Elation ELAR EXFLOOD User Instructions page 3

ELAR EXPAR SPECIFICATIONS:
Working Position: Any safe working position
Voltage:
Power Consumption:
Power Draw:
Weight:
Dimensions: 9.5" (L) x 8.0" (W) x 12" (H)
Colors:
Beam Angle:
LEDs:
DMX Channels:
IP Rating:
Warranty:
DMX CHANNEL MODES: There are two DMX modes, a 3 Channel mode and a 5 Channel mode. If
green LED's flash you are in 3 Channel mode, if blue LED's flash you are in 5 Channel mode. Set the
mode before you address the fixture.
Elation® Architectural - www.elationlighting.com - Instruction Manual Page 3
100V ~ 240V
20W
0.6 Amps
11lbs./ 4.8Kgs.
240 x 200 x 305mm
RGB Color Mixing
40 Degree
145 10mm
3 or 5 DMX Channels
IP65
2 Year (730 days)
3 cHAnnEl MoDE
channel Value
1 0 - 255
2 0 - 255
3 0 - 255
5 cHAnnEl MoDE
channel Value
1 0 - 255
2 0 - 255
3 0 - 255
4 0 - 255
5
0 - 10
11 - 255
Function
RED
0% - 100%
GREEN
0% - 100%
BLUE
0% - 100%
Function
RED
0% - 100%
GREEN
0% - 100%
BLUE
0% - 100%
DIMMING
0% - 100%
STROBING
NO FUNCTION
STROBING SLOW - FAST
