NORMAL OPERATION

Once you have completed programming your Memory Positions, your system will enter normal operating mode.
N TPMS COMPON
Your TPMS system will begin checking tire pressures. You will see the a series of check
N TPMS COMPONENTS
marks illuminate in the top left corner of the display screen. These checks indicate that
your TPMS system is reestablishing the RF connections with each sensor and verifying tire
pressures. When all pressures report at normal levels, checking will stop and you will receive a notification of
"OK" that confirms normal pressure for all tires. Until your monitor confirms all pressures are reporting normal, you
will see a blinking yellow light on the front of the monitor case. When all tires are confirmed as OK, your monitor
will illuminate the green light.
If you have turned your monitor off, you will need to turn it on to begin the normal operation mode. Note that
from the off position, your TPMS system will need to reestablish the RF signature for each sensor for the Memory
Position last used. This process could take up to 5 minutes depending on the communication cycle of the sensors.
When the monitor reestablishes RF connections, the monitor will display a yellow light, to indicate that it has yet to
verify all tire pressures.
Tip: We recommend that once your system is operating, you leave it plugged in and turned on. This
ensures that you have a continuous monitoring of all tires.
Changing Your Memory Position
If your driving situation has changed since you last used your TPMS system, you will want to update
Memory Position.
Open the monitor display, press the Program Button and use the arrow keys to move to your desired Memory
Position. Press to confirm your selection and exit programming mode. Your system will begin checking all
tires. When all tires report within normal pressure ranges, the green light will illuminate.
17
