- Page 1 Digital Audio Baby Monitor User’s Manual Manuel d'utilisation Benutzerhandbuch Manual del Usuario Manuale utente...
-
Page 3: Table Of Contents
ontents Legend of functions Parent unit Baby unit What you get What else you need Important information Setting up Set up the baby unit Power supply Set up the parent unit Power supply Belt clip Check the connection Using the baby monitor Adjust volume Mute function Talk back... -
Page 4: Legend Of Functions
Legend of functions A, Parent unit Fig. 1 Mute button Link / Unlink indicator LED Talk back button Sound level light Link Power Volume / VOX sensitivity control Power / charging indicator LED ON/OFF button Belt clip Battery compartment Power adapter jack for the charger Link Power... -
Page 5: Baby Unit
Legend of functions B, Baby unit Fig. 2 Link / Unlink indicator LED Night light Night light ON/OFF button Volume control Power / Battery low indicator LED ON/OFF button Power adapter jack Battery compartment cover lock Battery compartment... -
Page 6: What You Get
What you get Baby unit Baby unit mains power adapter Parent unit Parent unit mains power adapter 2 x AAA rechargeable batteries for the parent unit Parent unit charger Belt clip for the parent unit This user ’s manual What else you need 4 x AA non rechargeable batteries (Alkaline recommended) batteries for the baby unit (not supplied). -
Page 7: Important Information
Important information Please read this user’s manual carefully be- fore using your baby monitor and keep it for future reference. This baby monitor is designed as an aid and should not be used as a substitute for responsible and proper adult supervision. - Page 8 Important information If travelling abroad, make sure that the voltage shown on the mains power adapter corresponds to the local mains power before connection to the power supply. To prevent electric shock, do not open the case of the baby unit and the parent unit (except bat- tery compartment covers).
-
Page 9: Setting Up
Setting up 1. Set up the baby unit ON/OFF 1.1 Power supply The baby unit uses either four AA Alkaline batteries or household AC current. Mains operation 1. Plug the mains power cable into the socket on the side of the baby unit. 2. - Page 10 Setting up Battery operation The baby unit also works on battery power, so that you can use it even when you are away from a mains power socket or during a power cut. 1. Remove the battery compartment cover and insert 4 x AA Alkaline batteries into the battery compartment on the baby unit, then close the battery compartment cover.
-
Page 11: Set Up The Parent Unit
Setting up 2. Set up the parent unit 2.1 Power supply The parent unit uses 2 rechargeable batteries. 2 x AAA rechargeable batteries for parent unit Battery operation 1. Remove the battery compartment cover and insert 2 x AAA rechargeable batteries into the battery compartment, then close the battery compartment cover as shown. - Page 12 Setting up Note 1: Even the parent unit is not placed on the charger, the charger light would always light up in red. 2: Insert the rechargeable batteries before charging the parent unit. 3: When the parent unit which does not contain, rechargeable batteries is plug into the charger, the parent unit will turn on the power about 3-5 seconds and then power off .
-
Page 13: Belt Clip
Setting up 2.2 Belt clip You can use the belt clip to carry the parent unit on the belt. You can use the belt clip to carry the parent unit on the belt. 3. Check the connection When both units are switched on, the green link indicator lights on both units will be on. -
Page 14: Using The Baby Monitor
Using the baby monitor Position both units in the same room to test the connection. Make sure the baby unit is at least 1 M/ 3 feet 1 meter / 3 feet away from the parent unit. Note: If you put the parent and baby units too close you will hear a high pitched noise, this is normal. -
Page 15: Mute Function
Using the baby monitor 2. Mute mode and microphone sensitivity level setting To set the sensitivity level, follow these steps: Press Mute button on the parent unit, then press – within 3 seconds to select the sensitivity level required- level 1 for Low sensitivity, or level 5 for High sensitivity (Default setting is level 3). -
Page 16: Night Light
Using the baby monitor 4. Night light The night light provides a soft and comforting glow for your baby and allows you to check on the baby without having to turn on the main room light. Press the Light button on the baby unit. Press again to switch it off. 5. -
Page 17: Troubleshooting
Troubleshooting Power lights do not turn on: If using the mains power adapters, make sure they are plugged in and switched on. If using batteries, check they are correctly installed. Link light does not turn on: Check that both the baby unit and parent units are switched on. If using batteries, check they are correctly installed. -
Page 18: Frequently Asked Questions
Frequently asked questions uestions nswer The technical specifications show an operat- The specified range is only valid outdoors ing range of 300 meters / 900 feet outdoors. in open air. Inside your house the coverage How come my baby monitor manages much range is limited by the amount and type of the less than that? walls and/or ceilings in between.
