User Manual
EP902
Digital 2-Line Long Range Cordless System
EnGenius Customer Service
Singapore: 65-62271088, http://www.engeniustech.com.sg/

Table of Contents

Safety Instructions .................................................................................... 4
General Safety Instructions ................................................................... 4
Product Safety Instructions ................................................................... 5
Battery Safety Instructions .................................................................... 7
Regulatory Information ............................................................................. 8
Equipment Checklist ............................................................................... 10
Handset Illustration ................................................................................. 11
Handset Features .................................................................................... 12
Basic Handset Features ....................................................................... 12
Additional Handset Features ............................................................... 14
Base Illustration ...................................................................................... 21
Base unit Diagram ............................................................................... 21
Base Features.......................................................................................... 22
Basic Base Station Features ................................................................. 22
Charger Illustration ................................................................................. 23
Charger Features ..................................................................................... 24
Getting Started ....................................................................................... 25
Base Station Installation ...................................................................... 25
Handset and Charger Installation ........................................................ 27
Basic Operations ..................................................................................... 28
Operation Modes ................................................................................ 28
A. Base Operation Modes ................................................................ 28
B. Handset Operation Modes .......................................................... 28
Making a Telephone Call ..................................................................... 30
Making an 2-Way/ Intercom Call ......................................................... 30
Making a Broadcast ............................................................................ 31
Handset to Handset Calls ................................................................ 31
Redial ................................................................................................. 32
Receiving a Telephone Call .................................................................. 32
Receiving an Intercom Call .................................................................. 33
Ending a Call ....................................................................................... 34
Adjusting Handset Speakerphone Voice Volume ................................. 34
Placing a Call On Hold ......................................................................... 34
Mute ................................................................................................... 35
~2~

Advertisement

Table of Contents
loading

Related Manuals for EnGenius EP902

Summary of Contents for EnGenius EP902

  • Page 1: Table Of Contents

    Receiving a Telephone Call ..............32 Receiving an Intercom Call ..............33 Ending a Call ..................34 Adjusting Handset Receiver (Earpiece) Voice Volume ......34 EnGenius Customer Service Adjusting Handset Speakerphone Voice Volume ......... 34 Singapore: 65-62271088, http://www.engeniustech.com.sg/ Placing a Call On Hold ................. 34...

  • Page 2: Safety Instructions

    Do Not Disturb (Silent Ring) ..............35 Safety Instructions Key Guard ................... 35 Battery Recharge and Replacement ............ 36 Caution: Your wireless telephone gives you freedom and flexibility to stay in touch while you move around. However, when using your phone equipment, Advanced Operations ................

  • Page 3: Product Safety Instructions

    Product Safety Instructions 13. Avoid using the product during a storm. There may be a risk of electric shock from lightning. 1. Read and understand all instructions. 14. Do not place the product where persons can step, trip, or fall on it. 2.

  • Page 4: Battery Safety Instructions

    Regulatory Information 1. Use only manufacturer approved Li-ion rechargeable batteries and charger. Do not use other types of rechargeable batteries or non-rechargeable batteries. EP902 0560 The batteries could short-circuit, and the battery enclosure may be damaged causing a hazardous condition.

  • Page 5: Equipment Checklist

    Equipment Checklist electronic devices, which can be determined by turning the system off and on, the user is encouraged to try to correct the interference by one or several of the following measures: We recommend at least 20 feet between the system and other electronic In a Base + Handset package, please find the following components: devices.

  • Page 6: Handset Illustration

    Handset Illustration Handset Features Basic Handset Features Antenna 4-line LCD (Liquid Crystal Display) a. The LCD display has LED (Light Emitting Diode) for backlighting. b. The 1 line of LCD consists of icons. Icons explanation from left to right RSSI level (Receive Signal Strength Indicator) Receiver During a call, the number of bars is proportional to the radio signal strength received.

