Summary of Contents for A&D UT-302PBT
- Page 1 DIGITAL BLUETOOTH THEROMETER...
-
Page 2: Table Of Contents
Index Introduction Important Information Before Use Product Identification Description of LCD Display Battery Installation Changing Modes (°C/°F Switchable) Tips for Measuring Human Temperature Measuring Body Temperature in the Ear Memory Function Operating The Bluetooth Function Care and Maintenance Applied Standards Error Codes Technical Specifications FCC Statement... -
Page 3: Introduction
Introduction Utilizing infrared technology, this thermometer takes temperatures in seconds by measuring heat generated by the ear canal or other objects . This product conforms to the provisions of the EC directive MDD(93/42/EEC).Its advantages include: 1. Wireless communication : Bluetooth (class 2) 2. -
Page 4: Important Information Before Use
Important Information Before Use When using this product, please be sure to follow all the notes listed below. Any action against these notices may cause injury or affect the accuracy. 1. Do not disassemble, repair, or remodel the thermometer. 2. Be sure to clean the thermometer lens each time after usage. -
Page 5: Product Identification
Product Identification Probe Tip LED (Wireless connecting indicator) Wireless Reset Key Power & Wireless Power Button Measure MEMORY Button Recall Button Display Battery compartment Description of LCD Display Degrees of Temperature Memory Symbol Celsius and Sets of Scale Records Fahrenheit Scale Scan in Smiling face... -
Page 6: Battery Installation
Battery Installation Low battery warning: When the battery power becomes low, the low battery symbol “ ” will appear on the display. The thermometer can still be used during this time, but the batteries should be replaced as soon as possible. If the batteries run out completely, “Lo” will be displayed along with the low battery symbol. -
Page 7: Changing Modes (°C/°F Switchable)
Changing Modes (°C/°F Switchable ) This thermometer can display result in either degrees Fahrenheit(°F) or degrees Celsius(°C). Changing °C/ °F, please make sure the device is in power on condition. Press the Power/Scan button, hold it, and then press the Memory button to toggle between °C and °F. -
Page 8: Tips For Measuring Human Temperature
Tips for Measuring Human Temperature Bear in mind that the thermometer needs to have been in the room in which the measurement is taken for at least 30 minutes before use. • Some people produce different readings in their left and right ear. -
Page 9: Measuring Body Temperature In The Ear
Measuring Body Temperature in the Ear 1. Remove the front cover: Remove the cover cap: Remove the cap by gently pushing it up (1) and then pulling it off forwards (2). 2. Press the Power button to switch the thermometer on. - Page 10 Measuring Body Temperature in the Ear • Under 1 year: Have child lay flat with the head sideways, so that the ear is facing upwards. Gently pull the ear straight back. • 1 year +: Stand behind and slightly to the side of the child/adult.
- Page 11 Measuring Body Temperature in the Ear The Readings: If the temperature measurement is below 38°C, a “Smiling Face ” will be appear next to the reading. If the reading is 38°C or above, a “Frowning Face ” will be displayed.
-
Page 12: Memory Function
Memory Function Memory Recall: You can recall up to 10 measurements of all currently stored measurements in memory to share with your physician or trained healthcare professional. 1. While in power on mode, press once briefly on the “Memory” button, then pass it again to show the last measurement accompanied by “... -
Page 13: Operating The Bluetooth Function
Operating The Bluetooth Function 1. Turn the ear thermometer to the back side. 2. Turn on the wireless power (From "off" to "on"), while the thermometer searches for other Bluetooth compatible devices, the LED (connection indicator) will flash. When the device connects successfully to health monitoring devices and Bluetooth-capable devices, such as a computer, PDA, or mobile phone, the LED will remain lit. - Page 14 Operating The Bluetooth Function What You Need: The host computer or terminal system to run Serial Port Profile (SPP) - A personal computer with Operating system: Windows 95 or later - A Smart Phone with Android system - Others: PDA, etc. Please refer to the instruction manual of your personal computer for how to install Serial Port Profile (SPP).
- Page 15 Operating The Bluetooth Function Communications Interface: Using Bluetooth communications terms, the UT-302PBT is a slave device. To connect the UT-302PBT to a master device you must initiate the connection by first pairing with the UT-302PBT. To complete the pairing process the “0000” number must be provided to the master as the Bluetooth Pass Key (Bluetooth PIN Code).
-
Page 16: Care And Maintenance
Care and Maintenance • Probe and Tip: Clean the probe and tip with an alcohol swab before and after each measurement. • Thermometer: Use a soft, dry cloth to clean thermometer body. Never use abrasive cleaning agents, thinners or benzene for cleaning. Do not scratch the surface of the probe lens or the display. -
Page 17: Error Codes
Error Codes When a malfunction or incorrect temperature measurement occurs, an error message will appear as described below. LCD Display Cause Solution Operate the thermometer The temperature measured is only between the lower than 34°C (93.2°F) specified temperature ranges. If necessary, clean the sensor tip. -
Page 18: Fcc Statement
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 19 FCC Statement 6. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 20: Emc Tables
EMC Tables Guidance and manufacturer's declaration-electromagnetic emission UT-302PBT Thermometer intended for use in the electromagnetic environment specified below. The customer or the user of the UT-302PBT Thermometer should assure that it is used in such an environment. Emissions test Compliance... - Page 21 EMC Tables Guidance and manufacturer's declaration-electromagnetic immunity UT-302PBT Thermometer is intended for use in the electromagnetic environment specified below. The customer or the user of the UT-302PBT Thermometer should assure that it is used in such an environment Immunity IEC 60601 test...
- Page 22 EMC Tables Recommended separation distances between portable and mobile RF communications equipment and the UT-302PBT Thermometer UT-302PBT Thermometer monitor is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the...
- Page 23 This device includes RF transmitter (with wireless communication)
- Page 24 A&D Company, Limited 1-243 Asahi, Kitamoto-shi, Saitama 364-8585 JAPAN Telephone: [81](48)593-1111 Fax: [81](48)593-1119 A&D INSTRUMENTS LTD. Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44](1235)550420 Fax: [44](1235)550485 A&D ENGINEERING, INC. 1756 Automation Parkway, San Jose, California 95131 USA Telephone: [1](408)263-5333 Fax: [1](408)263-0119 A&D AUSTRALASIA PTY.LTD.
