FLEX™ VAC
INSTRUCTION MANUAL
CATALOG NUMBERS
HFVAB320JC
PLEASE READ BEFORE RETURNING THIS
PRODUCT FOR ANY REASON.
If you have a question or experience a problem with your Black+Decker
purchase, go to http://www.blackanddecker.com/instantanswers
If you can't find the answer or do not have access to the Internet, call
1-800-544-6986 from 8 a.m. to 5 p.m. EST Mon. - Fri. to speak with an agent.
Please have the catalog number available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
VEA EL ESPANOL EN LA CONTRAPORTADA.
INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE GARANTÍA.
ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
To register your new product, call 1-800-544-6986
or visit www.BlackandDecker.com/NewOwner
Table of Contents
loading

Frequently Asked Questions (9)

  • What should I do if the Black & Decker FLEX HFVAB320JC has poor suction?

    To optimize suction force, the filters must be cleared regularly during use. If suction is poor, one of the filters may be clogged. Pull the door latch and open the dust container door. Remove the pre-filter and the pleated filter. Brush any loose dust off the filters and wash them in warm, soapy water. Make sure the filters are dry before placing them back in the vacuum.

    Was this helpful?
  • How do I empty and clean the dustbin of the Black & Decker FLEX HFVAB320JC?

    To empty the dust container:

    To clean the dust container:

    • Unwrap the hose (4) and handle (2) from the main part of the appliance.
    • Push and hold the release button on the opposite side of the handle from the dust container door (5).
    • Rotate the handle toward the back of the appliance.
    • Pull the dust container to the side, away from the base of the appliance.
    • Remove the pre-filter (18) and filter (19) from the appliance by twisting and pulling them.
    • Once filters are removed, wipe the removable bowl (10) and pre-filter with a damp cloth, or rinse with warm soapy water and allow to dry.
    Was this helpful?
  • Why does my Black & Decker FLEX HFVAB320JC vacuum cleaner keep turning off?

    If your vacuum cleaner keeps turning off, check the following:

    • The charger was correctly plugged in for recharge.
    • The charger cord is not damaged and is correctly attached to the charging base.
    • The charger is plugged into a working electrical outlet.
    • The appliance was switched to the "off" position to charge. The battery will not be charged with the switch in the “on” position.
    • One of the filters may be clogged. Remove the pre-filter and the pleated filter, brush any loose dust off, and wash them in warm, soapy water. Ensure the filters are dry before placing them back in the vacuum.

    For more information, see page 6 of the manual.
    Was this helpful?
  • How often should I clean or replace the filter in my Black & Decker FLEX HFVAB320JC?

    Both the plastic pre-filter and the pleated filter should be cleaned regularly. The dust container must be emptied regularly, preferably after every use.


    For more information, see page 5 of the manual.
    Was this helpful?
  • What attachments are included with the Black & Decker FLEX HFVAB320JC?

    The included attachments are:

    • 2-in-1 nozzle accessory (12)
    • Crevice tool (13)
    • Pet hair tool (14)
    • Extendable flexible crevice tool (17)

    For more information, see pages 3 and 4 of the manual.
    Was this helpful?
  • How long does it take to charge the Black & Decker FLEX HFVAB320JC?

    The rechargeable cells of the product need a minimum charge time of 13 hours to ensure full power.

    Was this helpful?
  • What type of filter does the Black & Decker FLEX HFVAB320JC use?

    The Black & Decker FLEX HFVAB320JC uses both a plastic pre-filter and a pleated filter.


    For more information, see page 5 of the manual.
    Was this helpful?
  • What are the best ways to use the Black & Decker FLEX HFVAB320JC for various tasks?

    For optimal use:

    Was this helpful?
  • How do I assemble the Black & Decker FLEX HFVAB320JC vacuum cleaner?