  • Page 7: Additional Handset Features

    The last line displays the left and right soft keys. ) /Down( ) Scrolling Keys a. Scroll through records and menu selections. b. Adjust receiver voice volume when in the Talk mode. Ringer a. Rings to an incoming call and intercom call. Press to enter received call log when in the Standby mode.
  • Page 8 available lines before making an outgoing call. DND (Do Not Disturb, i.e., Silent Ring) b-3. Predefine line: A handset will be set a specific line for making an Call Logs outgoing call. Redial: Stores 10 phone numbers (up to 26 digits each) dialed most recently.
  • Page 9 Dial from display. 21. Custom Name During the stand-by mode, you can enter the phone book by pressing Allow changing the “EP902” screen to the desired wording or info, such as scrolling key. the user’s name. Phone book transfer via air Re: Up to 32 characters can be entered.
  • Page 10 Allow changing the base PIN which requires entering the “Base Settings” (MENU-6-5). 33. Headset Ring Using registered handset to change PIN from MENU-6-5. Allow changing the ringer emitted either from handset speaker or receiver of b. Default PIN is “0000”. headset.

  • Page 11: Base Illustration

    Connect to an external device for music on hold Console jack Power/Line-1/Line-2 Jack for firmware upgrade (Type-B USB connector) Re: Please consult with EnGenius Tech support about the firmware upgrade. DC In: to plug in the power adaptor ~21~ ~22~...

  • Page 12: Charger Illustration

    Charger Features Charger Illustration DC In Connects to Charger AC Adaptor. DC In Handset Charging Slot Charge handset battery when handset is placed in cradle. b. Refer to the handset LCD for charging status (1) Charging: battery status bar is running and the LCD screen showed: “Charging”.

  • Page 13: Getting Started

    Getting Started Base Station Installation Mounting There are three possible base station setups: Base station alone Points Base station plus telephone answering device Base station plus standard telephone For best performance, maintain at least a distance of 1 meter (about 3 feet) between the base station and other electronic devices (e.g., TV, computer, stereo, fax machine, answer machine, cordless phone, etc.) Install base station antenna.

  • Page 14: Handset And Charger Installation

    Handset and Charger Installation Basic Operations Plug the transformer end of the Charger AC/DC adaptor into a standard AC Operation Modes electric power outlet, plug the other end into the “DC In” jack on the back of the Charger. Both the base station and handset have levels of operation at which time only certain procedures of functions can be performed.

  • Page 15: Making A Telephone Call

    A call duration timer will start displaying the length of the call after link is established. Making an 2-Way/ Intercom Call The EP902 Cordless Phone System offers private, Intercom/ 2-way radio calls independence of base station. Intercom/ 2-way communication can be placedbetween handsets.

  • Page 16: Making A Broadcast

    Re: the initiating handset press and hold the key is needed 1. Press key followed by a two-digit handset ID or during the speaking or broadcasting. Group ID. c. Release key to end the broadcasting. Press key to end the call. 3.

  • Page 17: Receiving An Intercom Call

    the current call. 2. If the handset is on the charger cradle (ringer will be temporarily switched to “Ring” if it has been set to Ending a Call “Vibrate”), lift the handset and press key to start conversation. To end a telephone or intercom call, press key, or place handset into charger Re: You can turn on the “Any Key Talk”...

  • Page 18: Mute

    Notes: 3. Once returning back to standby mode for 15 seconds, the Handset LCD displays a call is being on hold. An alert tone (double beep) every 30 seconds will remind the handset that a call is being on keyguard will be automatically enabled. hold.

  • Page 19: Advanced Operations

    Advanced Operations de-registration process. Upon successful de- registration, the handset display will show ”Please register”. Handset Registration Notes: If your handset(s) is purchased as part of a system, it has been pre-registered The base station has a 30 second registration timeout starting from with the base station at the factory.

  • Page 20: Call Transfer

    automatically. Notes: The handset can change group affiliations at any time. After the call transferred to destination handset, the original The base station is not responsible for group assignments. handset will go back to standby mode automatically. Consequently, it cannot de-subscribe a handset from a group. When an intercom caller enters a group ID, all handsets subscribed to Notes: If the destination handset does not answer after handset paging or this group will ring.

