EBOX-3300A / 3310A series
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EBOX-3300A series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DMP Electronics EBOX-3300A series

Summary of Contents for DMP Electronics EBOX-3300A series

  • Page 1 EBOX-3300A / 3310A series User’s Guide...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part, in any form or by any means without the prior written permission of the DMP Electronics Inc.
  • Page 3 Trademarks Acknowledgment The EBOX-3300A/ 3310A series is the registered trademarks of DMP Electronics Inc. Microsoft, Windows, and AMI are registered trademarks of Microsoft Corporation and American Megatrends Inc. in the United States and/or other countries respectively. Other brand names, product names or trade names appearing in this document are the properties and registered trademarks of their respective owners.

  • Page 4: Safety Information

    Safety Information WARNING Do not expose EBOX-3300A/ 3310A series to rain or moisture, in order to prevent shock and fire hazard. Never install EBOX-3300A/ 3310A series in wet locations. Do not open the cabinet to avoid electrical shock. Refer to your nearest dealer for qualified personnel servicing.
  • Page 5 Regulatory FCC Class A Note This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 6: Product Description

    User’ Manual to check for the contents and appearance of this product; contact immediately your nearest dealer or DMP office for any defective or missing parts. The supplier will not be responsible for any reported discrepancy thereafter the expiration period of 3-days from the date of purchase.

  • Page 7: Table Of Contents

    Contents Chapter 1 02 Unpacking your EBOX Mini PC Chapter 2 05 EBOX-3300A/ 3310A series Overview 06 System Specifications 07 Peripherals Connecting Chapter 3 11 BIOS Reconfiguring 11 Path to the Watchdog configuration Debian / Ubuntu Linux Installation Guide Chapter 4 16 Technical Specifications Chapter 5 18 Onboard Connectors Summary...
  • Page 8 Chapter...

  • Page 9: Unpacking Your Ebox Mini Pc

    Unpacking Your EBOX Mini PC Congratulation! You have just acquired EBOX-3300A/ 3310A series, please check the following items. Packing List: Item No. Description Q’ty EBOX-3300A/ 3310A series VESA PC Max. 10 - watts External Power Adaptor, Vin: 100~240VAC 50/ 60Hz, 0.45A / Volt: +5.0 VDC @ 2.0A Max.
  • Page 10 Preface EBOX-3300A/ 3310A series: VESA PC The EBOX-3300A/ 3310A series is a revolutionary device which is especially designed for limited physical space and temperature concerns. No matter you are in a jammed office, a crowded place, or public transportation, it can be easily integrated with a VESA LCD to bring you EBOX-3300A/ 3310A series access at any time.
  • Page 11 Chapter...

  • Page 12: Ebox-3300A/ 3310A Series Overview

    EBOX-3300A/ 3310A series Overview Front Panel Power LED The power LED lights up when system is turn on. HDD LED LED flashes when the system is accessing Hard Drive. Audio Line Out Audio output to speaker Audio Mic In For Microphone Input CF &...

  • Page 13: System Specification

    System Specification Operating System MSTI-PDX-600 ( System on Chip ) Windows XP Home/ Pro Windows XP Embedded Main Memory Windows Embedded CE 256 MB DDR2 512 MB DDR2 Supported Linux Distribution list: ( 512MB DDR2 version called 3310A series ) 1.

  • Page 14: Peripherals Connecting

    Peripherals Connecting the Power Adaptor DC Power Jack To use EBOX-3300A/ 3310A series immediately, please attach the supplied adapter for the power source. See the left diagram for visual connection. Connect the DC power jack of the power adaptor to the DC Input of EBOX-3300A/ 3310A series.
  • Page 15 Peripherals Connecting the USB EBOX-3300A/ 3310A series provide Three external USB ports with (Two at the front, One at the rear) and one internal USB port. Micro-SD and CF Slot For connecting to Device with Compact Flash Card and Micro-SD (T-flash). Microphone/Earphone The EBOX-3300A/ 3310A series supports Microphone Input and Speaker Output.

  • Page 16: Connecting The Keyboard And Mouse

    Connecting the Keyboard and Mouse PS/2 Keyboard or Mouse (6-pin) This PS/2 Port is shared for connecting Keyboard and/ or Mouse by using Split Y-Cable (not included). Connecting Serial port Serial Ports (Optional) The serial port is usually connected to a serial device like modem or terminal devices.
  • Page 17 Chapter...

  • Page 18: Bios Reconfiguring

    BIOS Reconfiguring Take note that AMI BIOS is used in the EBOX-3300A/ 3310A series. To reconfigure the EBOX-3300A/ 3310A series, press or hit the <Del> key to enter your BIOS setup main menu. Select from the menu, the desired setup for change. Press <Esc>...

