- Page 1 CEILING FAN INSTALLATION AND OPERATION INSTRUCTION READ AND SAVE THESE INSTRUCTIONS MODEL# Y52YH5-06 FAN RATING AC 120V. 60Hz UL LISTED MODEL : AC-552...
-
Page 2: Tools And Materials Required
1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items; a. Fan blades (5) b. Hanger bracket c. -
Page 3: Safety Rules
3. SAFETY RULES 1. To reduce the risk of electric shock, 7. Do not operate reversing switch while insure electricity has been turned off fan blades are in motion. Fan must be at the circuit breaker or fuse box turned off and blades stopped before before beginning. -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing CUL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the Outlet box building structure. Use appropriate fasteners and building materials. - Page 5 5. Hanging the Fan UL Listed electrial REMEMBER to turn off the power. Follow the steps below to hang your fan properly: Step 1. Pass the 120-volt supply wires Washers Hanger through the center hole in the ceiling bracket hanger bracket as shown in Fig. 5. Hook Step 2.
-
Page 6: Make The Electric Connections
6. MAKE THE ELECTRIC CONNECTIONS POWER LINES 120V GREEN GROUND Remember to disconnect the power. Follow the steps below to connect the fan WIRING to your household wiring. Use the wire connecting nuts supplied with your fan. GROUND TO Secure the connectors with electrical tape. MOUNTING BRACKET Make sure there are no loose strands or... -
Page 7: Finishing The Installation
7. FINISHING THE INSTALLATION Outlet box Hanger Step 1. Slide the canopy up to the bracket ceiling and over the two screws on hanger bracket. Rotate canopy clockwise Screws until tight. Note: adjust the canopy screws Canopy needed until the canopy is snug. (Fig. 11) Figure 11 8. -
Page 8: Installing The Light Kit
9. INSTALLING THE LIGHT NOTE: Before starting installation, Lock washer Switch housing disconnect the power by turning off the Pull chain circuit breaker or removing the fuse at Plug Pull chain holder fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock. -
Page 9: Operating Your Fan
10. OPERATING YOUR FAN NOTE: Wait for fan to stop before changing the setting of the slide switch. Turn on the power and check the operation of your fan. The pull chain controls the fan speed as follows: 1 pull- High, 2 pulls-Medium, 3 pulls- Low, and 4 pulls-Off. -
Page 10: Troubleshooting
11. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. Fan sounds 1. Make sure all motor housing screws are snug. noisy. -
Page 11: Specifications
12. SPECIFICATIONS These are approximate measures. They do not include Amps and Wattage used by the light kit. Fan Size Speed Volts Amps Watts N.W. G.W. C.F. 0,20 1025 11.8 1,81 52" Medium 0,35 3500 0,49 5400 High...
