- Page 1 Ear Thermometer Model UT-601 Instruction Manual Original ’ Manuel d instructions Manual de Instrucciones Manuale di Istruzioni 使用手冊 1WMPD4002420...
-
Page 2: Table Of Contents
Contents Dear Customers ..............2 Preliminary Remarks............. 2 Precautions ................2 Parts Identification ............... 3 Symbols ................4 Features ................5 Using the Thermometer............6 Installing / Changing the Batteries ........6 Measuring Ear Temperature..........7 Measuring the Temperature of Liquid or Solid Objects..8 Measuring Air Temperature .......... -
Page 3: Dear Customers
Dear Customers Congratulations on purchasing a state-of-the-art A&D ear thermometer, one of the most advanced thermometers available today. We recommend that you read through this manual carefully before using the device for the first time. Preliminary Remarks This device conforms to the European Directive 93/42 EEC for Medical Products. -
Page 4: Parts Identification
Parts Identification Probe cover Detection probe button with mark On/Scan Battery cover Battery cover latch Part of Display MEMORY mark Scanning in progress Low battery mark Unit of temperature Select before measurement Temperature reading English... -
Page 5: Symbols
Symbols Symbols Function / Meaning Recommended Action Standby and Power on. Direct current Serial number Date of manufacture Type B: The device is designed to provide special protection against electrical shocks. Last reading stored in MEMORY. The thermometer will automatically turn off after 30 seconds of no operation When appears: The battery is Replace both batteries with... -
Page 6: Features
Features The UT-601 Ear Thermometer is a multi-use thermometer. It detects body temperature from the ear canal. It can also detect the temperature of solids, liquids or air in a fast and non-contact manner. The thermometer measures the infrared heat generated by the eardrum or other objects. -
Page 7: Using The Thermometer
Using the Thermometer Installing / Changing the Batteries 1. Use a small pointed object such as a ballpoint pen to press the battery cover latch and release the latch. 2. Remove the battery cover by pushing the sides of the cover upward while pressing the battery cover latch. -
Page 8: Measuring Ear Temperature
Using the Thermometer Measuring Ear Temperature 1. Press the button to turn the On/Scan thermometer on. All the display segments appear. Note: The thermometer will turn off automatically after 30 seconds of no operation. When turned on 2. Select the unit of measure as necessary. While all the display segments appear, press and hold the button to toggle between °C... -
Page 9: Measuring The Temperature Of Liquid Or Solid Objects
Using the Thermometer Measuring the Temperature of Liquid or Solid Objects Note: The display temperature range is 0 °C to 100 °C. If the temperature of the object is out of the range, an error, HI or Lo, appears. 1. Press the button to turn the thermometer on. -
Page 10: Troubleshooting
Troubleshooting Problem Possible Reason Recommended Action Replace both batteries with new Batteries are drained. Nothing appears ones. on the display, Reinstall the batteries with even when the Battery terminals are negative and positive terminals button On/Scan not in the correct matching those indicated on the is pressed. -
Page 11: Maintenance
If at any time you question the accuracy of measurement, please contact your dealer or the A&D service group. Technical Data Type UT-601 Display temperature range 0 °C to 100 °C (32 °F to 212 °F) Display resolution 0.1 °C or 0.1 °F Measurement accuracy (In an ambient temperature of 16 °C to 35 °C) -
Page 12: Calibration Checks-Testing Instructions
Calibration Checks-Testing Instructions For trained specialist staff only Calibration checks must be performed by the following institutioins or persons: Manufacturer Trade measurements authorities Persons who fulfil the requirements of the legislation governing the operation of medical devices. (A) Function testing Function testing of the thermometer can only be carried out on a person or with a suitable simulator. - Page 13 1-243 Asahi, Kitamoto-shi, Saitama 364-8585 JAPAN Telephone: [81] (48) 593-1111 Fax: [81] (48) 593-1119 A&D INSTRUMENTS LTD. Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420 Fax: [44] (1235) 550485 A&D ENGINEERING, INC. 1756 Automation Parkway, San Jose, California 95131 U.S.A.
