Summary of Contents for Clarion NX502A
- Page 1 Owner's manual NX502A DVD MULTIMEDIA STATION WITH BUILT-IN NAVIGATION & 6.2" TOUCH PANEL CONTROL...
-
Page 2: Table Of Contents
Contents Thank you for purchasing this Clarion product. • Please fully read this owner’s manual before operating this equipment. • Check the contents of the enclosed warranty card and store it in a safe place with this manual. 1. FEATURES ........................3 Expanding Systems ...................... -
Page 3: Features
Rear Vision Monitor Camera 6 Channel Amplifier USB Memory iPod / iPhone (Connect via CCA-750) Portable Player ® Bluetooth (Connect via AUX IN Jack) mobile phone SD Card Notes: • T he items listed outside of the frames are the commercial products generally sold. • CCA-750: Sold by separately. NX502A... -
Page 4: Precautions
7. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. ® and any use of such marks by Clarion Co.,Ltd, is under license. 8. DivX , DivX Certified and associated logos are trademarks ®... -
Page 5: Cautions On Handling
• The USB memory sticks must be recognized as “USB mass storage class“ to work properly. Some models may not operate correctly. W hen the memorized data is lost or damaged by any chance, Clarion shall not be liable for any damage. When using an USB memory stick, we recommend that you backup your data stored on it before using a personal computer etc. -
Page 6: Handling Discs
Storage • Do not expose discs to direct sunlight or any heat source. • Do not expose discs to excess humidity or dust. • Do not expose discs to direct heat from heaters. NX502A... -
Page 7: Controls
• Press again to return current source. ] EJECT Button • Press to eject disc. [ MIC ] Hole • Internal microphone [RESET] Button • Press to load original settings. Note: When the [RESET] button is pressed, frequencies of radio stations, titles, etc. stored in memory are cleared. NX502A... -
Page 8: Remote Control
• Enter navigation mode • Number input mode [PIC] Button [BACK] Button • Adjust screen • Back from source menu return to previous display [BAND] Button • Select tuner band ], [ ], [ ], [ ] Buttons • Move cursor up/down/left/right [TAG] Button • Not used NX502A... - Page 9 2. Insert the battery with the plus (+) and minus (–) poles aligned properly. • When using for the first time, pull out the film protruding from the tray. 3. Close the back cover. NX502A...
-
Page 10: Main Menu Operations
[ W a l l p a p e r ] : T o u c h t h e i c o n t o e n t e r Wallpaper setting menu. (see “System Setup”) [Monitor Off]: Touch the icon to turn off the monitor. To turn on the monitor, touch the monitor again. NX502A... -
Page 11: System Setup
[OK] to confirm. 24-Hour format Initialize: Load original buttons backlight. Touch [On] to select 24-Hour format. Touch [ BACK ] on the bottom left of the Touch [Off] to select 12-Hour format. screen to return to main setting menu. NX502A... - Page 12 Select subtitle language from list. Dimmer • Set Password Touch [-] or [+] button to the right of “Dimmer” To set password for parental control, to adjust dimmer. Touch [Set] to show password menu. The setting is only for Day or Night. NX502A...
- Page 13 [ G e n e r a l ] b u t t o n a n d i n p u t t h e o l d password. Note: Please make a note of the Anti theft code not to forget. if the right code is not inputted, it becomes impossible to operate this unit. NX502A...
-
Page 14: Disc Operations
• The number of recorded subtitle languages two sessions have been recorded. The first are indicated by the icon shown below. session is Audio session and the second session is Data session. Your personally- created CDs with more than second data NX502A... - Page 15 Note on region numbers The DVD video system assigns a region number to DVD video players and DVD discs by sales area. DVD video players sold in Australia can play back DVD discs with the region number “ALL”, “4” or any combination NX502A...
-
Page 16: Accessing A Disc
The disc plays automatically after loading. Notes: • N ever insert foreign objects into the disc slot. • I f the disc is not inserted easily, there may be another disc in the mechanism or the unit may require service. NX502A... -
Page 17: Dvd Player Operations
13. Back to main operation bar Touch [Chapter] or [Title] to show DVD chapter/title list. DVD audio select During playback, touch [ ], [Audio] buttons to select audio language to listen if the DVD has multiple audio languages. NX502A... - Page 18 During playback, touch [ Picture ] button, then use [-], [+] buttons to adjust Dimmer/Brightness/Contrast/Color. DVD angle select ], [ Angle ] During playback, touch [ buttons to select different angle to view if the DVD has multiple-angle views. NX502A...
-
Page 19: Cd Player Operations
] button to perform random play. Selecting a track Track-up 1. Touch the [ ] button to move to the beginning of the next track. Track-down 1. Touch the [ ] button to move back to the beginning of the current track. NX502A... -
Page 20: Mp3/Wma Playback
The files will be played soundlessly if you attempt to play files without MP3/WMA data. * When VBR files are played, the play time display may differ the play location. * When MP3/WMA files are played, a little no sound part is caused between tunes. NX502A... - Page 21 3. Play/Pause 4. Repeat play 5. Previous track Fast reverse (long press) 6. Progress bar 7. Next track Other operations about playing MP3/WMA Fast forward (long press) are same as CD Player mode. 8. Random play 9. Show other options NX502A...
