User Manual
Durable, Long-Range Cordless Phone
EnGenius Customer Service
http://www.engeniustech.com/
Table of Contents
Safety Instructions ........................................................................................ 5
General Safety Instructions ...................................................................... 5
Product Safety Instructions ...................................................................... 5
Battery Safety Instructions ...................................................................... 7
Regulatory Information ................................................................................ 8
Equipment Checklist ................................................................................... 11
Handset Illustration .................................................................................... 12
Basic Handset Features .......................................................................... 13
Additional Handset Features ................................................................. 15
Base Illustration ..................................................................................... 21
Base Features ............................................................................................. 22
Basic Base Station Features ................................................................... 22
Charger Illustration .................................................................................... 23
Charger Features ........................................................................................ 24
Getting Started ........................................................................................... 25
Base Station Installation ........................................................................ 25
Handset and Charger Installation .......................................................... 26
Basic Operations ......................................................................................... 27
Operation Modes ................................................................................... 27
A. Base Operation Modes .................................................................. 27
B. Handset Operation Modes ............................................................ 27
Making a Telephone Call ........................................................................ 29
Making a 2-Way/ Intercom Call ............................................................. 30
Making a Broadcast................................................................................ 30
Handset-to-Handset Calls .................................................................. 30
Redial ..................................................................................................... 31
Receiving a Telephone Call .................................................................... 32
Receiving an Intercom Call ..................................................................... 32
Ending a Call ........................................................................................... 33
Adjusting Handset Receiver (Earpiece) Voice Volume .......................... 33
Adjusting Handset Speakerphone Voice Volume .................................. 33
Placing a Call On Hold ............................................................................ 34
Mute ....................................................................................................... 34
Do Not Disturb (Silent Ring) ................................................................... 34
Key Guard ............................................................................................... 35
Battery Recharge and Replacement ...................................................... 35