    To assemble the vacuum cleaner:

    • Attach accessories by pressing the accessory clip and sliding the accessory onto the handle. To remove, press the accessory clip and remove the accessory.
    • To unwrap and extend the handle and hose, grab the handle and lift upwards. Unwrap the handle and hose from the main appliance. The hose can extend up to approximately 4 feet (1.21m).
    • To place the handle and hose back, wrap the hose back underneath and around the vac, ensuring the hose fits between the two “feet” of the appliance. Align the handle with its cradle and click back into place.
    • The handle can be removed from the hose allowing accessories to be connected directly to the hose cuff.

    For more information, see page 4 of the manual.
    Was this helpful?
Need help?

Need help?

Do you have a question about the FLEX HFVAB320JC and is the answer not in the manual?

Questions and answers

Jose Bove
June 3, 2025

How long should you charge cleaner

0
1 comments:
Mr. Anderson
June 3, 2025

You should charge the Black & Decker FLEX HFVAB320JC cleaner for a minimum of 13 hours when it is new to ensure full energy.

This answer is automatically generated

0
RICHARD REIS
March 8, 2025

WHERE TO BUY REPLACEMENT BATTERY PACK & INSTRUCTIONS

0
1 comments:
Mr. Anderson
May 14, 2025

You can find a replacement battery pack at a BLACK+DECKER Company-Owned or Authorized Service Center. For instructions to remove the battery pack:

1. Turn the product on and let it run until the motor stops to fully discharge the battery.
2. Remove the removable bowl.
3. Invert the appliance to access the screws attaching the base.
4. Remove the two screws and lift off the battery housing.
5. Detach all lead connections from the battery pack.
6. Remove the battery pack.

For replacement parts or service, contact the nearest BLACK+DECKER Service Center.

This answer is automatically generated

0
Jean Edwards
February 15, 2025

Can the rechargeable battery be replaced? Black & Decker HFVSB320JCB

0
1 comments:
Mr. Anderson
February 15, 2025

The Black & Decker HFVAB320JC uses a Lithium-Ion rechargeable battery, which can be removed for recycling when it no longer holds a charge. However, the manual does not explicitly state that the battery is user-replaceable or that replacements are available for purchase.

This answer is automatically generated

0
James Ramey
September 13, 2025

what is the battery pack part number for a hfvab320jc vacuum?

0
Robert McVerry
August 7, 2025

I have misplaced my charger for the B&D cordless flex car vac. Box says # HBVAB320JC26. What is the availability and cost of a replacement? Thanks,

0
RICHARD REIS
March 8, 2025

WHERE TO PURCHASE REPLACEMENT BATTERY PACK & INSTRUCTIONS

0

Related Manuals for Black & Decker FLEX HFVAB320JC

Summary of Contents for Black & Decker FLEX HFVAB320JC

  • Page 1 FLEX™ VAC INSTRUCTION MANUAL CATALOG NUMBERS HFVAB320JC PLEASE READ BEFORE RETURNING THIS PRODUCT FOR ANY REASON. If you have a question or experience a problem with your Black+Decker purchase, go to http://www.blackanddecker.com/instantanswers If you can’t find the answer or do not have access to the Internet, call 1-800-544-6986 from 8 a.m.

  • Page 2: Safety Guidelines - Definitions

    SAFETY GUIDELINES - DEFINITIONS It is important for you to read and understand this manual. The information it contains relates to protecting YOUR SAFETY and PREVENTING PROBLEMS. The symbols below are used to help you recognize this information. DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 3: Additional Safety Warnings

    FUCTIONAL DESCRIPTION there is a possibility of small debris being 1. On/off power switch discharged from the air vents, especially 2. Removable handle after cleaning / replacement of the filters 3. Locking ring as debris inside the unit can be disturbed. 4.

  • Page 4: Operation

    While charging, the charger may get warm, this is perfectly normal and safe. It is safe to leave the appliance connected to the charger indefinitely. The charger automatically reduces power consumption To unwrap and extend the handle and hose: The handle and hose can be unwrapped when charging is complete.
  • Page 5 off switch to the left until it clicks into the for better access. off position. CLEANING FILTERS (FIGURES G - I) Both the plastic pre-filter (18) and the VACUUMING pleated filter (19) are re-usable and should • When operating the appliance, make sure be cleaned regularly.