-
Page 22: Mp4/Divx Playback
Drag up/down to browse, and touch desired option to select it. Pausing play 1. Touch the [ ] button on the screen to pause play. “ PAUSE” appears in the display. 2. Touch [ ] button to resume play. NX502A... -
Page 23: Sd/Usb Operations
[SD] to enter SD mode. If [SD] is not on the current source menu, touch [ - ] buttons on the bottom of the screen, or hold the center of screen and drag left/right to show more icons. NX502A... -
Page 24: Sd/Usb Audio Operations
Notes: • T his system will not operate or may operate improperly with some card or USB. • F iles protected with any DRM cannot be played. • O nly USB device, DivX is available. Operations about SD/USB video operations are same as MP4/DivX playback mode. NX502A... -
Page 25: Bluetooth Operations
[Cancel] to return to 4. Search for new Bluetooth devices. list menu. 5. Select NX502A from the pairing list on the mobile phone. Choose paired device 6. Enter “0000” as the password. 7. After pairing successfully,... - Page 26 14. Show Bluetooth information 15. Bluetooth indicator Making a call • Dial Number 1. Input numbers by digit-keys on the screen. 2. Touch [ ] button to dial. Touch [ ] button to delete characters. 3. Touch [ ] button to terminate call. NX502A...
-
Page 27: Bluetooth Audio Operations
Please Track-up consult your nearest Clarion dealer for more 1. Touch the [ ] button to move to the information on the product of wireless audio beginning of the next track. -
Page 28: Radio Operations
2. T he unit has 4 bands, such as FM1, FM2, 11. Choose local or distant seeking mode FM3 and AM. FM3 and AM can store 12. Store stations automatically by AS function. Each bands can store 6 13. Back to main operation bar stations, NX502A can store 24 stations in total. NX502A... - Page 29 To open LOCAL function, touch [ ] button on the operation bar, then touch the [Mode] button to select “Local” or “DX”. Note: The number of radio stations that can be received will decrease after the local seeking mode is on. NX502A...
-
Page 30: Dab Operations(Dab302E (Sold Separately) Is Required)
/ lower station. To stop searching, repeat the operation above or press other buttons having radio functions. Note: When a station is received, searching stops and the station is played. 9. Turn on/off Service Link. 10. Turn on/off traffic announcement. NX502A... - Page 31 2. Touch to select a preset service. PTY Search Touch [ ] button on the operation bar, and then touch [PTY Select] to show PTY type. Drag up/down to scroll, and touch to select. Touch [Seek] to seek a channel within the selected category. NX502A...
-
Page 32: Ipod & Iphone Operations
6. Previous track 2. Touch the [ ] button twice to move back Fast reverse (long press) to the beginning of the previous track. 7. Progress bar 8. Next track Fast forward (long press) 9. Random play 10. Show other options NX502A... - Page 33 To playback video from iPod, touch top left button, then touch [Wide screen] to set it to corner of the screen, then select a video file [On]. to play. During playback, touch the bottom half of screen to show operation bar. NX502A...
-
Page 34: Navigation Operations
[AUX 2] to enter rear auxiliary device. If [AUX 1] or [AUX 2] is not on the current source menu, touch [ - ] on the bottom of the screen, then hold the center of screen and drag left/right to show more icons. NX502A... -
Page 35: Trouble Shooting
There are red, panel is produced according to technology green, and blue ____________________ with very high precision. Note that, though points in display there are effective pixels of 99.99% or more, pixel missing or normally lit pixels account for 0.01%). NX502A... - Page 36 “NO the card or USB device. device. FILE” shown. The video image The TV Signal setting of the Set the TV Signal setting (NTSC/PAL) of the of iPod/iPhone is iPod/iPhone is not set correctly. iPod/iPhone correctly. disturbed. NX502A...
- Page 37 Adjust the gain and position of the external connection with a The external microphone is microphone. Bluetooth-enabled not set correctly nor properly For example, stick the microphone onto the device. positioned. dashboard so it is close to the driver. NX502A...
-
Page 38: Error Displays
If an error display other than the ones described above appears, press the [RESET] button. If the problem persists, turn off the power and consult your store of purchase. * When the [RESET] button is pressed, frequencies of radio stations, titles, etc. stored in memory are cleared. NX502A... -
Page 39: Specifications
Playable video format: M4V(.m4v),MP4(.mp4): MPEG4part2(Simple),MPEG4 AVC/ H.264(Baseline@2.1) 3GP(.3gp): MPEG4part2(Simple) 178mm 7" 4" 100mm Resolution : 480x272 Audio format :AAC,AMR,MP3,WMA,WAV Note: Bluetooth • S pecifications and design are subject to change without notice for further improvement. Specification: Bluetooth Ver. 2.0+EDR Profile: HFP (Hands-free Profile) NX502A... -
Page 40: Wiring And Connections
White Black Black DAB302E (sold separately) Line Out Gray Front Right Line Out Front Left White Line Out Black Rear Right Line Out Rear Left White 6-Channel Amplifier White Purple Subwoofer 1 Subwoofer 2 Black USB connector USB Memory NX502A... - Page 41 Connect it to the car power supply terminal for antenna Not used. Green/Black Insulate each wire Fresh Green wire (Parking) Connect it to the car power supply terminal for parking Purple/White wire (Reverse) Connect it to the car power supply terminal for reverse NX502A...
- Page 42 Clarion Co., Ltd. All Rights Reserved. Copyright © 2012: Clarion Co., Ltd. Printed in China...
