- Page 1 快速入门指南 & 安装手册 PEDoMAn MUlAI CEPAT & PETUnjUK PEMASAnGAn NX502A DVD MUlTIMEDIA STATIon WITH BUIlT-In nAVIGATIon & 6.2” ToUCH PAnEl ConTRol เครื ่ อ งเล่ น DVD มั ล ติ ม ี เ ดี ย พร้ อ มแผงควบคุ ม ระบบสั ม ผั ส และระบบนำ า ทางในตั ว ขนาด 6.2”...
-
Page 2: Table Of Contents
Wire Connection ....................... 9 7. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. ® and any use of such marks by Clarion Co.,Ltd, is under license. , DivX Certified 8. DivX and associated logos are trademarks ®... -
Page 3: Operational Panel
Touch [ - ] on the bottom of screen to show front zone sources. in memory are cleared. Change page by dragging left or right or touching other [ - ] buttons. Touch the icons on the screen to enter corresponding work mode, such as Disc mode, Tuner mode, Telephone mode, etc. NX502A... -
Page 4: Source Media Modes
11. Show playback information 4. Repeat play 12. Back to main operation bar 5. Previous track Fast reverse (long press) 6. Progress bar 7. Next track Fast forward (long press) 8. Random play 9. Show other options Scan: Scan play stored stations NX502A... -
Page 5: Ipod Video Playback
Fast reverse (long press) 4. Progress bar 5. Next file Fast forward (long press) 6. Show iPod list menu 7. Show other options 8. Turn on / off Simple Control 9. Turn on Widescreen mode 10. Back to main operation bar NX502A... -
Page 6: Bluetooth Operations
Bluetooth Operations Start using Clarion Mobile Map When Clarion Mobile Map is started the first time, you need to do the following: Pairing 1. Select the written language of the application interface. Later you can change it in Settings. 1. Touch [Custom] on the bottom left of the main menu, then select [Settings] to enter Setting 2. -
Page 7: Map Screen
Start using Clarion Mobile Map Installation Guide Before Starting Map Screen 12. To enlarge this small map and open the 1. This set is exclusively for use in cars with a Map screen, tap [Show Map] button negative ground, 12 V power supply. -
Page 8: Installing The Main Unit
Mounting bracket Center Panel *1 (1 pair for the left and right sides) Fuse holder • After the connection, fix the cord by a clamp or insulation tape for protection. Screws marked and mounting bracket are attached to the vehicle. NX502A... -
Page 9: Installing The Gps Antenna
NX502A Installation Guide Installation Guide Installing The GPS Antenna Wire Connection GPS Antenna GPS Antenna (Black) WARNING (Black) External Microphone External Microphone • Do not install the GPS antenna in a place where it may interfere with the operation of the... - Page 10 Parking brake signal cord Not used. Green/Black Insulate each wire Fresh Green wire (Parking) Connect it to the car power supply terminal for parking Stopper Parking brake cord (Grass-green) Purple/White wire (Reverse) Connect it to the car power supply terminal for reverse NX502A...
- Page 11 Clarion Co., Ltd. All Rights Reserved. Copyright © 2012: Clarion Co., ltd. China/พิ ม พ์ ใ นประเทศจี น /中国印制/Dicetak di Cina Printed in PN: 127075004146...