  • Page 6: Troubleshooting

    TROUBLESHOOTING If the product does not work, check the following: • The charger was correctly plugged in for recharge. • The charger cord is not damaged and is correctly attached to the charging base. • The charger is plugged into a working electrical outlet.

  • Page 7: Maintenance

    TWO-YEAR LIMITED WARRANTY Black & Decker (U.S.) Inc. warranties this product to be free from defects in material or workmanship for a period of two (2) years following the date of purchase, provided that the product is used in a home environment. This limited warranty does not cover failures due to abuse, accidental damage or when repairs have been made or attempted by anyone other than BLACK+DECKER and its Authorized Service Centers.
  • Page 8 ASPIRATEUR SANS FIL À MINI-RÉSERVOIR MODE D’EMPLOI NUMERO DE CATALOGUE HFVAB320JC À LIRE AVANT DE RETOURNER CE PRODUIT POUR QUELQUE RAISON QUE CE SOIT : Si des questions ou des problèmes surgissent après l’achat d’un produit Black+Decker, consulter le site Web www.blackanddecker.com/instantanswers pour obtenir des réponses instantanément 24 heures par jour.

  • Page 9: Consignes De Sécurité Additionnelles

    CONS IGNES DE SÉCURITÉ chauffées. • Ne pas débrancher l’appareil en tirant RTANTES IMPO sur son cordon. Pour le débrancher, Lors de l’utilisation d’appareils électriques, saisir la fiche et non le cordon. toujours observer des précautions de • Ne pas manipuler la fiche si vous avez base, notamment les suivantes : les mains mouillées.

  • Page 10: Description Fonctionnelle

    DESCRIPTION position de marche, invite les accidents. b) Le recharger seulement avec le FONCTIONNELLE chargeur spécifié par le fabricant. 1. Interrupteur marche/arrêt Un chargeur propre à un type de bloc- 2. Poignée amovible piles peut créer des risques d’incendie 3. Bague de blocage lorsqu’utilisé...
  • Page 11 Durant le chargement, le chargeur peut devenir chaud; ceci est tout à fait normal et ne présente aucun danger. Il est sécuritaire de laisser l’appareil branché au chargeur indéfiniment. Le chargeur réduit automatiquement la consommation Pour détacher et allonger la poignée et électrique lorsque la charge est complète.
  • Page 12 du tuyau (17) si désiré. CONSEILS POUR OPTIMISER L’UTILISATION • Lorsque l’on passe l’aspirateur dans les escaliers, il faut toujours commencer dans le bas et progresser vers le haut. • Utiliser l’outil de nettoyage des poils pour déloger et aspirer les poils et la saleté...

  • Page 13: Dépannage

    • Tourner la poignée vers l’arrière de • Enfoncer le bouton de dégagement qui l’appareil comme le montre la figure J. se trouve du côté opposé de la poignée, • Tirer latéralement sur le contenant à par rapport à la trappe du contenant à poussière pour le détacher de la base de poussière (5), et le maintenir enfoncé.

