Bios Recovery - Fujitsu Siemens Computers D2568 Technical Manual

Board Installation

BIOS Recovery

i
All BIOS settings are reset to the default values.
► Opening the casing as described in the operating manual.
► Close the jumper RCV (JP23).
► Close the casing as described in the operating manual.
► Insert a BIOS Recovery Disk and start the PC.
► Note the signals issued from the buzzer or loudspeaker. You have successfully restored the
BIOS if you hear continuously fast repeated beeps.
► Power off your system.
► Open the casing as described in the operating manual.
► Remove the jumper RCV (JP23).
► Close the casing as described in the operating manual.
► Remove the floppy disk from the drive.
► Start the PC and invoke BIOS Setup.
► Select the menu item Reset configuration in the menu Advanced and change the setting to
Yes.
► Save the change and terminate BIOS Setup.
The BIOS recovery has now been completed. The system restarts.
26 A26361-D2568-Z120-1-7619, edition 1