  • Page 19: Debian / Ubuntu Linux Installation Guide

    Linux can boot up normally, after install completed. Step2: A. Copy the .deb file (kernel package) that DMP provided into your USB pen driver or other removable storage. B. Press Ctrl + Alt + F1 keys to enter text mode.
  • Page 20 D. To unpack the kernel package and update. # dpkg -i xxx.deb # update-initramfs –k 2.6.30-vortex86mx -c # update-grub E. When these three procedures completed, type reboot to reboot system. # reboot Step3: Moving the storage installed Linux, back to VortexDX platform. Step4: Turn on the power to boot.
  • Page 21 For Ubuntu When it start booting, press the Esc key when it boot. Confirm the Grub list first. There should has an option 2.6.30-vortex86mx, and then to boot. For Debian Please press the Esc key to confirm Grub list and press E key to confirm and modify the storage’s codename. Note: The Grub list parameters you can modify in the file /boot/grub/menu.lst.
  • Page 22 Chapter...

  • Page 23: Technical Specification

    EBOX-3300A-JSK / 3310A-JSK: Standard Version with Mini PCI support and 2 x RS-232 ports EBOX-3300A-L2 / 3310A-L2: Standard Version with 2 x LAN and 2 x RS-232 ports, no PS/2 EBOX-3300A-LS / 3310A-LS: Standard Version with 128MB CF card + DMP Embedded Linux OS...
  • Page 24 Chapter...

  • Page 25: Onboard Connectors Summary

    Onboard Connectors Summary Summary Table for CPU Board Description Type of Connections Pin nbrs. IDE connector Box Header 22 x 2 2.0mm 44-pin USB (Front) USB Connector 8pin USB (Front) USB Connector 8-pin USB (Front) USB Connector 8-pin JTAG connector Wafer 1.25mm 6-pin PS/2 connector...
  • Page 26 Rear Connectors Outline DC Power Jack PS/2 KB/Mouse RJ-45 LAN Power Switch Serial Ports Wireless ANT (Optional) DC Power Jack RJ-45 LAN Power Switch Serial Ports (Optional) Wireless ANT (Optional)

  • Page 27: Pin Assignments

    Pin Assignments J8: PS/2 Keyboard or Mouse – 6-pin Mini-Din Connector Pin # Signal Name KBCLK PMCLK KBDAT PMDAT SB5V J13: Power SW – Push Button Switch Pin # Status J12: DC-IN (5V) – 3-pin Mini-Din Lock Pin Socket Signal Name Pin # J3: USB (90 ) –...
  • Page 28 J15: VGA – 15-pin D-Sub Connector Pin # Signal Name Pin # Signal Name Pin # Signal Name HYSYNC VSYNC J4, J5: USB (USB2): For connection to external USB device –4-pin USB Type 1 Connector (H) Signal Pin # Name USB2- USB2+ J9, J11: COM - 9-pin D-Sub Connector...
  • Page 29 Chapter...

  • Page 30: Taking Care Your Ebox Vesa Pc

    Taking Care of your EBOX This section gives you some guidelines on using EBOX-3300A/ 3310A series – Safe using, Storing and Handling. Storing Do not place EBOX-3300A/ 3310A series in a location that is subject to: Heating sources, such as stove, oven, heater, radiator or air duct Direct contact from sunlight Rain or moisture area Excessive dust accumulation area...

  • Page 31: Cleaning Your Ebox Vesa Pc

    Using Cables for Connection To avoid problem, use only the specified interface cables in your accessory bag. The supplier will not be responsible for the connection arising from the other unspecified peripheral equipment. Do not use cut or damaged cables for connection. Cleaning Your VESA PC Clean the VESA PC with a soft, dry cloth or a soft cloth lightly moistened with a mild detergent solution.

  • Page 32: Troubleshooting

    Troubleshooting This section describes the techniques of resolving some basic problems that you encounter when using EBOX-3300A/ 3310A series. For more troubleshooting guidelines, please contact your nearest dealer for technical support. Troubleshooting Your VESA PC A. VESA PC Make sure the EBOX-3300A/ 3310A series is properly secured and plugged into a power source before it is turned on.
  • Page 33 Go to “Exit” menu using the Direction keys <↑↓> and choose the option “Load Optimal Defaults”, then press <Enter>. A message dialog appears as seen below, hit “Y” key and presses <Enter> to save and recover to the factory setting. “Load Optimal Defaults (Y/N)? Y”.
  • Page 34 Chapter...

  • Page 35: Terms And Condition

    Return Merchandise Authorization（ （ （ （ RMA） ） ） ） policy If the DMP staff or dealer determines that a part is defective. Purchaser must call our technical support service to obtain an RMA number before attempting to return any part. Please contact your nearest dealer to obtain an RMA number.

This manual is also suitable for:

Ebox-3310a series
