flatbed Inkjet Printer １７ Finish, please move the print-head back to initialized position and start to print, if need to appoint the initialized position, please press the key ”cleaning” and lead the printer enter media loading situation, and adjust the columnar media on the top side of the devices。 F．The cleaning to print-head（Manual）...
- Page 18 Flatbed Inkjet Printer １８ Note：the “coat” be canned is with brume technology we can have direct spray to the surface of the media. for the bulk type, please use brush & dipping way to use it。 b．The Using way to the Bulk Coat (one)： 1．Empty the bulk coat to the container。...
- Page 19 Flatbed Inkjet Printer １９ 3．Sometimes to the edge of the object, there might with more liquid of the coat, you can repair it by blade before printing & after printing。 Note： 1．During the operating of processing coat, please avoid having over liquid on the object. 2．Please do not touch the coat before drying of the coat, avoid to interfere the printing quality, please also did not touch the coat after drying。...
- Page 20 Flatbed Inkjet Printer ２０ same to coat. C．Coat cleaning liquid 1．At the situation of printing outputting with dissatisfied effect, you might need to have clean job to the surface of the printing object and repeat to the printing outputting. At this situation, you need to have cleaning job to the print image by the Coat cleaning liquid。...
- Page 21 Flatbed Inkjet Printer ２１ 1, Start the image processing software adobe Photoshop。 2,Open the image be selected。 Some of the image with small size，we have to adjust the size by the tool of the processing software for increasing the value of size & differentiate rate, finished, the software will automatic create a new image with better quality after processing。...
- Page 22 Flatbed Inkjet Printer ２２ 7、Have free counterchange to the image, let the file have compatible size。 8、 We now take the same sample to design the image base on mobile phone panel, now check the size of the printing object, and put it on the appropriate position(to set it with distance to top at 0 + left 0)。...
- Page 23 Flatbed Inkjet Printer ２３ select the tool of Quadra to select the printing position。 In order to let the image with color on nature transition effect on printing object, we need to have eclosion processing to the image (on menu ” Select ”), the value of eclosion will depend on the size of the file &...
- Page 24 Flatbed Inkjet Printer ２４ And now we have finished the image processing, and you can print the image on the center position of the phone panel. 9、adjust image。 （the following steps is base on regulation situation, they are not necessary, and not just limited in these steps, during practicality application, it will depend on really situation）.
- Page 25 Flatbed Inkjet Printer ２５ D— adjust the acutance，for some image, it might with low definition, we can improve the acutance。 10、Optimize the image。 During real application, we can add font & image to optimize the image。 （1） 、add font: select the tool of “font”, and input the font。 （2）...
- Page 26 Flatbed Inkjet Printer ２６ （2）When the setting has been done, click “printing” button to enter print, and please confirm the name of the printer is 1290,if the quantity over 1 pc, please refer to the mentioned information on other chapter。 （3）Pleas click “property”...
- Page 27 Flatbed Inkjet Printer ２７ A．Color Control to the image Because the media is with different materials & Color, during application, we should has reasonable adjust to the image。 1．When we have printing job to the transparent object, the image should be adjusted with saturation at 15-30, and you can add the contrast at 30。...
- Page 28 Flatbed Inkjet Printer ２８ C．Other Function One．Set language on the displayer of the printer When the printer did not enter Online Status, press the Button of “Setting” to enter language selection, select the key at the left & right about ”Setting” to select, when them be done, repress setting to ensure &...
- Page 29 Flatbed Inkjet Printer ２９ B．Consumable Merchandise Information 1．Ink Name Spec. Code Professional ink-Cyan 150ml LGINK1 Professional ink- Magenta 150ml LGINK2 Professional ink -Yellow 150ml LGINK3 Professional ink-Black 150ml LGINK4 Professional ink –Light Cyan 150ml LGINK5 Professional ink –Light Magenta 150ml LGINK6 2．Coat Name...
