Manual Data Storage Mode
The Model 42580 can store 99 readings in each of 4 sets numbered #1 through #4. The
function of the buttons in the Manual Datalogging mode are:
Opens the manual data storage mode, Opens a set and clears the data.
Selects the set # for recording or viewing.
Prints the stored records in a set.
Scroll up or down through the records in a set.
Stores the temperature reading.
1 to Z Alpha-numeric label entry (9 buttons).
1. Press the
storage mode. A cursor (11111111) will appear
next to the selected set# with the label (if stored).
2. Press the
one of the four sets.
3. If data is stored in the set, the label or the date and
time will appear next to the record number.
4. Press again to open the selected set.
5. The Set Screen will open with the cursor on the first
record number that does not contain any data. Data
can now be viewed, printed or new data can be
saved to the set.
6. Press the
Manual logging mode.
Storing Data
1. Point the meter at the surface to be measured.
2. Press and Hold the
3. Release the
4. For each set up to 99 readings can be stored.
Viewing Data
Press the
Printing Data
Press the button and the display will respond with Print?. Press the
a second time to confirm the print request. The printer will print all the records from record
01 to the last record that contains data.
Erasing Data
Press and HOLD the
erased. To clear the date and time (or stored labels) Press and HOLD the
for at least three second while in the Manual logging Mode Main Screen.
button to enter the manual data
button to scroll through and select
button a third time to EXIT the
button until a reading appears on the display in a box.
button and press the
buttons to scroll through and view the stored data.
button for at least three seconds and the recorded data will be
#1 User Defined Label
01: 07-11
02: 07-11
03:
04:
05:
Manual logging Screen
#2
01: 07-14
79.9
02:
----. --
03:
----. --
07-14-03
Manual logging Open Set Screen
button.
6
13:55:25
14:05:03
13:55:25
o
F
o
F
o
F
10:11:51
button
button
Model 42580 Version 2.2 11/03
