  • Page 1 INSTALLATION INSTRUCTIONS F o r B u i l t - i n M i c r o w a v e O v e n s Model: EM 204-630 Built-In Trim Kit Model: ER 204-630 (Sold Separately)
  • Page 2 Please read this entire manual before proceeding IMPORTANT Local codes vary. Installation, electrical connections, circuit breakers and grounding must comply with all applicable codes. Save these instructions for your local electrical inspector's use. INSTALLER: Please leave these Installation Instructions with this unit for the owner.
  • Page 3 • Screws #8 x1" (6) • Template (1) Caution: • Trim kits are designed for use only with the Gaggenau microwave oven models listed (See Table 1). • For safety, do not alter or modify any part of this kit or oven.
  • Page 4 Your microwave oven can be installed into a cabi- ure 1. net or wall by itself or above any of the following Gaggenau wall ovens: EB 290, EB 291, EB 294 • It is a good practice when the microwave oven is and EB 295.
  • Page 5 Step 3: Electrical Installation The Gaggenau microwave oven is equipped with a grounded cord. The wall receptacle must be installed and grounded in accordance with the national electrical code. Also, electrical connections and grounding must comply with all applicable local codes.
  • Page 6 Step 4: Installing The Microwave Oven (continued) Step B Remove the one existing screw from the left side of the microwave oven. Connect the side duct to upper duct as shown. Insert projecting tabs of upper duct into holes of side duct. Bend tabs up as shown.
  • Page 7 Step 4: Installing the Microwave Oven (continued) Anti-tip Step D Bottom Assembly Slide microwave oven part way into cabinet Duct opening. (Bottom bracket must be flat to the cutout floor to engage correctly with anti-tip brackets as shown). " screw Anti-tip Plug in the microwave oven.

  • Page 8: Bsh Home Appliances Corporation

    Gaggenau reserves the right to change specifications or design without notice. Some models are certified for use in Canada. Gaggenau is not responsible for products which are transported from the United States for use in Canada. Check with your local Canadian distributor or dealer.
