water. If battery liquid gets into the eye, rinse water over the open eye for three minutes or
until irritation ceases. If medical attention is needed, the battery electrolyte is composed of a
mixture of liquid organic carbonates and lithium salts.
wARNING:
Symbols
• The label on your tool may include the following symbols. The symbols and their
definitions are as follows:
V ..................volts
Hz ................hertz
min ..............minutes
or DC ..direct current
................Class I Construction
(grounded)
................Class II Construction
(double insulated)
SAVE THESE INSTRuCTIONS

PRODuCT FEATuRES

1. On/Off switch
2. Removable hose / handle
3. Locking ring
4. Hose
5. Filter cleaning wheel
6. Transparent door
7. LED charging indicator
8. Door latch
9. Accessory clip
10. Long crevice tool
11. Pet hair cleaning tool
12. 2-in-1 nozzle / brush tool
13. Charging base
ASSEMBLy
Mounting accessories
(figures A & B)
The 2-in-1 nozzle / brush tool (12)
has a brush that can be folded
forward for dusting and upholstery cleaning. The pet hair cleaning tool (11) is for
use when vacuuming pet hair and/or ground-in debris from carpeted or upholstery
surfaces.
wARNING:
directly on animals.
The crevice tool (10) allows for vacuuming in narrow and hard to-reach places.
• To attach an accessory, press the accessory clip (9) and slide the accessory onto the
handle (2).
• To remove an accessory, press the accessory clip (9) and remove the accessory.
To unwrap and extend the handle and hose:
The handle and hose can be unwrapped from the main appliance for extended reach when
cleaning. Grab the handle where the arrows indicate and lift upwards. Unwrap the handle and
hose from the main appliance. The hose can extend up to approximately 4 feet (1.21m).
To place the handle and hose back onto the main appliance, wrap the hose back underneath
and around the vac making sure that the hose fits between the two "feet" of the appliance. Align
the handle with its cradle and click back into place. The handle (2) can be removed from the hose
allowing the accessories to be connected directly to the hose cuff (16) when desired.
Burn hazard. Battery liquid may be flammable if exposed to spark or flame.
Injury to pets. Do not use pet hair cleaning tool
4
A ...................amperes
W ..................watts
or AC .......alternating current
n o .................no load speed
.................earthing terminal
.................safety alert symbol
.../min or rpm..revolutions or reciprocation
per minute
