NAVIGATION AND CONTROL BUTTONS

Press the quick-release button on the right side of the monitor and the display screen will open (See Illustration D).
Beneath this screen are your navigation and control buttons (See Illustration E).
These buttons are used to program, edit or change settings, select different memory positions and navigate through
each tire to verify the exact pressure level by tire.
When you power up your nVISION TPMS for the first time, it has been designed to automatically begin in
programming mode. See Initial Set Up for details on how to program your system.
Program Button:
editing mode. Program mode allows you to choose or edit the basic tire configurations of each memory
position, as well as the type of pressure displayed (PSI, kPa or BAR).
Navigation Buttons:
configuration options, as well as browse from tire to tire.
Select Button:
when you have completed your initial programming steps.
Undo Button:
Undo button in program mode will undo the current selection and allow you to navigate through other options.
Illustration D: Quick-Release Button
Pressing this button switches your system from monitoring mode to programming or
Your monitor has 4 arrow keys that allow you to move through different
This button confirms your selection, as well as allows you to exit programming mode
Should you make a selection and decide you want to change it - no problem. Pressing the
Quick-Release Button
Illustration E:
Program Button
Select Button
Navigation Buttons
9
Navigation and Control Buttons
Undo Button
