  • Page 1 Ear Thermometer UT-101 Instruction Manual UT-101AEX-C WM+PD4000231C...

  • Page 2: Dear Customers

    Dear Customers Congratulations. You have purchased an A&D ear thermometer, one of the most technologically advanced yet easy to use products available in the marketplace today. We strongly recommend you read this instruction manual carefully prior to using the thermometer the first time. General Information Patient population The device is intended for use by adult, pediatric and neonatal patients.
  • Page 3 Precautions 1. Precision components were used in the construction of this device. Extremes in temperature, humidity, direct sunlight, shock or dust should be avoided. 2. Clean the device with a dry, soft cloth or cloth moistened in alcohol. Never use thinner, benzine or cleaner with abrasives.

  • Page 4: Parts Identification

    Parts Identification...
  • Page 5 Symbols Symbols Function / Meaning Action Start button Battery installation guide Serial number Date of manufacture Type BF: Device is designed to provide special protection against electrical shocks. LOW BATTERY mark Replace all batteries with new ones. Appears when the batteries are drained. (Begins to flash when the battery voltage has become low.
  • Page 6 Symbols –continued- Symbols Function / Meaning Action MEMORY mark Previous measurement stored in memory. Appears if the measuring room Move the thermometer to temperature is 40.1 or over. a room with a room temperature of 25 Appears if the measuring room leave it there for an hour.

  • Page 7: One Touch Operation

    Features Easy to use friendly design The pen-type design allows easy handling and very convenient carrying and storage. Can easily measure a baby’s temperature even during sleep. One touch operation When you press the START button once, the thermometer is ready to measure your temperature.
  • Page 8 Using the Ear Thermometer Before Using the Thermometer Caution Keep this device out of the reach of children. A child may swallow the probe cover while playing with it. If a child should swallow it, seek medical treatment immediately. Use the thermometer at a room temperature between 5 and 40 . If the thermometer is stored in an environment with the temperature out of the above range or the temperature of the storage area differs greatly from that of the measuring area, allow the thermometer to equalize to the room...
  • Page 9 Install the probe cover on the probe tip. (A probe cover was installed at time of purchase.) Install the probe cover on the probe tip. Inserting the Thermometer into the Ear Caution Do not force the thermometer into your ear. Insert the thermometer straight into the ear canal.
  • Page 10 Using proper posture When measuring your own temperature: Raise and hold your left hand as shown to the right to pull on your ear. Hold the thermometer in your right hand and insert it into your right ear. (Reverse this when measuring your temperature in the left ear.) When measuring a child’s temperature: Hold the child’s head so that it will not move.

  • Page 11: Measuring Temperature

    Measuring Temperature Caution Do not use the thermometer for purposes other than measuring temperature in the ear. Stop using the thermometer immediately if your ear hurts, looks or feels unusual. 1. Check the following. Is the probe tip clean? Has the probe cover been installed? (See “Before Using the Thermometer”...
  • Page 12 3. Insert the thermometer into the ear. Insert the thermometer gently into the ear. Always insert the thermometer into the same ear with the same direction and depth. (See “Inserting the Thermometer into the Ear” on pages 9 and 10.) Press the start button.

  • Page 13: Switching The Unit Of Measure

    Switching the Unit of Measure With the UT-101, two units of measure are available for use, Celsius and Fahrenheit. The displayed unit can be changed using the following steps. 1. Press and hold the START button for about seven seconds when the liquid crystal does not display anything.
  • Page 14 Taking Care of the Thermometer Cleaning Caution The thermometer is not water resistant. Protect it from liquid spills. Do not wash it in water. Main unit Lightly wipe using a dry, soft cloth. Do not use thinner, benzine or cleaner with abrasives. Probe tip / Probe cover Lightly wipe using a dry, soft cloth or cloth moistened in alcohol after each measurement.

  • Page 15: Replacing The Batteries

    Replacing the Batteries Caution Keep the thermometer out of the reach of children. A child may swallow the battery while playing with it. If a child should swallow the battery, seek medical treatment immediately. 1. Using a Phillips screwdriver, loosen the screw holding the battery cover and remove the battery cover.
  • Page 16 Notes 1. When the LOW BATTERY mark ( ) appears in the display, replace all batteries with new ones. Do not mix old and new batteries. Doing so could shorten the battery life or cause the device to malfunction. 2. Battery life varies with the room temperature and may be shorter at low temperatures.

  • Page 17: Body Temperature

    About Ear Temperature Body temperature The body temperature refers to the core temperature. This core body temperature can be obtained quickly and accurately by measuring the temperature of the eardrum, because it is believed that the temperature of the eardrum constantly and accurately reflects changes in temperature of the thermoregulatory center, or hypothalamus, in the brain.
  • Page 18 Why can the temperature be measured in the ear Every object emits infrared energy that corresponds to its temperature. Therefore, the temperature of an object can be obtained by measuring the amount of the infrared energy. The ear thermometer employs this theory and detects the radiated heat out of the eardrum using an infrared sensor.

  • Page 19: Frequently Asked Questions

    Frequently Asked Questions Q.The reading is different each time I measure my temperature. Why is that? A. The following may be the cause: You insert the probe into the ear in a different way (direction, depth or different ear) each time. The probe tip is not clean.
  • Page 20 Q. Why is the reading taken in the right ear different from that taken in the left ear? A. Basically the temperature is the same in both ears, but the values may differ because the shape of each ear interior is different.

  • Page 21: Troubleshooting

    Troubleshooting Problem Probable cause Corrective action Nothing appears in Batteries are drained. Replace all batteries with the display, even new ones. when the power is Battery terminals are not in Place the battery terminals turned on. the correct position. correctly. The LOW BATTERY Batteries are drained.

  • Page 22: Maintenance

    Maintenance Do not open the device. It uses delicate electronic components that could be damaged. If you cannot fix the problem using the troubleshooting instructions, request service from your supplier or from the A&D service group. The A&D service group will provide technical information, spare parts and units to authorized suppliers.

  • Page 23: Technical Data

    Technical Data This device conforms to the European Directive 93/42/EEC for Medical Products. This is evidenced by the CE mark of conformity accompanied by the reference number of a designated authority. Type UT-101A Temperature sensor Thermopile sensor Measurement range to 42.2 Measurement accuracy (In the temperature range from 36 to 39 ,...