  • Page 14: Entretien

    RETRAIT ET ÉLIMINATION DES PILES AVERTISSEMENT : S’assurer que Ce produit utilise des piles rechargeables l’aspirateur est complètement sec avant et recyclables Lithium Ion. Quand les piles de l’utiliser. ne tiennent plus la charge, elles doivent être IMPORTANT : Pour garantir la SÉCURITÉ retirées de l’aspirateur et recyclées.
  • Page 15 un avis technique, une réparation ou des pièces de rechange authentiques installées en usine, communiquer avec l’établissement BLACK+DECKER le plus près de chez vous. Pour trouver l’établissement de réparation de votre région, composer le numéro suivant : 1 800 544-6986 ou consulter le site www.blackanddecker.com GARANTIE LIMITÉE DE DEUX ANS Black &...
  • Page 16 ASPIRADORA INALÁMBRICA CON MINIDEPÓSITO MANUAL DE INSTRUCCIONES CATÁLOGO N° HFVAB320JC LEA EL MANUAL ANTES DE DEVOLVER ESTE PRODUCTO POR CUALQUIER MOTIVO: Si tiene una consulta o algún inconveniente con su producto Black+Decker, visite http://www.blackanddecker.com/instantanswers para obtener respuestas instantáneas las 24 horas del día. Si no encuentra la respuesta o no tiene acceso a Internet, llame al 1-800-544-6986 de lunes a viernes de 8 a.

  • Page 17: Instrucciones De Seguridad Importantes

    INSTRUCCIONES DE mojadas. • No inserte ningún objeto en los orificios SEGURIDAD IMPORTANTES de la unidad. No la utilice si alguno de Al utilizar aparatos eléctricos, siempre los orificios está bloqueado, manténgala deben seguirse algunas precauciones libre de polvo, pelusas, pelos y cualquier básicas, entre las que se incluyen: cosa que pueda reducir el flujo de aire.

  • Page 18: Descripción De Las Funciones

    10. Depósito desmontable incendio si se utiliza con otra batería. 11. Sujetador para accesorios c) En condiciones de abuso, el líquido 12. Accesorio de boquilla 2 en 1 puede salirse de la batería; evite el 13. Herramienta para ranuras contacto. Si se produce un contacto 14.
  • Page 19 mango con su base y vuelva a encajarlo en su a temperaturas de ambiente inferiores a lugar. 10 °C (50 °F) o superiores a 40 °C (104 °F). El mango (2) puede extraerse de la manguera, lo que permite conectar los Ensamblaje accesorios directamente a la boquilla de la MONTAJE DE ACCESORIOS...
  • Page 20 • Desenrolle la manguera (4) y el mango (2) 2. Puede aspirar con el mango (2) y la manguera (4) desenrollados del aparato de la parte principal del aparato. principal; esto le permite alcanzar una • Tire del seguro de la puerta (8) y abra la distancia máxima de aproximadamente puerta del depósito para polvo (5) y vacíe 1,2 m (4 pies) con respecto al aparato.

  • Page 21: Mantenimiento

    reciclarlas. O bien, consulte en la municipalidad aparato girando el filtro hacia la derecha y de su localidad para conocer las instrucciones tirando de este para extraerlo del aparato. de desecho adecuadas de su ciudad o localidad. • Después de quitar los filtros, limpie el Para quitar el paquete de baterías para depósito para polvo (10) y el prefiltro (23) su eliminación:...
  • Page 22 Es posible que se requiera el comprobante de compra. cadmio, níquel e hidruro metálico o de iones de litio Consulte al comerciante minorista sobre su política gastadas en la basura o la corriente de residuos sólidos específica de devoluciones con respecto a los límites de urbanos;...
  • Page 23 · GARANTÍA BLACK +DECKER · BLACK+DECKER WARRANTY . SOLAMENTE PARA PROPOSITOS DE MEXICO Distributor Name · Sello firma del distribuidor Date of purchase · Fecha de compra Invoice No. · No. de factura PRODUCT INFOMATION · IDENTIFICACIÓN DEL PRODUCTO Cat. No. · Catalogo ó Modelo Serial Number ·...
  • Page 24 SOLAMENTE PARA PROPOSITOS DE MEXICO Grupo Realsa en herramientas, Herramientas y Equipos Profesionales S.A. de C.V. Av. Colón 2915 Ote. Súper Manzana 69 MZ.01 Lote 30 Col. Francisco I. Madero (Av. Torcasita) Monterrey, Nvo. León Col. Puerto Juárez Tel. 01 81 83 54 60 06 Cancún, Quintana Roo Htas.