  • Page 21: Call Park

    Call Park DELETE (Right) soft key to delete the last digit entered. When completed, press SAVE (Left) soft key to save. Re: Up to 16 characters can be entered as the name. While a telephone call is in progress, you can place call on hold and pick this phone line by another handset.
  • Page 22 For phone sending party, press to enter sending mode. looking for. i. Either press ALL(Left) soft key to transfer all phonebook entries to For example, you are looking for “EnGenius”, and then press the number another handset(s). once. ii. Or press TX ONE (Right) soft key to transfer one entry to another d.

  • Page 23: Programmable Feature Call

    Press the correspondence number of the feature call 1. If EP902 base station is installed behind a PBX system, it is feasible to pre- which you want to perform i.e. press “0” to perform program some feature call along with the PBX’s feature code into the system.

  • Page 24: Multi-Base Setting

    Multi-Base Setting 3. When viewing a call record, the number can be dialed, stored to the phonebook or deleted. “Multi-Base” setting allows expanding coverage or lining capacity. When adding 2 or 4 base station, using one of the handsets which registered to the 1 base View Call Log station (i.e.

  • Page 25: Call Manager

    CHANGE left soft key to set the Subscribe BS ON/OFF. Call Manager Note: If set the Subscribe BS ON, that means the handset is able to access the line of the desired base station, so the handset is able to make outgoing call or “Call Manager”...

  • Page 26: Outgoing

    edited by pressing CHANGE (Left) soft key and followed key to select line 1 or line 2. Press by digit , 2, & & to select the line or line CHANGE (Left) soft key to change the dedication sequence for outgoing call. handset or group or all handsets.

  • Page 27: Visual Message Waiting Indicator (Vmwi)

    When using headset, to avoid missing the call due to the ringer emitted from b. Press OPTION (Right) soft key to delete or edit the Call Barring codes. receiver of headset, you can change the ringer emitting from either handset Up to 5 sets of Call Barring codes can be programmed.
  • Page 28 Menu Operations 1. Press MENU right soft key to enter menu mode while the phone is in standby mode. Re: You can either press , followed by SELECT left soft key to confirm the selected menu. Or Press the digit directly to confirm the selected menu.
  • Page 29 Re: Once entering the custom name, the greeting of LCD in standby mode will be changed as the entering. Re: When set “on”, press any key (except SILENT key) to answer the incoming call. Default greeting is “EP902”. Press to Change Password: ~57~ ~58~...
  • Page 30 CHANGE left soft key to select and confirm on or off. The Re: When setting “on”, the EP902 will automatically hang up if the far end caller hung up already. However, this function depends on if there is “dial tone or busy tone” signal sent out by PBX or PSTN, after the call hung up.

  • Page 31: Index

    Index De-registration, 36 2-WAY INTERCOM, 13 Direct transfer, 38 DND, 15 3-Way Conferencing, 39 Do Not Disturb (Silent Ring), 34 DTMF Duration, 18, 58 Adjust Handset Microphone Gain, 52 Adjust Headset, 52 electric shock, 4, 5, 6 Adjusting Handset Receiver (Earpiece) Voice Volume, 33 Emergency, 4 Adjusting Handset Speakerphone Voice Volume, 33 Equipment Checklist, 10...
  • Page 32 Menu Display, 17, 18, 59 Technical Specifications, 64 MENU mode, 27 transformer, 25, 26 Multi-Base Setting, 47 Multiple Base setting, 19 Vibrator, 14 Multiple handsets registration, 14 View Call Log, 46 Mute, 16, 34 Visual Message Waiting Indicator, 52 Name tagging with caller ID, 14 warning message, 24 Outdoor Antenna, 10 Outgoing, 15, 48, 50...
  • Page 33 Technical Specifications Electrical Specifications Base Station Portable Handset Frequency 863-865 MHz 863-865 MHz Peak: 8 dBm Peak: 8 dBm RF Output Power Average: 5 dBm Average: 5 dBm Channel Spacing 150 kHz 150 kHz Number of Channels Modulation GMSK GMSK TDD Frame Length 10 ms 10 ms...
