Instruction manual
Dear Reader ...
Instruction manual
We would like to congratulate you on the purchase of your new motorhome. You have selected a top-quality
vehicle which will afford you many years of enjoyment.
To enable you to always use and operate your motorhome properly and easily, your Bürstner dealer will first
provide you detailed instructions for all important functions when you take delivery.
This manual, the instruction manuals from the base vehicle manufacturer as well as the instruction manuals
from the appliance manufacturer will always be at hand to answer any questions you may have regarding your
motorhome.
Before your first journey
Please familiarise yourself with this manual rather than relying on it strictly for reference.
Fill in the warranty cards for the appliances and special equipment in the individual instructions and send these
cards to the respective manufacturers. This ensures your warranty claim for each appliance.
© 2013 Bürstner GmbH Kehl
I-Modell - 13/14 - Ausgabe 08/13 - 2354644 - BUE-0056-07EN
