Hint
You can also display the Web page for the scanner by right-clicking
the scanner in the main window of the Scanner Wireless Connection
Utility and selecting [Display the Web page] in the menu that
appears.
Display the Web page directly from a Web browser
Enter the IP address that is configured on this product in the address
bar of the Web browser and then press the ENTER key.
Example: Enter 192.168.0.10 and then press the ENTER key (The
address is displayed as http://192.168.0.10/.)
About Each Page
When you click the items on the left menu, the following pages are
displayed.
Status
Shows the operating status of this product.
Network Conf.
Configures the network settings.
Access Point Conf. Configures the wireless LAN settings for AP
mode.
Station Conf.
Configures the wireless LAN settings for
station mode.
Security
Configures the security settings.
Maintenance
Loads the factory default settings, restarts
the product, and updates the firmware.
28
IMPORTANT
The user name and password are required to configure the settings.
When the screen below is displayed, enter the user name (root) and
password, and then click [OK]. (No password is configured in the
factory default settings.)
Hint
• From [Select Language], you can change the language of the Web
page.
• In the bottom left of the Web page, the firmware version and the Mac
address of this product are displayed.
